Help CenterEuropean Standard High Hardenability 20mncrs5 Alloy Structural Round Steel, Steel for High-precision Gears in Mechanical Manufacturing (1.7149)
Related Products
-
in Stock, 42crmo4 Round Steel Cut to Order, 42crmo4v Alloy Steel Forging Round Bars, qt Quenched and Tempered, Polished, Guaranteed Material QualityUS$ 1.46 - 1.62MOQ: 10 Kilograms -
German Standard Low-alloy Chromium-molybdenum 50crmo4 Quenched and Tempered Round Steel, American Standard Sae 4150 Steel Bar, Customizable From 16 to 600, Cutting AvailableUS$ 1.46 - 1.62MOQ: 10 Kilograms
-
35crni3wa Alloy Round Steel for Mine Drilling Equipment, Highly Wear-resistant 35crni3mov Round Bar, Sufficient Steel IngotsUS$ 1.46 - 1.62MOQ: 10 Kilograms
-
Jingcheng Yangming American Standard A182f5 Round Steel, Martensitic Heat-resistant f5 Alloy Steel Bar, Forgings, Non-standard Customization, 80 CuttingUS$ 1.46 - 1.62MOQ: 10 Kilograms
-
Boiler Steel A182 F92 Round Steel, A182 F91 Alloy Steel Bars for Boiler Hangers and Valves, Cut, High - Quality From Large ManufacturersUS$ 1.46 - 1.62MOQ: 10 Kilograms
Industry Pain Points and Solutions
In the field of mechanical manufacturing, especially in high-precision gear processing, the selection of materials directly determines the service life and transmission efficiency of parts. Traditional gear steels often face core pain points such as insufficient hardenability leading to low core hardness, uneven carburized layer, large machining deformation, and poor cutting performance. These defects can cause problems such as early fatigue fracture, increased noise, and decreased meshing accuracy of gears during service, seriously affecting the reliability and safety of the main equipment. Liaocheng Jincheng Yangming Special Steel Co., Ltd. has been deeply involved in the special steel field for many years and has a profound understanding of this industry problem. Our European high-hardenability 20MnCrS5 alloy structural round steel (material number 1.7149) is a special gear steel developed specifically for the above pain points. This steel grade optimizes the sulfur content and hardenability control on the basis of traditional 20MnCr5. Through precise alloy ratio and strict heat treatment process, it significantly improves the hardening uniformity and cutting workability of the material, while maintaining excellent carburizing performance, effectively solving the problems of insufficient core hardness and deformation control of large-module gears. Relying on its own technical accumulation in the smelting and processing of special steel, the company ensures that each batch of round steel meets the EN 10084 standard, providing stable and reliable raw materials for high-precision gear manufacturing.
Working Mechanism and Product Features
20MnCrS5 belongs to low-alloy carburizing steel. Its working mechanism mainly obtains a high-carbon martensite structure through surface carburizing, endowing the gear surface with high hardness and wear resistance, while the core maintains a low-carbon martensite or bainite structure, ensuring good toughness and fatigue strength. The addition of alloying elements chromium and manganese improves the hardenability of the steel, enabling large-section parts to obtain a uniform hardened layer. The addition of sulfur element (0.020 - 0.040%) improves the cutting performance, which is especially suitable for large-scale precision machining. The following are the key technical features of this product:
- High Hardenability: Through fine control of Mn and Cr content and hardenability bandwidth, it ensures that the core hardness of sections below φ80mm after oil quenching is ≥30HRC, meeting the strength requirements of high-load gears.
- Stable Carburizing Performance: The grain size is finer than grade 7, the carburized layer depth is uniform, and the carbon gradient is gentle, effectively reducing quenching deformation.
- Excellent Machinability: The sulfur-containing free-cutting design extends the service life of turning, hobbing, and gear shaping tools by more than 30%, reducing processing costs.
- High Dimensional Accuracy: The diameter tolerance of the round steel is controlled within ±0.5mm, and the ovality is ≤1% of the diameter, reducing the subsequent machining allowance.
- Purity Assurance: Using the ladle refining + vacuum degassing process, the non-metallic inclusion level is controlled at fine series ≤1.5 grade and coarse series ≤1.0 grade, eliminating internal crack sources.
| Typical chemical composition (wt%) | C: 0.17-0.22 | Si: ≤0.40 | Mn: 1.10-1.40 |
| P: ≤0.025 | S: 0.020-0.040 | Cr: 1.00-1.30 | Ni: ≤0.30 |
| Mechanical properties (quenching + low-temperature tempering) | Tensile strength: ≥1200 MPa | Yield strength: ≥900 MPa | Elongation: ≥9% |
| Impact energy (-20℃): ≥27 J | Surface hardness: 58-62 HRC | Core hardness: 30-42 HRC | Carburizing depth: 0.8-1.2mm |
Advantages in industry applications
This round steel is particularly suitable for occasions with strict requirements on dimensional accuracy and fatigue life, such as automotive transmission gears, engineering machinery transmission gears, and precision machine tool spindle gears. Compared with ordinary 20CrMnTi, it has higher hardenability and is suitable for parts with larger cross-sections. Compared with 40Cr, it has better carburizing performance and better surface hardness uniformity. In the gear manufacturing process, using 20MnCrS5 can simplify the heat treatment process, reduce the deformation risk of direct quenching after carburizing, and improve the product qualification rate.
