Help CenterHot Rolled Steel H-Beam With Mill Test Report ASTM / JIS Standard
Product Spotlights
Related Products
-
Structural Carbon Steel I-Beam 100x50mm ASTM JIS Hot Rolled 6mNegotiableMOQ: 1 Ton -
Carbon Steel Rod 1045 Turned and Polished 30mm Diameter 3m Length 0.1mm ToleranceNegotiableMOQ: 1 Ton
-
Carbon Steel Rod Cold Drawn 12mm Round Bar 1m Length ISO 9001 Production LineNegotiableMOQ: 1 Ton
-
Carbon Steel Rod 1045 With 1 Year Warranty and Free Cutting ServiceNegotiableMOQ: 1 Ton
-
Carbon Steel Rod SAE 1018 Precision Ground ±0.05mm Tolerance for MachiningNegotiableMOQ: 1 Ton
Welcome to Hemaokang Steel (Shandong) Co., Ltd. – your reliable partner for high-quality steel products. Our Hot Rolled Steel H-Beam is manufactured with strict adherence to ASTM and JIS standards, and each batch comes with a complete Mill Test Report for full traceability. As a newly established company in 2025 with an annual export value exceeding US$50 million, we combine modern production capabilities with experienced export management to serve clients worldwide. Our H-beam is designed to meet the demanding requirements of structural steel applications, offering excellent load-bearing capacity and dimensional accuracy.
Below you will find a detailed overview of the product characteristics, technical specifications, and the benefits you can expect when choosing our H-beam for your projects.
Key Features and Advantages
- Superior Strength: Manufactured via hot rolling process, the H-beam provides high structural integrity and uniform mechanical properties.
- Strict Compliance: Meets ASTM A36, A992, JIS G3101 (SS400, SM490) standards – Mill Test Report supplied per shipment.
- Wide Range of Sizes: Available from 100mm x 100mm up to 900mm x 300mm, with lengths from 6m to 12m (custom lengths on request).
- Excellent Weldability and Formability: Carbon steel composition ensures easy welding, cutting, and drilling without compromising strength.
- Cost-Effective: Hot rolled process reduces production costs, making it an economical choice for large-scale projects.
- Traceability: Every beam is marked with heat number, grade, and standard; Mill Test Report includes chemical composition, mechanical properties, and dimensional inspection.
Technical Specifications (Typical Parameters)
| Parameter | Value/Range |
|---|---|
| Standard | ASTM A36, A992 / JIS G3101 (SS400, SM490, SM520) |
| Flange Width (B) | 100 – 300 mm |
| Web Height (H) | 100 – 900 mm |
| Web Thickness (tw) | 5 – 21 mm (depending on size) |
| Flange Thickness (tf) | 7 – 28 mm |
| Length | 6m, 9m, 12m (customizable up to 18m) |
| Yield Strength | ≥ 250 MPa (A36) / ≥ 235 MPa (SS400) |
| Tensile Strength | 400 – 550 MPa |
Note: The above values are typical. Specific Mill Test Report data will be provided upon shipment. Custom sizes and grades are available upon request.
Applications and Customer Benefits
- Building Structures: Ideal for steel frames, columns, and beams in commercial and industrial buildings.
- Bridge Construction: High load capacity and fatigue resistance make it suitable for bridge girders.
- Infrastructure Projects: Used in tunnels, platforms, and heavy machinery supports.
- Shipbuilding & Offshore: When specified with higher grades, it can be used for ship hulls and offshore platforms.
- Benefit: Reduced fabrication time due to straightness and consistent dimensions; lower total cost of ownership.
At Hemaokang Steel, we understand the importance of reliable supply. With a team of 51–100 skilled employees and a sales network covering North America, South America, Europe, Southeast Asia, Africa, Oceania, the Middle East, and Asia, we ensure timely delivery and professional after-sales support. Our ISO9001 certified quality management system guarantees that every H-beam you receive meets the highest standards. We have served clients in diverse markets, consistently earning their trust through product consistency and responsive service.
We invite you to experience the Hemaokang Steel difference. Send us your inquiry with your required size, grade, and quantity – we will provide a competitive quotation with a complete Mill Test Report. Partner with a company that values quality, transparency, and customer satisfaction.
Frequently Asked Questions (FAQ)
-
Q: What is the difference between ASTM A36 and JIS G3101 SS400?
A: Both are carbon steel structural grades with similar yield strength (250 MPa vs 235 MPa). A36 is more common in North America, while SS400 is widely used in Asia. We can supply either standard per your requirement. -
Q: Will the Mill Test Report be provided for each shipment?
A: Yes, a Mill Test Report (MTR) is included with every batch, detailing chemical composition, mechanical properties, and dimensional inspection results. Additional copies are available upon request. -
Q: Can you supply cut-to-length or custom sizes?
A: Absolutely. We offer custom lengths within 6m–18m, and we can also cut to specific lengths (e.g., 6.5m) at your request. Please specify your exact dimensions. -
Q: What surface treatments are available?
A: Standard surface is bare mill finish. We also offer painting (primer or color), hot-dip galvanizing, or oiling for rust protection. Please indicate your preference. -
Q: What is the minimum order quantity (MOQ)?
A: For standard sizes, MOQ is typically 25 metric tons. For non-standard sizes or special grades, the MOQ may be higher. Contact us for details. -
Q: How long does delivery take?
A: Standard production takes 15–20 working days after order confirmation, depending on quantity. Shipping time varies by destination (sea freight usually 15–40 days). -
Q: Do you have certifications beyond ISO9001?
A: We hold ISO9001 certification. For specific project requirements, we can arrange third-party inspection (e.g., SGS, BV) at an additional cost. -
Q: Can I get a sample before placing a bulk order?
A: Yes, sample orders are welcome. However, sample freight and handling fees apply. Please contact our sales team for sample availability.
