What Is Tinplate Coil？
Product Definition：
Tinplate (Electrolytic Tinplate – ETP) is a thin cold-rolled low-carbon steel sheet coated with a layer of pure tin (≥99.8% Sn) on both sides through an electrolytic plating process--45. The tin coating provides excellent corrosion resistance, solderability, and a non-toxic surface, making tinplate the preferred material for food and beverage packaging, aerosol cans, chemical containers, and general metal packaging-.
Key Characteristics：
| Feature | Description |
|---|---|
| Food Grade Safety | Non-toxic, odorless, complies with FDA, EU, and GB food contact standards- |
| Excellent Corrosion Resistance | Tin coating provides both physical barrier and electrochemical protection-8 |
| High Formability | Suitable for deep drawing, stamping, bending, and roll forming- |
| Good Weldability | Tin coating enables high-frequency resistance welding for can body seams-8 |
| Printability | Excellent surface for lithographic printing, lacquering, and decorative coatings-8 |
| 100% Recyclable | Environmentally friendly with no loss of properties |
Why Choose Tinplate？
| Factor | Tinplate | Aluminum | Plastic | Glass |
|---|---|---|---|---|
| Food Safety | Excellent | Excellent | Variable | Excellent |
| Barrier Properties | Excellent (light, oxygen, moisture) | Excellent | Poor | Excellent |
| Strength | High | Moderate | Low | High (brittle) |
| Formability | Excellent | Excellent | Excellent | None |
| Recyclability | 100% | 100% | Limited | 100% |
| Cost | Moderate | Higher | Lower | Higher |
Typical Applications by Industry：
| Industry | Applications | Recommended Grades |
|---|---|---|
| Food & Beverage | Canned food, beverage cans, tea canisters, coffee tins, milk powder tins, fruit cans | MR, L (acidic foods), T3–T5 |
| Pharmaceutical | Medicine tins, pill boxes, health supplement containers | MR, T3–T4 |
| Chemical & Industrial | Paint cans, oil cans, chemical drums, aerosol cans, lubricant containers | SPCC, T2–T4 |
| Cosmetics & Personal Care | Cosmetic containers, perfume boxes, cream jars, hairspray cans | MR, T3–T5 |
| Gift & Packaging | Gift boxes, chocolate tins, COOKIE tins, promotional packaging | SPCC, T2–T3 |
| Electronics | Shielding cans, battery casings, electronic component enclosures-4 | DR8, T4 |
| Construction & Appliances | Decorative panels, appliance housings | SPCC, T2–T3 |
Key Specifications – Tinplate Coil
| Parameter | Specification / Range | Remarks |
|---|---|---|
| Standards | JIS G3303, ASTM A623, GB/T 2520, EN 10202, DIN EN 10203-13-45 | Others on request |
| Base Material (Steel Grade) | MR (most common), SPCC, L (acid-resistant), D (deep drawing)-1 | |
| Thickness | 0.14 mm – 0.60 mm-45 | Single-reduced (SR) & Double-reduced (DR)- |
| Width | 260 mm – 1500 mm-45-1 | Custom slitting available |
| Coil ID | 420 mm or 508 mm-13 | |
| Coil Weight | 3 – 10 tons per coil-13-45 | Custom coil weight available |
| Temper (Hardness) | T1, T2, T2.5, T3, T4, T5, DR7, DR7.5, DR8, DR9, DR9M, DR10-45 | See Screen 5 |
| Annealing Method | CA (Continuous Annealing) / BA (Batch Annealing)-45 | Affects formability |
| Tin Coating (Equal) | 1.1/1.1, 2.2/2.2, 2.8/2.8, 5.6/5.6, 8.4/8.4, 11.2/11.2 g/m²-1-45 | |
| Tin Coating (Differential) | 2.8/5.6, 5.6/8.4 g/m²-4-45 | Different coating on each side |
| Surface Finish | Bright (B), Stone (R), Silver (S), Matte (M)-1-13 | See Screen 6 |
| Surface Treatment | Passivation (chromate) + DOS oil coating-4 | Prevents oxidation |
| Density | 7.85 g/cm³ | |
| Testing | Chemical analysis, tensile, hardness, tin coating weight, pinhole test, corrosion test | Mill cert EN 10204 3.1 |
| Packaging | Vertical or horizontal, waterproof paper + steel straps + wooden pallet-13 | Seaworthy, ISPM 15 |
