Welcome to Anping Xinye Metal Wire Mesh Products Co., Ltd, your trusted partner in high-quality wire mesh solutions from Hengshui, Hebei, China. Our 316 Stainless Steel Welded Wire Mesh with 3mm Wire Diameter and 1 Inch Square Opening is designed for demanding industrial applications where corrosion resistance, strength, and precision are critical. Each roll or panel comes with a Mill Test Report to guarantee material integrity and traceability. Whether you need reliable filtration media, security fencing, or concrete reinforcement, this product delivers consistent performance you can count on.
Key Features & Benefits
- Superior Corrosion Resistance: Made from genuine 316 stainless steel, offering excellent resistance to chlorides, acids, and marine environments — ideal for coastal or chemical processing applications.
- Heavy-Duty 3mm Wire Diameter: Provides exceptional tensile strength and rigidity, suitable for high-traffic areas, heavy loads, and structural reinforcement.
- Precise 1 Inch Square Opening: Consistent aperture size ensures accurate screening, sorting, and separation. The square pattern allows efficient flow while maintaining structural integrity.
- Resistance Welded Construction: Each intersection is fused at high temperature, creating a strong, monolithic mesh that resists deformation and maintains shape under stress.
- Mill Test Report Included: Every shipment comes with a certified mill test report verifying chemical composition and mechanical properties — giving you full material traceability and quality assurance.
- Versatile Applications: Suitable for fencing, cages, partitions, filtration baskets, walkway mesh, gabion baskets, and concrete reinforcement.
- Customizable Options: Available in rolls (standard 1m x 30m) or cut-to-size panels. Custom widths, lengths, and edge treatments (e.g., welded border, loops) are available upon request.
Technical Specifications
| Parameter | Value |
|---|---|
| Material | 316 Stainless Steel (UNS S31600) |
| Wire Diameter | 3.0 mm (0.118 inch) |
| Opening Size (Center to Center) | 25.4 mm x 25.4 mm (1 inch x 1 inch) |
| Open Area | Approx. 76% |
| Mesh Count (per inch) | 0.5 (approx. 2 openings per inch) |
| Standard Roll Size | 1m x 30m (3.3ft x 98ft) — other sizes customizable |
| Tensile Strength | ≥ 550 MPa (typical for 316 wire) |
| Surface Finish | As welded, bright or matte (optional passivation) |
Detailed Product Description
Our 316 Stainless Steel Welded Wire Mesh is manufactured using high-quality 316 stainless steel wire, which contains molybdenum for enhanced pitting and crevice corrosion resistance compared to 304 grade. The 3mm wire diameter creates a robust mesh that can withstand heavy loads and impact, making it suitable for industrial flooring, walkways, and machine guards. The 1-inch square opening offers a balance between strength and visibility, allowing light, air, and small particles to pass through while keeping larger objects contained.
Each intersection is precision resistance-welded, ensuring that the mesh remains intact even under continuous vibration or stress. The welded joints are smooth and free of sharp edges, reducing the risk of injury during handling and installation. For applications where hygiene is critical, such as food processing or pharmaceutical environments, the smooth surface facilitates easy cleaning and sterilization.
The Mill Test Report accompanying each order provides detailed chemical analysis (e.g., chromium, nickel, molybdenum content) and mechanical test results (tensile, yield, elongation). This documentation is essential for quality control, compliance with industry standards, and customer peace of mind. We recommend retaining the report for future reference.
Why Choose Anping Xinye?
Based in the renowned wire mesh manufacturing hub of Anping County, Hebei, China, our company has years of experience producing high-quality welded wire mesh for global markets. We adhere to strict quality control procedures at every stage — from raw material sourcing to final packaging. Our team ensures that every roll or panel meets your specifications before shipment. With a commitment to customer satisfaction, we offer prompt delivery, competitive pricing, and responsive after-sales support. Many clients in the mining, construction, and filtration industries rely on our products for their critical applications.
Frequently Asked Questions (FAQ)
-
Q: What is the difference between 304 and 316 stainless steel welded mesh?
A: 316 contains molybdenum (2-3%), which provides superior resistance to chlorides, saltwater, and acidic environments. It is preferred for marine, chemical, and food processing applications. 304 is suitable for general indoor use but may corrode faster in harsh conditions. -
Q: Can this mesh be used in seawater or coastal areas?
A: Yes, 316 stainless steel is specifically designed for marine environments. The 3mm wire diameter adds extra durability against wave impact and corrosion. However, regular rinsing with fresh water is recommended to extend service life. -
Q: How do I cut or shape the welded mesh?
A: The mesh can be cut using angle grinders, bolt cutters, or plasma cutters. For clean edges, we recommend using a cut-off wheel. Custom sizes can also be pre-cut at our factory upon request. -
Q: Is the mesh suitable for concrete reinforcement?
A: Yes, with 3mm wire diameter and 1-inch openings, it provides excellent bond strength with concrete. It is commonly used in slabs, walls, and precast elements. However, for structural applications, please consult a civil engineer. -
Q: What is the typical lead time for orders?
A: Standard sizes (1m x 30m rolls) are usually shipped within 7-10 working days. Custom sizes may require 15-20 working days. We can expedite urgent orders upon request. -
Q: Do you provide samples before bulk order?
A: Yes, we offer free samples (shipping cost applies) for quality evaluation. Please contact our sales team to arrange a sample. -
Q: Is the Mill Test Report provided for each batch?
A: Yes, we include a Mill Test Report for every shipment, which details the chemical composition and mechanical properties of the wire used. This ensures full traceability and compliance with your quality requirements. -
Q: Can the mesh be galvanized or coated after welding?
A: While 316 stainless steel typically does not require additional coating, we can offer passivation or electropolishing services for enhanced corrosion resistance. Galvanizing is not recommended as it may reduce the benefits of stainless steel.
In summary, the 316 Stainless Steel Welded Wire Mesh 3mm Wire Diameter 1in Square Opening from Anping Xinye is a durable, corrosion-resistant, and precisely engineered product suitable for a wide range of industrial applications. With a certified Mill Test Report included, you can be confident in the material quality. Contact us today for a quote or to discuss your specific requirements. We look forward to serving you with reliable mesh solutions.
