Worm Shaft Bevel Pinion Shaft Set With Mill Test Report & 12 Months Warranty Support
Product Spotlights
Premium Worm Shaft Bevel Pinion Shaft Set with Mill Test Report for full material traceability and 12-month warranty. High-precision machining, alloy steel construction (HRC 58-62), customizable dimensions. Ideal for gearboxes and mining equipment. Factory-direct from ISO-certified manufacturer with global shipping.
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Application:
Other, Industrial Gearboxes
Certification:
Other, Mill Test Report Included
Material:
Alloy Steel (20CrMnTi, 40Cr, 42CrMo)
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Precision Gear Shaft Machining | Custom Gear Shaft Manufacturer - Henan Sankuang MachineryNegotiableMOQ: 1 Set -
Precision Gear Shaft for Heavy Duty Applications - 42CrMo Alloy SteelNegotiableMOQ: 1 Unit
-
Custom Gear Shaft Solutions - Engineering Support AvailableNegotiableMOQ: 1 Unit
-
Heavy Duty Transmission Gear Shaft - 1000Nm Torque CapacityNegotiableMOQ: 1 Unit
-
Hardened Gear Shaft With 0.005mm Tolerance - CNC MachinedNegotiableMOQ: 1 Unit
Application
Other, Industrial Gearboxes
Certification
Other, Mill Test Report Included
Material
Alloy Steel (20CrMnTi, 40Cr, 42CrMo)
Hardness
HRC 58-62
Precision Grade
DIN 6-8
Shaft Diameter
Customizable (20-200 mm)
Warranty
12 Months
Surface Treatment
Gear Grinding, Shot Blasting
Welcome to Henan San Kuang Machinery Technology Co., Ltd. – your reliable partner for high-quality power transmission components. Our Worm Shaft Bevel Pinion Shaft Set is engineered for demanding industrial applications, combining precision machining with rigorous quality control. Every set comes with a comprehensive Mill Test Report and is backed by a 12-month warranty, ensuring you receive a product that meets strict mechanical standards. With over a decade of manufacturing experience and a factory spanning 10,000–30,000 square meters, we deliver shafts that offer excellent wear resistance, long service life, and seamless integration into your gearbox or drive system.
Product Features & Technical Specifications
- Material Excellence: Manufactured from premium alloy steels such as 20CrMnTi or 40Cr, carburized and quenched to achieve a surface hardness of HRC 58-62, providing exceptional durability against fatigue and impact.
- High-Precision Machining: Our shafts are produced with advanced CNC gear hobbing and grinding equipment, ensuring precise tooth profiles and concentricity. Tolerances comply with DIN grade 6–8, guaranteeing smooth and quiet operation.
- Complete Set: The set includes both the worm shaft and the bevel pinion shaft, perfectly matched in module and pressure angle for optimal meshing and torque transmission.
- Mill Test Report Included: Each shipment is accompanied by a detailed Mill Test Report that documents material composition, mechanical properties, and heat treatment results, providing full traceability.
- 12-Month Warranty: We stand behind our products with a full 12-month warranty against manufacturing defects, giving you peace of mind.
- Customizable Dimensions: Available in various sizes (shaft diameter from 20 mm to 200 mm) and configurations to meet your specific requirements. Contact us for non-standard designs.
- Surface Finish Options: As standard, shafts are gear-ground and shot-blasted to reduce stress concentration. Additional treatments like phosphating or DLC coating are available upon request.
| Parameter | Value | Notes |
|---|---|---|
| Material | 20CrMnTi / 40Cr / 42CrMo | Carburized & quenched |
| Surface Hardness | HRC 58–62 | Effective case depth 0.8–1.2 mm |
| Precision Grade | DIN 6–8 | Custom higher grades available |
| Shaft Diameter Range | 20 – 200 mm | Other sizes upon request |
| Module Range | 1 – 10 | Worm and pinion matched |
| Lead Angle | Customizable | Typically 3°–30° |
| Warranty | 12 months | Against manufacturing defects |
| Report | Mill Test Report | Material & heat treatment data |
Why Choose Our Worm Shaft Bevel Pinion Shaft Set?
