Home > Electrical & Electronics > Telecommunication & Broadcasting > Satellite > Ku-Band LNA 10.7-14.5GHz
Ku-Band LNA 10.7-14.5GHz
US$ 2000
1 - 9 Combo
US$ 1500
10 - 99 Combo
US$ 1300
≥100 Combo
Key Specifications
Get Latest Price
Location:
Shenzhen, Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Satellite Matrix Switch,Huashi,GARDINERUS$ 30000MOQ: 1 Combo -
Satellite Matrix Switch,GARDINER,Huashi,SwitchUS$ 9999MOQ: 1 Set
-
Satellite Power Amplifier,Satellite Power Amplifier,PA,GARDINER,HuashiUS$ 600MOQ: 1 Combo
-
Satellite Power Amplifier,Satellite Power Amplifier,PA,GARDINER,HuashiUS$ 600MOQ: 1 Combo
-
Satellite Power Amplifier,GARDINER,Huashi,LNBUS$ 1000MOQ: 1 Combo
Parameter |
Specification |
|---|---|
Frequency range |
10.7-14.5 GHz |
Gain |
50dB min., 60dB typ., 65dB max. |
Gain Flatness |
±2.5 dB max., full band |
VSWR |
Input 3.0:1 max. |
Noise Figure |
80K max. |
Output P1 dB |
5dBm min. |
Connecters |
Input WR 75 Cover Flange |
Power requirements |
DC 3-core aviation connector 12V~24V/260mA |
Operating Temperatures |
-30°C to +60°C |
