2000N Digital Automatic Valve Spring Load Tester 220V Lab Equipment for Spring Tension and Compression Testing
Product Spotlights
2000N Digital Automatic Valve Spring Load Tester 220V Lab Equipment for Spring Tension and Compression Testing
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Product Certifications:
ISO9001, Others
Port of Shipment:
qingdao, shanghai, tianjin
Main Markets:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, Domestic Market
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao，shanghai，tianjin
Delivery Detail:
25 days
Related Products
-
50N Digital Auto Coil Spring Compression Load Test Machine Spring Tester PriceUS$ 3650 - 4000MOQ: 1 Set -
500kg 5000N Digital Spring Load Testing Machine 7-inch Touch Screen for Tension Compression SpringsUS$ 2760 - 2950MOQ: 1 Set
-
Zhongchuang Digital Automatic Spring Load Force Testing Machine 2000N Digital DisplayUS$ 2450 - 2650MOQ: 1 Set
-
2000N Automatic Coil Spring Compression Load Testing Machine Laboratory EquipmentUS$ 2500 - 2650MOQ: 1 Set
-
Spring Tension and Compression Tester Small Spring Compression TesterUS$ 2550 - 2650MOQ: 1 Set
Spring Tension and Compression Testing
Max test force |
1000N 2000N |
Display type |
7 inch industrial touch screen |
Test force range |
1%-100% |
Min reading value of test force |
0.1N |
Relative error of zero point |
±0.1% |
Relative error of test force indicating value |
±1.0% |
Relative error of indicating value repeatability of test force |
1.0% |
Resolution of displacement |
0.001mm |
Effective test space |
300mm |
Diameter of pressure plate |
100mm |
Parallelism error of up and down pressure plate |
≤0.10 mm |
Test speed range |
0.01mm/min-500mm/min |
Error of deformation indication value |
≤±(50+0.15L) |
Size of testing machine |
434*275*850mm |
Weight of testing machine |
90kg |
Protection function |
Over-load protection function |
Power supply |
AC 220V±10% 50Hz |
