Help CenterDIN EN10210 Galvanized Square Steel Tube Hollow Section Building Material
Product Spotlights
Related Products
-
Straight Bright Stainless Steel Bar Round Stainless Steel Bar With Complete SpecificationsUS$ 2.7 - 5MOQ: 100 Kilograms -
Corrosion Resistant 304 316 Stainless Steel Bar For Construction Chemical EquipmentUS$ 2.7 - 5MOQ: 100 Kilograms
-
SUS304 316L 310S 2205 321 904L Stainless Steel Round Bar Bright RodUS$ 2.7 - 5MOQ: 100 Kilograms
-
Stainless Steel Round Flat Angle Square Bar Grade 304 316 409 Factory Price AISIUS$ 2.7 - 5MOQ: 100 Kilograms
-
AISI 201-430 Stainless Steel Bar Rod Round Square Hex Flat Angle Channel Profiles 304/304L/316LUS$ 1.65 - 2.85MOQ: 100 Kilograms
Wuxi Yansheng Technology Co., Ltd., established in 2017, is a professional manufacturer of high-quality steel products with an annual export value exceeding US$50 million. Our DIN EN10210 Galvanized Square Steel Tube Hollow Section is a premium building material designed for structural integrity and long-lasting performance. With a factory spanning 1,000–3,000 square meters and a dedicated team of 101–200 employees, we deliver precision-engineered hollow sections that meet stringent European standards, ensuring reliability for your construction projects.
Our galvanized square steel tubes are produced using advanced cold-forming or hot-rolling processes, followed by hot-dip galvanizing to provide superior corrosion resistance. The DIN EN10210 standard guarantees consistent mechanical properties and dimensional accuracy, making these hollow sections ideal for load-bearing structures, frameworks, and architectural applications. Available in various sizes and wall thicknesses, they offer excellent strength-to-weight ratio and ease of fabrication.
Key Features & Technical Specifications
Compliance: Manufactured strictly to DIN EN10210 (hot-finished structural hollow sections) with EN 10210-2 tolerances.
Material Grade: Available in carbon steel grades such as S235JRH, S355J2H, and S275J0H, ensuring excellent weldability and toughness.
Surface Finish: Hot-dip galvanized coating (minimum 85 µm, per EN ISO 1461) for exceptional corrosion resistance in outdoor and harsh environments.
Dimensional Range: Square sections from 20×20 mm to 400×400 mm, wall thickness from 1.5 mm to 16 mm, and lengths up to 12 m (custom lengths available upon request).
Mechanical Properties: Yield strength ≥ 235 MPa (for S235JRH), excellent impact resistance at low temperatures.
Fabrication: Easy to cut, weld, drill, and form, suitable for trusses, pillars, handrails, and architectural frames.
| Parameter | Value |
|---|---|
| Standard | DIN EN10210 (EN 10210-1, EN 10210-2) |
| Material Grade | S235JRH, S275J0H, S355J2H, S355J0H, etc. |
| Surface Coating | Hot-dip galvanized, coating weight ≥ 600 g/m² |
| Square Section Size | 20×20 mm – 400×400 mm |
| Wall Thickness | 1.5 mm – 16 mm |
| Length | 6 m, 12 m (customizable) |
| Tolerance | EN 10210-2 Class B (standard) |
Product Advantages: Compared to ordinary black steel tubes, our galvanized square hollow sections provide up to 5–10 times longer service life in corrosive environments. The uniform zinc coating ensures complete coverage inside and outside the tube, eliminating the need for additional painting. The square shape offers high torsional rigidity and aesthetic appeal, widely used in modern architectural designs, solar panel supports, and industrial structures.
Customer Benefits: By choosing our DIN EN10210 galvanized square tubes, you reduce maintenance costs, improve structural safety, and accelerate project timelines. The consistent quality and precise dimensions minimize on-site adjustments. We offer flexible packaging (bundled, waterproof covers) and shipping via major ports (Tianjin, Shanghai, Qingdao, Ningbo) to destinations worldwide.
Trust & Reliability: Wuxi Yansheng Technology Co., Ltd. has been serving global markets including North America, Europe, Southeast Asia, and Africa since 2017. Our factory is ISO9001 certified (quality management system), and we strictly follow DIN EN10210 standards. With an annual export value of US$50–100 million, we have proven capability to handle large-volume orders with consistent quality. Our dedicated QC team performs dimensional checks, chemical composition analysis, and mechanical testing on every batch. We also offer third-party inspection support (e.g., SGS, BV) upon request.
Contact us today for a competitive quotation and fast delivery! Our experienced sales team can assist with custom sizes, special grades, or additional processing (cutting, drilling, threading). Let our high-quality galvanized square steel tubes be the foundation of your next successful project.
Frequently Asked Questions (FAQ)
Q: What is the difference between DIN EN10210 and EN10219?
A: DIN EN10210 covers hot-finished structural hollow sections, while EN10219 covers cold-formed sections. Our product is hot-finished, offering better dimensional accuracy and uniform mechanical properties.Q: Can you provide custom lengths and wall thicknesses?
A: Yes, we offer custom lengths (e.g., 9 m, 10 m) and wall thicknesses within the production range. Please contact our sales team with your requirements.Q: How long does the galvanized coating last?
A: The hot-dip galvanized coating typically lasts 20–50 years in normal atmospheric conditions, depending on the environment. It provides excellent corrosion protection without maintenance.Q: Are these tubes suitable for load-bearing structures?
A: Absolutely. They are designed for structural applications such as columns, beams, trusses, and bracing. The DIN EN10210 standard ensures high yield strength and toughness.Q: What certifications do you have?
A: Our factory is ISO9001 certified. We also comply with HACCP, SA8000, and other management systems. Specific product certificates (e.g., EN 10210 compliance report) can be provided with each shipment.Q: What is the minimum order quantity (MOQ)?
A: For standard sizes, the MOQ is 5 tons. For custom sizes, MOQ may be higher. Please inquire for details.Q: How do you pack the tubes for export?
A: We use steel strapping, waterproof paper, and plastic caps to protect the ends. Tubes are bundled securely for container loading. Custom packaging is available upon request.Q: Can you arrange third-party inspection?
A: Yes, we can arrange inspection by SGS, BV, or other accredited agencies at the buyer’s cost. Our QC team will also provide mill test certificates.
