Experience superior performance with our Inconel 800 Steel Plate – a high-temperature nickel-iron-chromium alloy designed for exceptional oxidation resistance and strength in harsh environments. As a leading supplier from Zhongzheng Stainless Steel Co., Ltd., we offer technical support, free samples, and standard export packaging to ensure your project runs smoothly. Our plate is ideal for industrial applications requiring both heat resistance and corrosion protection.
Our Inconel 800 plates are manufactured under strict quality controls, ensuring consistent chemistry and mechanical properties. The alloy offers excellent resistance to carburization, nitriding, and stress-corrosion cracking. Below you will find detailed specifications and benefits to help you make an informed decision.
| Parameter | Value |
|---|---|
| Alloy Composition | Ni: 30-35%, Cr: 19-23%, Fe: Balance, Mn ≤1.5%, Si ≤1.0% |
| Tensile Strength (MPa) | ≥ 520 (as rolled) |
| Yield Strength (MPa) | ≥ 205 |
| Elongation (%) | ≥ 30 |
| Max Service Temperature | Up to 1100°C (2012°F) |
Key Features and Benefits:
- High Temperature Resistance: Maintains structural integrity in oxidizing atmospheres up to 1100°C, reducing downtime in heat treatment furnaces.
- Corrosion & Oxidation Resistance: Chromium content forms a protective oxide layer, ideal for chemical plants and petrochemical equipment.
- Easy Fabrication: Can be welded, formed, and machined with conventional techniques; supports custom sizes and thicknesses.
- Technical Support Included: Our experienced engineers provide guidance on cutting, welding, and application-specific recommendations.
- Free Sample Available: Test the quality before bulk purchase – request a sample with standard export packaging.
- Standard Export Package: Seaworthy plywood pallets or crates ensure safe delivery worldwide.
Our Inconel 800 plate is widely used in: heat exchangers, exhaust gas components, reheater tubes, furnace rollers, and radiant tubes. The alloy’s resistance to sulfur-containing environments also makes it a preferred choice in the coal conversion and gasification industries.
Why Choose Zhongzheng Stainless Steel Co., Ltd.? With our location in Tianjin, China, we have served markets across North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, and the domestic market. Over the years, we have built a reputation for on-time delivery and consistent quality. We offer free samples so you can verify performance under your conditions. Our technical support team is available to answer questions about heat treatment, welding procedures, and material selection. Combined with standard export packaging that complies with international shipping requirements, you can order with confidence. Contact us today to request a quote or free sample – let us help you find the exact solution for your high-temperature needs.
Frequently Asked Questions
-
Q: What is the difference between Inconel 800 and Inconel 600?
A: Inconel 800 has higher chromium content (19-23%) compared to Inconel 600 (14-17%), providing better oxidation resistance at elevated temperatures. Inconel 800 also contains titanium and aluminum for improved creep strength. -
Q: Can you supply plates with cut-to-size dimensions?
A: Yes, we offer custom cutting to your required length and width. Please provide your dimension specifications during inquiry. -
Q: Are free samples subject to any limitations?
A: We provide free samples of standard sizes (typically 100x100mm or 200x200mm) for evaluation. Shipping costs may be covered depending on the order volume – please ask our sales team for details. -
Q: What surface finishes are available?
A: Common finishes include hot-rolled (black), pickled (clean), and cold-rolled (smooth). Descale and passivation treatments are also available upon request. -
Q: How do you ensure quality consistency for large orders?
A: Each batch is tested for chemical composition and mechanical properties according to ASTM B409. Mill test certificates are provided for all orders. -
Q: What is the typical lead time for standard plates?
A: For standard thicknesses and sizes, lead time is 10-15 days after order confirmation. Custom specifications may require 20-30 days. -
Q: Do you offer welding recommendations?
A: Yes, our technical support can provide recommended filler metals (e.g., ERNiCr-3) and preheat/post-weld heat treatment guidelines for Inconel 800. -
Q: Is the packaging suitable for sea freight?
A: Absolutely. Our standard export package includes plywood pallets or crates with steel strapping and protective wrapping to prevent corrosion and damage during ocean transport.
