As a leading Stainless Steel Heat Exchange Tube manufacturer based in Wuxi, China, Wuxi Yansheng Technology Co., Ltd. has been dedicated to delivering high-quality tubes for chemical processing applications since 2017. With a factory spanning 1,000–3,000 square meters and a team of 101–200 skilled employees, we combine advanced manufacturing techniques with rigorous quality control to produce tubes that withstand extreme temperatures, high pressures, and corrosive media. Our annual export value exceeding US$50 million reflects the trust of global clients across North America, Europe, Southeast Asia, and beyond. This tube is designed to maximize heat transfer efficiency while ensuring long-term reliability in harsh chemical environments.
Key Features & Technical Specifications
- Material Excellence: Made from premium stainless steel grades (304/304L, 316/316L, 321, 310S) to resist pitting, crevice corrosion, and stress corrosion cracking in acidic or alkaline media.
- Precision Dimensions: Outer diameters from 6 mm to 219 mm, wall thicknesses from 0.5 mm to 20 mm, and lengths up to 18 meters per piece – all customizable to meet your exact design requirements.
- Superior Welding & Seamless Options: Available in both welded and seamless configurations, with full penetration welding and 100% eddy current or hydrostatic testing available upon request.
- Surface Finish Flexibility: Choose from bright annealed, pickled, or polished finishes to optimize fluid flow, reduce fouling, and facilitate cleaning.
- Compliance with International Standards: Manufactured in accordance with ASTM A213, A269, A249, and EN 10216-5, ensuring compatibility with global engineering codes.
- Certified Quality Systems: Our production is backed by ISO9001, ISO14000, OHSAS18001, SA8000, HACCP, and other certifications, guaranteeing consistent quality and responsible manufacturing.
Typical Parameters (Reference Table)
| Parameter | Value Range | Notes |
|---|---|---|
| Outer Diameter | 6 – 219 mm | Custom sizes available |
| Wall Thickness | 0.5 – 20 mm | SCH 5S, 10S, 40S, 80S etc. |
| Length | Up to 18,000 mm | Custom lengths upon request |
| Tensile Strength | ≥ 515 MPa (for 316L) | Varies by grade |
| Yield Strength | ≥ 205 MPa (for 316L) | Varies by grade |
| Hardness | ≤ 90 HRB (for 316L) | Annealed condition |
Why Choose Our Stainless Steel Heat Exchange Tube?
- Enhanced Heat Transfer: Optimized wall thickness and surface finish reduce thermal resistance, improving overall heat exchanger efficiency by up to 15% compared to standard tubes.
- Long Service Life: Superior corrosion resistance minimizes downtime and replacement costs, especially in environments with chlorides, sulfuric acid, or caustic solutions.
- Customization: We offer tailor-made solutions including U-bending, swaging, and special end preparations to fit your specific heat exchanger design.
- Reliable Supply Chain: With multiple ports of shipment (Tianjin, Shanghai, Qingdao, Ningbo) and flexible production capacity, we ensure on-time delivery for large-volume orders.
- Technical Support: Our experienced engineering team provides material selection guidance, welding recommendations, and after-sales service to ensure your project success.
Trust & Credibility
Wuxi Yansheng Technology Co., Ltd. has been a reliable manufacturer since 2017, exporting over US$50 million annually to markets across North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. Our factory is ISO9001, ISO14000, OHSAS18001, SA8000, and HACCP certified, reflecting our commitment to quality, safety, and social responsibility. We have served more than 200 chemical processing clients worldwide, many of whom have placed repeat orders for their critical heat exchanger projects. By choosing our stainless steel tubes, you are partnering with a supplier that values precision, durability, and customer satisfaction above all. Contact us today for a quote or technical consultation – we are ready to support your next chemical processing application.
Frequently Asked Questions (FAQ)
Q1: What stainless steel grades are best for heat exchange tubes in chemical processing?
A: The most common grades are 304/304L for general corrosion resistance, and 316/316L for enhanced resistance to chlorides and acids. For high-temperature or highly corrosive environments, we also offer 321 and 310S. Our team can recommend the ideal grade based on your specific process conditions.
Q2: Can you provide tubes with custom dimensions?
A: Yes, we offer fully customizable outer diameters (6–219 mm), wall thicknesses (0.5–20 mm), and lengths up to 18 meters. Please provide your design drawings or specifications, and we will produce tubes that match your requirements.
Q3: Are your tubes suitable for high-pressure applications?
A: Absolutely. Our tubes are manufactured to ASTM and EN standards, with wall thicknesses that can be selected to meet pressure ratings. We also perform hydrostatic testing and eddy current testing as needed to ensure structural integrity under high pressure.
Q4: What surface finishes do you offer, and which one is best for reducing fouling?
A: We offer bright annealed, pickled, and polished finishes. For chemical processing where fouling is a concern, a polished finish (Ra ≤ 0.8 μm) minimizes surface roughness and reduces deposit buildup, improving heat transfer efficiency over time.
Q5: How do you ensure the quality of each tube?
A: We follow a strict quality management system certified under ISO9001. Each batch undergoes dimensional inspection, mechanical property testing, and corrosion resistance checks. We also provide mill test certificates (MTC) with every shipment to guarantee traceability.
Q6: What is the typical lead time for an order?
A: For standard sizes, lead time is approximately 15–25 days after order confirmation. Custom orders may require 25–40 days depending on complexity and quantity. We work with multiple shipping ports to ensure timely delivery worldwide.
Q7: Do you offer samples for testing?
A: Yes, we can provide sample tubes (typically 300–500 mm length) for evaluation. The sample cost is negotiable, and it is refundable for bulk orders. Please contact our sales team to arrange samples.
Q8: Can you handle large-volume orders for international projects?
A: Certainly. With an annual export value exceeding US$50 million and a factory capacity of over 300 tons per month, we are well-equipped to fulfill large-scale orders. Our experienced logistics team ensures smooth customs clearance and delivery to any destination.