Trust endorsement and company advantages
Liaocheng Jincheng Yangming Special Steel Co., Ltd. always adheres to the business philosophy of "seeking truth from facts and honesty as the foundation" and has accumulated a good reputation in the special steel industry. The company has a perfect quality control system. Each batch of round steel undergoes chemical composition analysis, mechanical property testing, ultrasonic flaw detection, and dimensional inspection before leaving the factory to ensure that the indicators meet the EN 10084 standard. The company has long served multiple fields such as petroleum, chemical industry, shipbuilding, and machinery manufacturing. Customer feedback shows that the fatigue life of gears produced using our company's 20MnCrS5 round steel is increased by more than 15% compared with similar products, and the scrap rate is reduced by 20%. In addition, the company can provide value-added services such as fixed-length cutting, annealing or normalizing treatment, and chamfering and deburring according to customer needs, reducing the customer's secondary processing procedures. We are well aware of the crucial role of material selection in the success or failure of products. Therefore, we recommend that you communicate with our technical team about the specific gear operating condition parameters (such as module, load, speed, etc.), and we will provide you with matching material specifications and heat treatment suggestions to ensure the optimal performance of the final product. If you need samples or technical data, please feel free to contact Liaocheng Jincheng Yangming Special Steel Co., Ltd. Let's work together to improve the quality of your gear manufacturing.
FAQ (Frequently Asked Questions)
Q: What are the advantages of 20MnCrS5 compared with 20CrMnTi in high-precision gear applications?
A: 20MnCrS5 has higher hardenability and is especially suitable for gears with a diameter of over 60mm. After oil quenching, the core hardness can reach over 35HRC, while the core hardness of 20CrMnTi is usually only 25 - 30HRC. In addition, 20MnCrS5 contains sulfur, and its cutting performance is significantly better than that of 20CrMnTi. The tool life is extended by about 30%, making it more suitable for precision hobbing and shaving processes.Q: What is the hardenability band width of the round steel? Can the consistency between batches be guaranteed?
A: Our company strictly implements the EN 10084 standard, and the hardenability band width is controlled within ±2HRC at the H point. Through strict spectral analysis and end quenching tests, we ensure that the hardenability curves of round steel with the same heat number and specification are highly consistent, meeting the process stability requirements for large - batch gear production.Q: What are the supply states of the round steel? Can pre - processing be carried out according to the drawings?
A: The standard supply state is annealing or normalizing, and the hardness is ≤217HBW, which is convenient for subsequent machining. We can also provide pre - processing services such as rough turning of bright bars, cutting to length, and chamfering according to customer requirements, reducing the loss in the customer's material cutting process. Specific requirements need to be negotiated based on the provided drawings or technical requirements.Q: Is this material suitable for gear grinding after carburizing and quenching? How to control the deformation?
A: It is very suitable. The carbon gradient of the carburized layer of 20MnCrS5 is gentle, and the structure after quenching is uniform. The deformation is usually controlled within 0.05 - 0.15mm (depending on the gear shape and size). It is recommended to adopt the process of quenching after carburizing and cryogenic treatment to further reduce the retained austenite and stabilize the size. We can provide recommended heat treatment process parameters.Q: How does the fatigue performance of 20MnCrS5 compare with that of foreign materials with the same grade?
A: The chemical composition and cleanliness control of our company's products are both benchmarked against the advanced European level. The non - metallic inclusion grade is lower than 1.5 (fine series), and the fatigue limit (105 cycles) can reach over 800MPa, which is comparable to imported materials from Germany. Actual vehicle loading tests by customers show that the bench test life of transmission gears made of our company's materials exceeds 2 million times, meeting the requirements of international mainstream OEMs.Q: What are the diameter tolerance and straightness of the round steel?
A: The diameter tolerance complies with the EN 10060 standard. The common grade is ±0.5mm, and the high - grade can reach ±0.3mm. The straightness is ≤2mm/m. If there are special requirements (such as materials for precision centerless grinding), stricter tolerances can be negotiated, but the selection cost needs to be increased.Q: Can this material be used for gears after carburizing and induction hardening?
A: Yes. 20MnCrS5 has good carburizing properties, and its matrix is also suitable for induction heat treatment. However, it is necessary to avoid overheating during induction heating to prevent grain coarsening. It is recommended to use an induction process with lower power and an appropriate rate. Liaocheng Jincheng Yangming Special Steel Co., Ltd. can provide reference for induction hardening process parameters.
