Help CenterGasoline Engine 168F-1 163cc, 3.8kW/3600rpm, Horizontal Shaft
Product Spotlights
Related Products
-
Belt-Driven Gasoline Sprayer 168F-22A, 25-49cc Pump, 15-25L/MinUS$ 20 - 80MOQ: 1 Combo -
Portable Gasoline Generator 1500W 110-230V, 154F Engine, Aluminum CoilUS$ 20 - 80MOQ: 1 Combo
-
Inverter ARC Welder ZX7-228 220V, 20-100A, IGBT Portable Stick WelderUS$ 20 - 80MOQ: 1 Combo
-
Oil-Free Silent Air Compressor 1200W-100L, 225L/min, 4-Bar, 2800rpmUS$ 20 - 80MOQ: 1 Combo
-
Industrial Belt-Drive Air Compressor 1500W 180L, 2.0m³/min 8barUS$ 20 - 80MOQ: 1 Combo
Product Overview The 168F-1 Gasoline Engine is a versatile single-cylinder OHV power unit rated at 3.8kW (5HP) at 3600rpm. With a 163cc displacement, the engine delivers strong torque for driving water pumps, generators, go-karts, tillers, and a wide range of small machinery. Its compact horizontal-shaft layout makes it ideal for direct-coupling to pumps and belt-driven equipment.
Engine Design The overhead valve configuration improves combustion efficiency, increases torque output, and reduces fuel consumption compared to side-valve designs. A cast iron cylinder liner and forged steel crankshaft deliver long service life under continuous duty. The 14mm spline output shaft can be customized to fit specific equipment requirements.
Fuel and Cooling A 1.5L fuel tank provides 2-3 hours of runtime at typical load. Forced air cooling via a flywheel-mounted fan keeps cylinder temperature in safe range during summer operation. The recoil starter uses a low-effort compression-release system for easy starting even in cold weather.
Typical Applications • Water pump drive (agricultural irrigation, drainage) • Generator drive (portable gensets) • Go-kart and small vehicle propulsion • Tiller and cultivator power • Construction equipment (concrete mixer, vibrator) • General small machinery drive
Parameters Table:
| Parameter | Value |
|---|---|
| Item No. | L183216 |
| Model | SD-168F-1 |
| Displacement | 163cc |
| Max Power | 3.8kW/3600rpm |
| Cooling | Forced Air-Cooled (Air-Cooled) |
| Packing | Plastic + Carton |
| Qty/CTN | 1/1 |
