Help Center304 Stainless Steel Welded Wire Mesh, 0.8mm Wire, 12.7mm x 12.7mm Opening, for Industrial Filtering
Product Spotlights
Related Products
-
Galvanized Welded Wire Mesh With Wire Diameter 2.0mm and Mesh Opening 50mm x 50mm for FencingNegotiableMOQ: 500 Acres -
Welded Wire Mesh for Agricultural Fencing, 2.5mm Galvanized Wire, 50mm x 100mm Mesh, Standard CompliantNegotiableMOQ: 500 Acres
-
Hot-Dipped Galvanized Welded Wire Mesh, 2.5mm Wire Thickness, 100mm x 50mm Grid, Mill Test Report IncludedNegotiableMOQ: 500 Acres
-
PVC Coated Welded Wire Mesh, Wire Diameter 1.8mm, 1 Inch x 1 Inch Mesh, 1 Year WarrantyNegotiableMOQ: 500 Acres
-
PVC Coated Welded Wire Mesh, Wire Diameter 1.5mm, Mesh 1/2"x1/2", Weatherproof for Outdoor FencingNegotiableMOQ: 50 Acres
As a leading manufacturer based in Hengshui, Hebei, China, Anping Xinye Metal Wire Mesh Products Co., Ltd. specializes in producing high-quality welded wire mesh for diverse industrial applications. Our 304 Stainless Steel Welded Wire Mesh with 0.8mm wire diameter and 12.7mm x 12.7mm opening is engineered to deliver reliable performance in demanding filtration environments. This product combines the corrosion resistance of 304 stainless steel with precise welding technology, ensuring consistent opening sizes and long service life.
Designed specifically for industrial filtering, sieving, and separation, this mesh excels in applications such as liquid filtration, powder screening, chemical processing, food & beverage production, and wastewater treatment. The 0.8mm wire offers a balanced strength-to-open-area ratio, while the 12.7mm square openings allow efficient flow of particles within a specific size range. Each panel is manufactured under strict quality control to maintain uniform mesh geometry.
Key Features & Technical Specifications:
- Material: Grade 304 stainless steel (equivalent to 1.4301) – excellent resistance to oxidation, rust, and many chemicals.
- Wire Diameter: 0.8 mm (±0.02 mm tolerance) – provides adequate stiffness while maintaining flexibility for cutting and forming.
- Opening Size: 12.7 mm x 12.7 mm (1/2 inch square) – ideal for separating particles from 8 mm to 12 mm, or as a support layer for finer filter media.
- Welding Process: Resistance welding at each intersection – ensures strong, durable joints that withstand repeated cleaning and mechanical stress.
- Surface Finish: Mill finish (bright annealed or natural) – no additional coating, suitable for direct contact with food products (subject to local regulations).
- Customization: Available in various sheet sizes, rolled lengths, and edge treatments (e.g., welded borders, cut edges, or hooked edges).
- Packaging: Standard export packaging with wooden pallets, plastic wrapping, and steel straps to prevent damage during transit.
| Parameter | Value |
|---|---|
| Material Grade | 304 Stainless Steel (UNS S30400) |
| Wire Diameter | 0.8 mm (0.0315 inch) |
| Opening Size | 12.7 mm x 12.7 mm (1/2 inch x 1/2 inch) |
| Open Area | Approximately 88% (calculated: (12.7/(12.7+0.8))^2 × 100) |
| Mesh Count | 2 x 2 wires per inch (approx.) |
| Tensile Strength | ≥ 520 MPa (typical for 304 SS wire) |
| Max Operating Temperature | Up to 870°C in intermittent service; 870°C continuous (oxidation resistance) |
| Standard Sheet Size | 1 m x 2 m (custom sizes available) |
Advantages for Industrial Filtration:
- High Open Area: With nearly 88% open area, the mesh offers minimal flow resistance, reducing pressure drop in filtration systems.
- Chemical Compatibility: 304 stainless steel resists a wide range of acids, alkalis, and organic solvents, making it suitable for chemical and pharmaceutical filtration.
- Easy to Clean: The smooth surface and welded construction allow for thorough cleaning via backwashing, ultrasonic cleaning, or chemical washing.
- Dimensional Stability: Welded intersections prevent wire shifting, ensuring consistent opening size even under high flow or vibration.
- Customizable Fabrication: Mesh can be cut, bent, welded, or formed into filter baskets, cylindrical cages, discs, and other custom shapes.
Trust & Reliability: At Anping Xinye, we have been manufacturing wire mesh products for over a decade, serving clients in more than 30 countries. Our factory is equipped with automated welding machines and rigorous inspection procedures. We ensure that every roll or sheet of 304 stainless steel welded wire mesh meets the dimensional tolerances required by your application. From raw material sourcing to final packaging, we maintain traceability and quality consistency. We also offer free samples for evaluation (shipping costs may apply), and our technical team is ready to assist with custom specifications. Contact us today to discuss your filtration needs – we are committed to providing cost-effective solutions without compromising on quality.
Frequently Asked Questions:
Q1: What is the difference between 304 and 316 stainless steel for this mesh?
A: 304 stainless steel offers excellent corrosion resistance in most environments, including food processing and mild chemical exposure. For more aggressive chemicals or marine environments, 316 stainless steel (with molybdenum) is recommended. We can produce the same mesh in 316 upon request.
Q2: Can this mesh be used for high-temperature filtration?
A: Yes, 304 stainless steel can withstand continuous service temperatures up to 870°C (1600°F) in oxidizing atmospheres. However, the mechanical strength decreases at elevated temperatures; please consult our technical team for your specific temperature and load conditions.
Q3: What sheet sizes are available?
A: Standard sheet sizes include 1 m x 2 m, 1.2 m x 2.4 m, and 1 m x 3 m. We also offer rolls up to 30 m long (depending on wire diameter and opening). Custom sizes are available upon request, with minimum order quantities.
Q4: How do I cut the mesh without causing deformation?
A: The mesh can be cut using metal shears, angle grinders with a cutting disc, or plasma cutters. For clean edges, we recommend using a fine-toothed blade in a reciprocating saw. We can also provide pre-cut panels to your exact dimensions.
Q5: Is this mesh suitable for food-grade applications?
A: 304 stainless steel is generally recognized as safe for food contact (FDA 21 CFR 177.2600). However, we recommend verifying with your local food safety authority, especially if the mesh will be used in direct contact with acidic foods or under high-temperature sterilization.
Q6: What is the minimum order quantity (MOQ)?
A: For standard sizes, the MOQ is 10 sheets or 50 square meters. For custom sizes or special edge treatments, MOQ may vary. We are flexible with sample orders for testing purposes.
Q7: How long does it take to produce and deliver?
A: For standard sizes in stock, we can ship within 7-10 working days. Custom orders typically require 15-20 working days. Delivery time depends on the destination and shipping method.
Q8: Can you provide a certificate of material compliance?
A: Yes, we can issue a mill test certificate (MTC) for the 304 stainless steel wire used in production. Please specify this requirement when placing your order.
With decades of experience in wire mesh manufacturing, Anping Xinye Metal Wire Mesh Products Co., Ltd. is your trusted partner for industrial filtration solutions. Our 304 stainless steel welded wire mesh is built to last, offering consistent performance and easy customization. We invite you to request a quote or sample – let us help you optimize your filtration process.
