Shanghai Kaiquan Pump WQ2327-672-250 Submersible Pump Impeller Wear Resistant Components
Product Spotlights
Precision-cast high-chromium alloy replacement impeller for Kaiquan WQ2327-672-250 submersible pumps. Hardness HRC 55-60, wear resistance 2-3x longer than standard iron, direct bolt-on fit. Reduces downtime and energy costs in wastewater, drainage, and slurry applications. Custom coating available for extreme abrasion. Manufactured by Jiangsu Manqi Machinery, Suzhou, China.
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Model:
WQ2327-672-250
Applicable Pump:
Kaiquan WQ series submersible pumps
Component Type:
Impeller (Wear Resistant)
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Shanghai Kaiquan KQSN500-M9/675 Split Case Pump Cast Impeller OEM Replacement ComponentNegotiableMOQ: 1 Piece -
Shanghai Kaiquan WQ2445-612-250 Submersible Pump Cast Impeller Durable Spare PartsNegotiableMOQ: 1 Piece
-
WQ2290-4112-250 Waste Water Pump Impeller Replacement Kit Fit Shanghai Kaiquan WQ Series PumpNegotiableMOQ: 1 Piece
-
200N135A Copper Alloy Pump Impeller Anti-Wear Replacement Parts of Shanghai Kaiquan Pump FittingsNegotiableMOQ: 1 Piece
-
WQ2520-1001-500T Pump Impeller for Wastewater Treatment, Cast Iron, 500mm, Solids HandlingNegotiableMOQ: 1 Piece
Model
WQ2327-672-250
Applicable Pump
Kaiquan WQ series submersible pumps
Component Type
Impeller (Wear Resistant)
Material
High-chromium wear-resistant alloy
Surface Hardness
HRC 52-60 (typical)
Color
As cast / Custom options available
Application
Wastewater treatment, drainage, industrial sewage
Craft
Precision investment casting + unique heat treatment
Customization
Available upon request
Packaging
Standard export wooden case
At Jiangsu Manqi Machinery Co., Ltd., we specialize in manufacturing high-performance replacement components for pumping systems. The Shanghai Kaiquan Pump WQ2327-672-250 Submersible Pump Impeller is a precisely engineered, wear-resistant part designed to restore and enhance the efficiency of WQ series submersible pumps used in demanding wastewater and drainage applications. Crafted from premium alloy materials, this impeller provides extended service life and dependable operation even in harsh environments containing abrasive solids. Our factory, located in Suzhou, Jiangsu, combines advanced casting techniques with rigorous quality control to deliver components that meet or exceed OEM standards.
Key Features & Technical Specifications
- Premium Wear Resistance – Made from high-chromium alloy iron with optimized carbide structure, achieving surface hardness up to HRC 60. This significantly reduces erosion from sand, debris, and other suspended solids.
- Precision Fit – Manufactured using investment casting and CNC machining to strict tolerances, ensuring perfect balance and smooth operation without vibration or excessive stress on the motor.
- Corrosion Resistance – The alloy composition provides excellent resistance to mildly acidic or alkaline wastewater, further extending the component’s lifespan.
- Heat Treated – A specialized heat treatment process (quenching + tempering) enhances toughness and prevents brittle fracture under high load or cavitation conditions.
- Direct Replacement for Kaiquan WQ2327-672-250 – Designed to match the original impeller dimensions, vane profile, and hub configuration for easy installation without modifications.
- Optional Coating – For extremely abrasive media, we can apply a ceramic-epoxy coating on the wearing surfaces (consult with our sales team for availability).
| Parameter | Value / Specification |
|---|---|
| Material | High-Cr white iron (approx. 25-30% Cr) |
| Hardness (as-cast) | HRC 52 – 58 |
| Hardness (heat treated) | HRC 55 – 60 |
| Density | approx. 7.6 g/cm³ |
| Max Operating Temperature | 80°C (continuous), 120°C intermittent |
| Applicable Pump Model | Kaiquan WQ2327-672-250 |
| Impeller Diameter (approx.) | 250 mm (as per model number indication) |
| Number of Vanes | Typically 3-4 (depending on OEM design; please verify) |
Benefits for Your Pumping System
- Reduced Downtime – The hardened material extends replacement intervals by up to 3 times compared to standard cast iron impellers in abrasive applications.