- Reduced Downtime: Rigorous quality control ensures consistent performance, minimizing unexpected failures in your production line.
- Cost-Effective: Direct from factory pricing with no middlemen – you get competitive costs without compromising on quality.
- Global Logistics: Shipped from major Chinese ports (Shanghai, Lianyungang, Qingdao, Tianjin) with reliable freight options to worldwide destinations.
- Technical Support: Our experienced engineering team provides after-sales support and customization advice.
With an annual export value of US$2.5 million to US$5 million, we serve clients across North America, South America, Europe, Africa, and Southeast Asia. Our factory is certified with multiple management standards (including ISO9001, ISO14000, OHSAS18001, and more), reflecting our commitment to quality, environment, and safety. Every Worm Shaft Bevel Pinion Shaft Set is delivered with a Mill Test Report and 12 months warranty support – a promise of reliability that our customers trust. Contact us today to discuss your requirements or request a quotation. We are ready to support your projects with precision-engineered shaft sets.
Frequently Asked Questions
1. What is a Mill Test Report and why is it important?
The Mill Test Report (MTR) provides certified data on the chemical composition, mechanical properties, and heat treatment results of the shaft material. It ensures traceability and confirms that the product meets specified standards, giving you confidence in its performance.
The Mill Test Report (MTR) provides certified data on the chemical composition, mechanical properties, and heat treatment results of the shaft material. It ensures traceability and confirms that the product meets specified standards, giving you confidence in its performance.
2. Does the 12-month warranty cover all types of damage?
The warranty covers manufacturing defects such as material faults, machining errors, or improper heat treatment. It does not cover damage caused by misuse, improper installation, or normal wear. Please review our warranty terms for details.
The warranty covers manufacturing defects such as material faults, machining errors, or improper heat treatment. It does not cover damage caused by misuse, improper installation, or normal wear. Please review our warranty terms for details.
3. Can I customize the shaft dimensions and tooth profile?
Yes, we offer full customization. Provide your drawings or specifications, and our team will manufacture the set according to your requirements. Minimum order quantities may apply for non-standard designs.
Yes, we offer full customization. Provide your drawings or specifications, and our team will manufacture the set according to your requirements. Minimum order quantities may apply for non-standard designs.
4. What materials are used for the worm shaft and bevel pinion?
Common materials include 20CrMnTi and 40Cr alloy steel. For high-torque or corrosive environments, we can also use 42CrMo or stainless steel. Consult with our engineers for the best material choice.
Common materials include 20CrMnTi and 40Cr alloy steel. For high-torque or corrosive environments, we can also use 42CrMo or stainless steel. Consult with our engineers for the best material choice.
5. How can I verify the quality before shipment?
We provide photographs, videos, and the Mill Test Report before shipment. Third-party inspection (e.g., SGS, BV) is also available upon request at an additional cost.
We provide photographs, videos, and the Mill Test Report before shipment. Third-party inspection (e.g., SGS, BV) is also available upon request at an additional cost.
6. What is the typical lead time for production?
Standard sizes: 15-25 working days. Custom orders: 25-40 working days, depending on complexity and quantity. Urgent orders can be expedited.
Standard sizes: 15-25 working days. Custom orders: 25-40 working days, depending on complexity and quantity. Urgent orders can be expedited.
7. Do you offer samples for testing?
Yes, we can provide samples. Please contact us with your requirements. Sample costs are negotiable and can be refunded for bulk orders.
Yes, we can provide samples. Please contact us with your requirements. Sample costs are negotiable and can be refunded for bulk orders.
8. How is the packaging to prevent damage during transport?
Each shaft set is individually wrapped with oil-proof paper, foam-protected, and packed in strong wooden crates suitable for sea or air freight. Custom packaging is available on request.
Each shaft set is individually wrapped with oil-proof paper, foam-protected, and packed in strong wooden crates suitable for sea or air freight. Custom packaging is available on request.
