Rossonix Co., Limited is proud to offer the Allen-Bradley 2711-K10G1 (2711K10G1), a high-performance PanelView 1000 Grayscale HMI designed for demanding industrial environments. Since 2011, we have supplied automation components to global markets, with an annual export value of US$5-10 Million and a client base spanning North America, Europe, Asia, and Oceania. Our ISO9001-certified quality management ensures every product meets rigorous standards. This HMI combines a grayscale display, tactile keypad, and dual-communication ports (RIO & RS232 Printer) to deliver reliable operator interface for PLC systems where cost-effective visualization is essential.
Key Features & Benefits
Grayscale Display (PV1000): Clear monochrome graphics with 256×128 pixel resolution, ideal for text and simple graphics in brightly lit factory floors.
Integrated Keypad: 32 function keys, numeric keypad, and navigation buttons provide robust input without dependence on touchscreens—suitable for gloved hands or harsh conditions.
Remote I/O (RIO) Communication: Direct connection to Allen-Bradley PLC-5, SLC 500, or ControlLogix via RIO network for high-speed data exchange.
RS232 Printer Port: Enables local printing of alarm logs, reports, and screen dumps—perfect for quality control or batch record keeping.
Durable Construction: NEMA 4X/12 rated front panel, resistant to water, dust, and oil splashes.
Plug-and-Play Replacement: Direct swap for existing 2711-K10G1 units, minimizing downtime.
Technical Specifications
| Parameter | Value |
|---|---|
| Display Type | Grayscale STN LCD (monochrome) |
| Resolution | 256 x 128 pixels |
| Backlight | CFL (replaceable) |
| Input Voltage | 24V DC (nominal), 18-30V DC range |
| Communication Ports | 1 x RIO (A/B), 1 x RS232 (DB9 printer), 1 x DH+ (optional) |
| Memory | Application memory: 512KB (expandable) |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Dimensions (H×W×D) | Approx. 260 x 320 x 90 mm |
| Weight | ~2.1 kg |
Why Choose Rossonix for Your 2711-K10G1?
With 11-50 dedicated professionals, we operate from Shenzhen, China, and maintain overseas offices to serve customers quickly. Our ISO9001 & ISO9000 certified processes ensure that every 2711-K10G1 unit is tested before shipment. In the past year alone, we have exported over 2,500 units of Allen-Bradley HMI products to 30+ countries. Our main markets include North America, South America, Eastern Europe, and Mid East. We offer free technical support for configuration and integration, and our inventory allows same-day dispatch for urgent orders. Choose Rossonix for competitive pricing, genuine products, and reliable after-sales service—your trusted partner in industrial automation.
Frequently Asked Questions (FAQ)
Q: Is this unit compatible with ControlLogix via RIO?
A: Yes, the 2711-K10G1 supports Remote I/O (RIO) protocol, enabling connection to ControlLogix, PLC-5, and SLC 500 systems with a RIO scanner module.Q: Can I use this HMI as a direct replacement for my existing 2711-PV1000?
A: Absolutely. The 2711-K10G1 is a direct form-fit-function replacement for earlier PanelView 1000 grayscale keypad models. You can reuse the same panel cutout and wiring.Q: Does the RS232 port support any standard printer?
A: It supports RS232 serial printers using PCL or Epson ESC/P protocols. We recommend configuring the baud rate and parity in PanelBuilder32 software.Q: What software is needed to program this HMI?
A: This unit is programmed using Rockwell Software's PanelBuilder32 (version 3.82 or later). Application files have .pba extension.Q: Is the backlight replaceable?
A: Yes, the CFL backlight can be replaced separately. We can supply replacement backlight kits upon request.Q: Does the unit come with a power supply?
A: No, power supply is not included. The HMI requires a 24V DC power source (typical 1.5A). We recommend an Allen-Bradley 2711-NC or equivalent.Q: What is the warranty period?
A: Rossonix offers a 12-month warranty from the date of shipment against manufacturing defects. Extended warranty options are available.Q: Can I use this HMI with a touchscreen overlay?
A: The 2711-K10G1 is a keypad-only unit; it does not have touch functionality. For touch version, please consider the 2711-T10 series.
