Self Drilling Screws for Steel Framing Hex Head Yellow Zinc Coated C1022A Carbon Steel
Product Spotlights
High-strength C1022A carbon steel self-drilling screws with yellow zinc coating for corrosion resistance. Hex washer head enables high-torque installation without pre-drilling. Designed specifically for steel framing applications, saving installation time and ensuring secure fastening. Custom sizes and packaging available.
US$ 900 - 1050
MOQ: 1 Ton
Key Specifications
Get Latest Price
Material:
Other, C1022A Carbon Steel
Coating:
Yellow Zinc Plated
Head Type:
Hex Washer Head
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
30 days
Related Products
-
Full Sizes C1022A Carbon Steel Self Drilling Screws Yellow Zinc Hex Head for Wall CladdingUS$ 900 - 1050MOQ: 1 Ton -
Ruspert Coated Self Drilling Screws Flat Head With EPDM Washer Full Sizes for Industrial ConstructionUS$ 900 - 1050MOQ: 1 Ton
-
C1022A Carbon Steel Self Drilling Screws High Hardness Fast Drilling No Snapping Wafer Head for Metal RoofingUS$ 900 - 1050MOQ: 1 Ton
-
Self Drilling Screws No Snapping High Hardness Stainless Steel 410 Dacromet Coated Hex HeadUS$ 900 - 1050MOQ: 1 Ton
-
Fast Drilling Self Drilling Screws for Metal Roofing With EPDM Washer Stainless Steel 410US$ 900 - 1050MOQ: 1 Ton
Material
Other, C1022A Carbon Steel
Coating
Yellow Zinc Plated
Head Type
Hex Washer Head
Application
Steel Framing, Metal Construction
Thread Type
Self-Drilling Point
Surface Treatment
Yellow Zinc
Size Options
No.8 to No.14, custom lengths
Hardness
Case Hardened
Color
Yellow
Welcome to Hefei SENOTECH New Materials Co., Ltd — your trusted partner in high-performance fasteners. Our Self Drilling Screws for Steel Framing Hex Head Yellow Zinc Coated C1022A Carbon Steel are designed to deliver exceptional holding power and corrosion resistance for demanding structural applications. Engineered from premium C1022A carbon steel and finished with a bright yellow zinc coating, these screws eliminate the need for pre-drilling, significantly reducing installation time while ensuring a secure, long-lasting connection. Whether you are framing commercial buildings or assembling metal structures, our screws offer the reliability you need.
Key Features & Technical Specifications
- Material Excellence: Manufactured from C1022A carbon steel, case hardened for maximum strength and durability. This provides excellent thread rolling and drilling capability into steel up to 0.125" (3 mm) thickness.
- Hex Washer Head Design: The integrated hex washer head allows for high torque application without stripping, compatible with standard power tools and sockets. Ensures firm clamping force.
- Yellow Zinc Coating: A uniform yellow zinc plating offers superior corrosion protection, making these screws suitable for interior and protected exterior environments. Salt spray resistance up to 72 hours (test method per ASTM B117).
- Self-Drilling Point: The sharp #2 drill point (self-drilling tip) eliminates separate drilling steps, saving labor and tool costs. Ideal for steel-to-steel fastening in gauge 12 to 22 steel.
- Thread Design: Deep, sharp threads provide excellent bite and pull-out resistance. Threads extend close to the head for maximum grip in thin materials.
- Versatile Applications: Perfect for steel framing, metal roof decking, light gauge steel construction, HVAC ductwork, and general metal fabrication.
| Parameter | Available Options |
|---|---|
| Diameter | No.8 (4.2mm), No.10 (4.8mm), No.12 (5.5mm), No.14 (6.3mm) |
| Length | 3/4" (19mm) to 3" (76mm) and custom lengths upon request |
| Drive Type | Hex Socket (1/4" or 5/16") |
| Point Type | Self-Drilling #2 Point (standard) |
| Coating Thickness | 5-8 microns (yellow zinc) |
| Hardness (Core) | HRC 28-36 |
Why Choose Our Self Drilling Screws?
- Time & Cost Savings: No pre-drilling required — reduces installation time by up to 50% compared to traditional screws.
- Reliable Performance: Consistent torque, minimal cam-out, and strong clamping force ensure vibration-resistant assemblies.
- Global Reach: As a trading company based in Hefei, China, we export to North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. Our annual export value exceeds US$1 million, demonstrating our capacity and reliability.
- Flexible Customization: We offer custom lengths, special coatings (e.g., galvanized, black oxide), and packaging options to meet your project requirements.
- Quality Assurance: Each production batch undergoes rigorous testing for hardness, coating thickness, and thread accuracy. Samples available for pre-qualification.
Trusted Partner for Steel Construction
Since our establishment in 2020, Hefei SENOTECH New Materials Co., Ltd has built a strong reputation for delivering high-quality industrial fasteners to clients worldwide. Our team understands the challenges of modern construction — speed, durability, and cost efficiency. The Self Drilling Screws for Steel Framing Hex Head Yellow Zinc Coated C1022A Carbon Steel are a direct answer to those demands. With an annual export value between US$1 million and US$1.5 million and a diverse market presence across six continents, we are committed to providing consistent quality and on-time delivery. Contact us today to request samples, bulk pricing, or technical data sheets. Let our screws fasten your success.
