Welcome to Henan San Kuang Machinery Technology Co., Ltd. – your reliable partner for high-quality power transmission components. Our Factory Direct Spiral Bevel Gear with 1 Year Warranty and Mill Test Report is engineered to deliver exceptional performance in demanding industrial applications. Since 2014, we have been serving global clients across North America, Europe, Asia, and more, with a factory spanning 10,000-30,000 square meters and a dedicated team of 51-100 professionals. Each gear is manufactured under strict quality control, backed by comprehensive certifications including ISO9001, ISO14001, and OHSAS18001, ensuring you receive a product that meets international standards.
Our spiral bevel gears are designed for smooth and efficient power transmission, with curved teeth that reduce noise and vibration while handling high torque loads. The factory-direct model eliminates middlemen, giving you competitive pricing without compromising on quality. Every gear comes with a 1-year warranty and a Mill Test Report detailing chemical composition and mechanical properties, giving you full traceability and confidence in your purchase.
Key Features & Benefits
- High Strength Alloy Steel: Made from premium 20CrMnTi or equivalent, carburized and hardened to HRC 58-62 for extended service life.
- Precision Grinding: Teeth are ground to DIN 6-7 or AGMA 9-10 accuracy, ensuring quiet operation and minimal backlash.
- Customizable Dimensions: Module, number of teeth, spiral angle, and bore size can be tailored to your specific application.
- Heat Treatment Included: Carburizing, quenching, and tempering are standard to achieve optimal surface hardness and core toughness.
- 100% Inspection: Each gear undergoes rigorous dimensional and hardness testing before shipment.
- Mill Test Report Provided: Chemical and mechanical test data are included with every order for quality assurance.
- 1-Year Warranty: Coverage against manufacturing defects – we stand behind our products.
- Factory Direct Pricing: Save up to 30% compared to distributor prices while receiving the same high quality.
Technical Specifications (Typical)
| Parameter | Standard Range |
| Module | 2 – 20 mm (customizable) |
| Number of Teeth | 10 – 150 |
| Pressure Angle | 20° (standard) |
| Spiral Angle | 25° – 35° |
| Hardness (Case) | HRC 58 – 62 |
| Core Hardness | HRC 30 – 40 |
| Precision Grade | DIN 6 – 7 / AGMA 9 – 10 |
| Maximum Outer Diameter | Up to 800 mm (customizable) |
Applications
- Industrial gearboxes for mining, cement, and steel mills
- Automotive differentials and drive axles
- Heavy machinery like excavators and cranes
- Marine propulsion systems
- Agricultural equipment and tractors
- Custom power transmission solutions for OEMs
Why Choose Henan San Kuang?
With an annual export value of US$2.5–5 million and a modern factory of 10,000–30,000 square meters, we have the capacity to handle large orders with consistent quality. Our products are certified under ISO9001, ISO14001, OHSAS18001, and other international standards (full list available upon request). We ship from major Chinese ports including Shanghai, Qingdao, and Tianjin, ensuring fast and reliable logistics to markets worldwide. Every order includes a Mill Test Report for full transparency, and our 1-year warranty gives you peace of mind. Contact us today for a quotation or to discuss your custom requirements – we are ready to support your business with top-tier spiral bevel gears.
Frequently Asked Questions (FAQ)
-
Q: What is a Mill Test Report and why is it important?
A: A Mill Test Report (MTR) documents the chemical composition and mechanical properties of the material used. It provides traceability and verifies that the gear meets specified strength and durability standards. -
Q: Can you customize the gear dimensions?
A: Yes, we offer full customization for module, number of teeth, spiral angle, bore size, and overall geometry. Please provide your drawing or specifications for a custom quote. -
Q: How long does the warranty cover?
A: We provide a 1-year warranty against manufacturing defects. This covers material and workmanship issues under normal operating conditions. -
Q: What materials are used for these gears?
A: Standard material is 20CrMnTi alloy steel, carburized and quenched. Other materials like 40Cr or stainless steel are available upon request. -
Q: What is the typical lead time?
A: For standard sizes, lead time is 15–25 days. Custom orders may take 25–40 days depending on complexity. -
Q: Do you provide samples for testing?
A: Yes, samples are available. The sample cost depends on the size, and we can deduct it from the bulk order. -
Q: What certifications does your company hold?
A: We are certified under ISO9001, ISO14001, OHSAS18001, and more. A full list of certifications is available upon request. -
Q: How do you ensure quality control?
A: Each gear undergoes 100% inspection including dimensional check, hardness test, and running noise test. The Mill Test Report is provided with every shipment.
