Help CenterHigh Efficiency Salt Separation Equipment 10m³/h Flow Rate 316L Stainless Steel
Product Spotlights
Related Products
-
Automatic Salt Separation Equipment 220V 50Hz 500kg/h Capacity Standard CompliantUS$ 7400 - 539000MOQ: 1 Combo -
Salt Separation Equipment IP65 Waterproof Housing 304 Stainless Steel for Saltwater TreatmentUS$ 7400 - 539000MOQ: 1 Combo
-
Industrial Salt Separation Equipment 380V Three Phase 1000kg/h ThroughputUS$ 7400 - 539000MOQ: 1 Combo
-
Salt Separation Equipment for Wastewater Treatment Zero Liquid Discharge TechnologyUS$ 7400 - 539000MOQ: 1 Combo
-
Automatic Salt Separation Machine, 5kW Motor, Processing Capacity 500kg/h, ISO9001 CompliantUS$ 1210 - 52800MOQ: 1 Combo
Qingdao Conqinphi Environmental Technology Group Co., Ltd., established in 2015 with a factory spanning 10,000–30,000 square meters and an annual export value exceeding US$10 million, introduces our High Efficiency Salt Separation Equipment with a 10m³/h flow rate and premium 316L stainless steel construction. This system is engineered to deliver outstanding salt recovery and brine concentration performance for demanding industrial applications, combining advanced separation technology with robust corrosion resistance. Our team of 201–300 skilled professionals ensures every unit meets rigorous quality standards, backed by certifications including ISO9001, ISO14000, and OHSAS18001.
Key Features & Technical Specifications
- High-Efficiency Salt Separation: Utilizes advanced membrane or thermal separation technology to achieve up to 98% salt removal efficiency, reducing waste volume and enabling salt reuse.
- 316L Stainless Steel Construction: Offers exceptional resistance to chloride-induced stress corrosion cracking, ensuring long service life even in aggressive saline environments.
- 10 m³/h Flow Rate Capacity: Designed for medium-scale operations, perfect for chemical plants, food processing, and desalination pre-treatment.
- Energy-Efficient Operation: Incorporates low-energy pumps and optimized heat recovery systems to minimize operational costs.
- Compact & Modular Design: Skid-mounted for easy installation and maintenance, with customizable configurations to fit site-specific requirements.
- Advanced Control System: PLC-based automation with touchscreen interface allows real-time monitoring and remote control (optional SCADA integration).
- Automatic Cleaning & Backwash: Reduces manual intervention and extends membrane/component life.
| Parameter | Specification |
|---|---|
| Flow Rate | 10 m³/h (nominal) |
| Operating Pressure | 0.5 – 2.0 MPa (adjustable) |
| Operating Temperature | 5°C – 60°C (customizable up to 80°C) |
| Material of Construction | 316L Stainless Steel (wetted parts) |
| Salt Separation Efficiency | ≥ 95% (typical) |
| Inlet Water Quality | TDS up to 50,000 ppm (optional high TDS) |
| Power Consumption | ≤ 3.5 kWh/m³ (depending on salt concentration) |
Detailed Advantages & Customer Benefits
Our salt separation equipment is designed to help you reduce waste disposal costs by recovering valuable salt and minimizing brine discharge. The use of 316L stainless steel ensures superior durability in harsh environments, reducing maintenance frequency and downtime. The system's modular nature allows for easy scaling as your production needs grow, while the advanced PLC control simplifies operation and reduces labor requirements. Additionally, the energy-efficient design can lower your electricity bills by up to 20% compared to conventional systems.
Key benefits include:
- Environmental Compliance: Helps meet stringent discharge regulations by reducing salt content in effluent.
- Resource Recovery: Recovered salt can be reused in processes (e.g., brine for chlor-alkali industry), creating a circular economy.
- Low Operating Cost: Automatic cleaning cycles and corrosion-resistant materials extend component life and reduce replacement costs.
- Global Support: As a manufacturer with exports to North America, Europe, Southeast Asia, and more, we provide timely after-sales service and spare parts.
Trust & Reliability
With over 9 years of manufacturing experience and a dedicated R&D team, Qingdao Conqinphi has delivered hundreds of water treatment systems worldwide. Our factory is certified under ISO9001, ISO14000, OHSAS18001, HACCP, and other management systems, ensuring consistent quality. We have served clients in over 20 countries, with annual export value ranging from US$10 million to US$50 million. Our main markets include North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and Europe, reflecting our global reach and local expertise.
We invite you to contact us today for a customized solution tailored to your salt separation needs. Our team will provide technical drawings, a competitive quotation, and prompt delivery from Qingdao Port. Trust in Conqinphi for reliable, efficient, and durable salt separation equipment that adds real value to your operation.
Frequently Asked Questions (FAQ)
-
Q: What is the typical salt concentration range that this equipment can handle?
A: The standard design can handle feed water with Total Dissolved Solids (TDS) up to 50,000 ppm. For higher concentrations, we can customize the system with additional stages or specialized membranes. -
Q: Can this equipment be used for seawater desalination?
A: While primarily designed for brine concentration and salt separation, it can be integrated into a desalination pre-treatment or post-treatment process. For direct seawater desalination, we recommend our reverse osmosis series. -
Q: What is the lifespan of the 316L stainless steel components?
A: With proper maintenance and operation within recommended parameters, the 316L stainless steel parts typically last 10–15 years, even in saline environments. Regular cleaning and monitoring of pH levels help extend service life. -
Q: Do you offer installation and commissioning services?
A: Yes, we provide on-site installation supervision and commissioning support for international clients. We also offer training for your operators, either remotely or on-site, upon request. -
Q: How much space is required for the 10m³/h system?
A: The skid-mounted unit typically occupies an area of approximately 6m x 2.5m with a height of 2.5m. Additional space for ancillary equipment (pumps, tanks) is needed. We can provide a detailed layout drawing upon request. -
Q: What is the power consumption of this equipment?
A: Under typical conditions, the power consumption is ≤ 3.5 kWh per cubic meter of treated water. However, this can vary depending on feed salinity and operating pressure. Our energy recovery options can further reduce consumption. -
Q: Can I get a sample or pilot test before purchasing?
A: Absolutely. We have a pilot-scale unit available for testing with your actual water sample. You can also visit our factory in Qingdao for a live demonstration. Contact us to arrange a trial. -
Q: What certifications does this equipment have?
A: Our manufacturing facility is certified under ISO9001, ISO14000, OHSAS18001, HACCP, and other standards. Individual units can be certified to meet specific requirements (e.g., CE, ASME) at an additional cost. Please inquire for details.