- Energy Savings – Precision balancing and smooth hydraulic design minimize frictional losses, maintaining pump efficiency and reducing power consumption.
- Lower Maintenance Costs – The robust construction reduces the risk of sudden impeller failure that could damage the mechanical seal or volute casing.
- Easy Installation – Supplied as a single monolithic casting with a precisely machined hub bore and keyway, ready for assembly with new wear rings if needed.
- Versatility – Suitable for use in civil sewage plants, mining dewatering, industrial sumps, and agricultural drainage systems containing sand or slurry.
Trust Built on Experience
Jiangsu Manqi Machinery Co., Ltd., established in 2017, operates a dedicated manufacturing facility spanning 10,000 to 30,000 square meters in Suzhou high-tech zone. We have supplied pump components to clients in Eastern Europe, Southeast Asia, Africa, and South Asia, maintaining a consistent record of quality and timely delivery. Our in-house team of engineers oversees every step from pattern making to final inspection. We ship from the Port of Shanghai via standard or expedited freight, with robust wooden crate packaging to ensure parts arrive undamaged. We encourage you to request a quote for this WQ2327-672-250 impeller or discuss your specific wear requirements – we can also produce custom impellers for other submersible pump brands. Choose durable, cost-effective replacement parts from a manufacturer that understands your operational needs.
Frequently Asked Questions
-
Q: Is this impeller a direct replacement for the Kaiquan original part?
A: Yes, it is designed to match the OEM dimensions, vane geometry, and mounting specifications for the WQ2327-672-250 model. However, we recommend comparing with your original part or providing the pump serial number for confirmation before ordering. -
Q: What material is used for this impeller?
A: We use high-chromium wear-resistant cast iron (typically 25-30% Cr), heat-treated to achieve a hardness of HRC 55-60. This material offers excellent abrasion resistance and moderate corrosion resistance for most wastewater environments. -
Q: How long does this impeller typically last in a sewage pump?
A: Service life depends on the concentration of abrasive solids, flow rate, and operating conditions. In typical municipal sewage applications, users report lifespan 2-3 times longer than normal cast iron impellers. In heavy sand-laden water, it can still last 1-2 years under normal maintenance. -
Q: Do you offer any warranty for this component?
A: We provide a standard 12-month warranty against manufacturing defects (material, casting flaws, or dimensional inaccuracy). Wear-related failures due to normal operation are not covered, but we can discuss extended warranty options for long-term contracts. -
Q: Can this impeller be used with other brands of submersible pumps?
A: It is specifically designed for Kaiquan WQ2327-672-250. However, we can supply custom-dimension impellers for other pump brands (e.g., Flygt, Grundfos, Sulzer) upon request. Please provide your pump model and shaft dimensions for a quotation. -
Q: What is the price and shipping time?
A: Price depends on quantity and current material costs. For inquiries, please contact our sales team. Typical production time is 15-25 working days after order confirmation. Stock items can ship within 7-10 days. We ship via sea from Shanghai port or via air if urgent. -
Q: Is custom coating available for extra wear resistance?
A: Yes, we offer an optional ceramic-epoxy coating that can be applied to the impeller vane surfaces and edges. This is recommended for pumps handling extremely abrasive media such as mining slurry or grit-laden water. Contact us for details. -
Q: How should I store or handle the impeller before installation?
A: Keep it in a dry environment, protected from impact. The casting surface is hard but can chip if dropped on concrete. For long-term storage, apply a light anti-rust oil to the machined surfaces (hub bore and keyway).
