What Is Wear Resistant Steel Plate？
Product Definition：
Wear resistant steel plate is a high-strength specialty steel plate designed for applications involving severe abrasion, impact, and wear. Through optimized alloy composition and quenching + tempering heat treatment (also known as quenching and tempering), the steel achieves high hardness (typically 360–550+ HBW) while maintaining good toughness and weldability--2. The “NM” designation stands for “Nai Mo”, the Chinese pinyin for wear resistance, with the number indicating the nominal Brinell hardness value-2-7.
Key Characteristics：
| Feature | Description |
|---|---|
| High Hardness | 360–550+ HBW (Brinell hardness) – provides excellent resistance to abrasive wear |
| High Strength | Yield strength from 840 MPa to 1300+ MPa, tensile strength up to 1600+ MPa-2-1 |
| Good Toughness | Optimized alloy design maintains impact resistance even at high hardness levels |
| Excellent Weldability | Suitable for welding using standard procedures (preheating may be required for thicker plates) |
| Good Formability | Can be cut, bent, and fabricated into various shapes |
| Cost-Effective | 3–5x longer service life than ordinary carbon steel – reduces downtime and maintenance costs |
| 100% Recyclable | Environmentally friendly with no loss of properties |
Why Choose Wear Resistant Steel？
| Factor | Wear Resistant Steel | Ordinary Carbon Steel |
|---|---|---|
| Hardness | 360–550+ HBW | 120–180 HBW |
| Wear Resistance | Excellent (3–5x longer life) | Poor |
| Service Life | Long (reduces downtime) | Short (frequent replacement) |
| Maintenance Cost | Low | High |
| Initial Cost | Higher | Low |
| Total Lifecycle Cost | Lower | Higher |
Typical Applications by Industry：
| Industry | Applications | Recommended Grades |
|---|---|---|
| Mining & Quarrying | Dump truck bodies, chute liners, crusher housings, feeder pans, bucket liners, conveyor components | NM400, NM450, NM500 |
| Cement Industry | Cyclone liners, classifier blades, raw mill separators, ductwork, silo liners, clinker chutes | NM360, NM400 |
| Steel & Metallurgy | Coke injection elbows, sinter screens, slag pots, transfer chutes | NM400, NM450 |
| Power Generation | Coal pulverizer liners, cyclone burners, coal handling chutes, ash handling systems | NM360, NM400 |
| Construction & Earthmoving | Excavator buckets, bulldozer blades, loader buckets, scraper blades | NM400, NM450, NM500 |
| Recycling & Waste | Shredder liners, compactor liners, sorting chutes | NM400, NM450 |
| Dredging | Dredge pump casings, cutter head protection, pipeline elbows | NM400, NM500 |
Key Specifications – Wear Resistant Steel Plate
| Parameter | Specification / Range | Remarks |
|---|---|---|
| Standards | GB/T 24186 (NM series), ASTM, EN, JIS | Others on request |
| NM360 | 320–400 HBW hardness, yield ≥840 MPa, tensile ≥980 MPa-2 | General wear resistance |
| NM400 | 360–440 HBW hardness, yield ≥900 MPa, tensile ≥1050 MPa-6 | Most common, versatile |
| NM450 | 420–480 HBW hardness, yield ≥1225 MPa, tensile ≥1477 MPa- | Higher wear resistance |
| NM500 | 480–530 HBW hardness, tensile ≥680 MPa-7 | High abrasion applications |
| NM550 | 525–575 HBW hardness, yield ≥1300 MPa, tensile ≥1600 MPa-1 | Extreme wear conditions |
| Thickness – NM360/400 | 3 mm – 120 mm | Custom on request |
| Thickness – NM450/500 | 6 mm – 60 mm-7 | – |
| Thickness – NM550 | 10 mm – 50 mm-1 | – |
| Width | 1000 mm – 4000 mm | Custom on request |
| Length | 2000 mm – 12000 mm | Custom cut to size |
| Delivery Condition | Quenched + Tempered (QT) | Also known as quenched and tempered |
| Density | 7.85 g/cm³ | – |
| Hardness Test | Brinell hardness (HBW) per GB/T 231 | Test after surface milling 1.0–2.5mm-2 |
| Testing | Chemical analysis, tensile, hardness, impact (Charpy), UT (optional) | Mill cert EN 10204 3.1 |
| Packaging | Steel strapped bundles, wooden pallet | Seaworthy, ISPM 15 |
