Welcome to Rossonix Co., Limited – your trusted partner for high-quality industrial automation components since 2011. With an annual export value exceeding US$5 Million and a dedicated team of 11–50 professionals, we proudly serve global markets including North America, Europe, Oceania, and beyond. Our 1746-IH16 Allen Bradley SLC500 System Input Module is a genuine, factory-tested solution designed to deliver reliable performance in demanding PLC control environments. Whether you are upgrading an existing SLC500 system or replacing a faulty unit, this module combines proven engineering with exceptional value.
The 1746-IH16 (also known as 1746IH16) is a 16-point AC input module specifically designed for the Allen Bradley SLC500 programmable logic controller family. It accepts 120VAC or 240VAC input signals, making it ideal for discrete sensing applications such as limit switches, push buttons, and proximity sensors. Each input is optically isolated for enhanced noise immunity and safety, ensuring stable operation even in electrically harsh environments. The module mounts directly into any SLC500 chassis and communicates seamlessly with the processor via the backplane.
Key Features & Technical Specifications
- 16 AC Input Points – Provides 16 independently isolated input channels for maximum flexibility.
- Wide Voltage Range – Accepts 120VAC (±15%) or 240VAC (±15%), 50/60 Hz.
- Optical Isolation – Each channel is optically isolated (1500VAC) to protect the controller from surges.
- LED Indicators – Front-panel LEDs indicate the state of each input for easy diagnostics.
- Hot-Swappable – Can be inserted or removed while the system is powered (subject to system design).
- Compact Form Factor – Occupies a single slot in the SLC500 chassis.
- Compliance – Manufactured under ISO9001:2015 quality management system by Rockwell Automation.
| Parameter | Specification |
|---|---|
| Model Number | 1746-IH16 / 1746IH16 |
| Input Voltage | 120VAC ~ 240VAC (±15%) |
| Input Frequency | 47 – 63 Hz |
| Number of Inputs | 16 points |
| Isolation Level | 1500VAC (optical) |
| ON-State Current (max) | 10 mA per input |
| OFF-State Current (max) | 1.5 mA |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C |
| Power Consumption (Internal) | Typically 5V DC @ 100 mA from backplane |
Why choose this module for your SLC500 system? The 1746-IH16 offers rock-solid input signal detection with high noise rejection, reducing false triggers and downtime. Its modular design allows quick replacement without removing wiring, thanks to the removable terminal block (RTB) – a standard feature in SLC500 I/O modules. The module is fully compatible with all SLC500 processors, including the 5/01, 5/02, 5/03, 5/04, and 5/05. Whether you are in manufacturing, water treatment, or packaging, this input module provides the dependable interface your process requires.
Customer Benefits
- Cost-Effective Upgrade – Extend the life of your legacy SLC500 system without replacing the entire chassis.
- Easy Installation – Plug-and-play with automatic backplane addressing.
- Global Support – We ship from Shenzhen, Hong Kong, and Europe, ensuring fast delivery to major industrial hubs.
- Quality Assurance – Each module is tested before shipment; we offer a 1-year warranty against defects.
At Rossonix Co., Limited, we understand that reliability and traceability are critical in industrial automation. Our company holds ISO9001 and ISO9000 certifications, reflecting our commitment to consistent quality management. With over a decade of experience in the global market, we have built a reputation for supplying authentic, high-performance automation components. Our annual export value of US$5–10 Million demonstrates the trust our customers place in us.
Ready to secure your SLC500 operation? Contact our sales team today for pricing and availability. We offer volume discounts, custom logistics solutions, and technical support to help you select the right module for your application. Your satisfaction is our priority – choose Rossonix for genuine Allen Bradley products and peace of mind.
Frequently Asked Questions
-
Q: Is the 1746-IH16 compatible with all SLC500 processors?
A: Yes, it works with any SLC500 processor (5/01 through 5/05) in a standard chassis. -
Q: What input voltage types does this module support?
A: It accepts both 120VAC and 240VAC, 50/60 Hz. It is not for DC inputs. -
Q: Can I mix AC and DC modules in the same SLC500 chassis?
A: Absolutely. The SLC500 backplane supports any combination of I/O modules within power budget limits. -
Q: Does the module include a removable terminal block?
A: Yes, standard for all SLC500 I/O modules. The RTB allows wiring changes without removing the module. -
Q: Is this a new genuine Allen Bradley product?
A: We supply new, factory-sealed units as well as tested refurbished ones. Please specify your preference when ordering. -
Q: What is the warranty period?
A: We provide a 1-year warranty against manufacturing defects. Extended warranty options are available. -
Q: How do I verify the module’s condition upon arrival?
A: Visually inspect for damage, then install and test using the front-panel LEDs. Our technical support is also available for troubleshooting. -
Q: What shipment ports do you use?
A: We primarily ship from Shenzhen and Hong Kong, with a European warehouse for faster delivery to Europe.
