Anping County Boli Hardware Wiremesh Products Factory, a trusted manufacturer since 1998, proudly presents our premium Filter Mesh for Water Treatment System crafted from 316L stainless steel with a precise 200 mesh count and 0.05mm wire diameter. This high-performance mesh is engineered to deliver exceptional filtration efficiency, durability, and corrosion resistance, making it an ideal choice for demanding water treatment applications. With over 20 years of experience and annual export value exceeding US$5 million, we ensure every roll meets international quality standards.
Our 316L filter mesh is specifically designed to remove fine particles, sediments, and contaminants from water systems while maintaining high flow rates. The combination of 200 mesh (0.077mm opening) and ultra-fine 0.05mm wire diameter provides a balanced filtration area and mechanical strength, suitable for both municipal and industrial water treatment processes.
Key Features & Technical Specifications:
- Material: 316L stainless steel – enhanced molybdenum content for superior resistance to chlorides, acids, and alkaline environments.
- Mesh Count: 200 mesh (200 openings per linear inch) – precisely woven to ensure consistent particle retention.
- Wire Diameter: 0.05mm – ultra-fine yet strong, providing excellent filtration without clogging.
- Opening Size: Approximately 77 microns (0.077mm) – effectively removes particles down to fine silt and sand.
- Weave Type: Plain weave – uniform structure for reliable filtration and easy cleaning.
- Corrosion Resistance: Excellent – suitable for seawater, wastewater, and chemical filtration.
- Temperature Range: Up to 800°C (1472°F) in oxidizing atmospheres, ideal for hot water or steam filtration.
- Customizable Dimensions: Available in rolls of various widths (1m, 1.2m, 1.5m, 2m) and lengths (30m, 50m, or custom).
Technical Parameters Table:
| Parameter | Value |
|---|---|
| Material Grade | 316L (UNS S31603) |
| Mesh Count | 200 mesh |
| Wire Diameter | 0.05 mm |
| Opening Size | 0.077 mm (77 micron) |
| Open Area | Approximately 37% |
| Tensile Strength | ≥ 600 N/mm² |
| Standard Width | 1.0 m – 2.0 m (customizable) |
| Standard Length | 30 m / 50 m per roll |
Benefits for Your Water Treatment System:
- High Filtration Precision: The 200 mesh with 77 micron openings effectively captures fine sand, rust, algae, and suspended solids, protecting downstream equipment.
- Long Service Life: 316L stainless steel offers superior resistance to pitting and crevice corrosion in chlorinated water, reducing replacement frequency.
- Easy Maintenance: The plain weave structure allows straightforward backwashing or chemical cleaning, minimizing downtime.
- Versatile Compatibility: Suitable for multi-media filters, sediment filters, strainers, and industrial water treatment skids.
- Cost-Effective: Durable material and customizable dimensions help reduce total cost of ownership over time.
Trusted by Global Markets: Our factory in Hengshui, Hebei, China has been serving customers across North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and beyond. With annual export value of US$5 million to US$10 million, we have established a reputation for consistent quality and reliable delivery. We ship from major ports including Tianjin, Qingdao, Shanghai, and Foshan, ensuring fast logistics.
Why Choose Anping County Boli Hardware Wiremesh Products Factory?
- Over 25 years of specialized wire mesh manufacturing experience.
- Strict quality control from raw material inspection to final packing.
- Customizable mesh size, width, length, and edge finishing (cut edges, welded edges, etc.).
- Competitive pricing with OEM/ODM services available.
- Small trial orders accepted to test product performance.
Frequently Asked Questions (FAQ):
1. What is the difference between 316 and 316L stainless steel mesh?
316L has a lower carbon content (max 0.03%) compared to 316 (max 0.08%), which provides better weldability and corrosion resistance in as-welded conditions. For water treatment applications, 316L is preferred if the mesh will be welded or exposed to aggressive chemicals.
2. Can this mesh be used for seawater filtration?
Yes, 316L stainless steel is known for excellent resistance to chloride-induced corrosion, making it suitable for seawater, brackish water, and desalination pre-filtration.
3. What is the maximum operating temperature for this filter mesh?
In continuous use, 316L can withstand temperatures up to 800°C (1472°F) in oxidizing environments, but for water filtration, typical temperatures are well below 100°C, so it is fully safe.
4. How do I clean the mesh if it becomes clogged?
Backwashing with clean water or gentle brushing is recommended. For stubborn deposits, chemical cleaning with mild acidic or alkaline solutions (within pH 4-10) can be used. Avoid abrasive tools that may damage the wire.
5. Do you offer custom sizes for specific filter housings?
Yes, we can cut the mesh to your required width and length, or supply rolls for further fabrication. Edge treatments such as welded edges, reinforced borders, or gasket attachments are available upon request.
6. What is the typical lead time for bulk orders?
For standard sizes, lead time is 7-15 days after confirmation. For custom specifications, it may be 15-25 days depending on the complexity. We always strive to meet your delivery schedule.
7. Is this mesh suitable for food-grade water filtration?
316L stainless steel is commonly used in food processing and potable water systems. However, we recommend verifying specific local regulations. Our mesh can be supplied with a clean, oil-free surface upon request.
8. Can I get a sample before placing a large order?
Absolutely! We offer free samples (shipping cost may apply) for evaluation. Please contact our sales team with your requirements.
Contact us today to discuss your water treatment filtration needs. With decades of expertise and a global footprint, Anping County Boli Hardware Wiremesh Products Factory is your reliable partner for high-quality filter mesh. We look forward to providing you with a customized solution that meets your exact specifications.
