Hot Sell Pet Monofilament Silk Screen Mesh for Screen Printing

Hot Sell Pet Monofilament Silk Screen Mesh for Screen Printing thumbnail-1
Hot Sell Pet Monofilament Silk Screen Mesh for Screen Printing thumbnail-2
Hot Sell Pet Monofilament Silk Screen Mesh for Screen Printing thumbnail-3
Hot Sell Pet Monofilament Silk Screen Mesh for Screen Printing thumbnail-4
Hot Sell Pet Monofilament Silk Screen Mesh for Screen Printing thumbnail-5
Hot Sell Pet Monofilament Silk Screen Mesh for Screen Printing photo-1
Hot Sell Pet Monofilament Silk Screen Mesh for Screen Printing photo-2
Hot Sell Pet Monofilament Silk Screen Mesh for Screen Printing photo-3
Hot Sell Pet Monofilament Silk Screen Mesh for Screen Printing photo-4
Hot Sell Pet Monofilament Silk Screen Mesh for Screen Printing photo-5

Product Spotlights

1. Material: 100% polyester monofilament yarn
2. Temperature for continuous operation: 120°C
3. Max temperature: 195°C
4. Mesh counts: 6T-180T (15mesh - 460mesh)
5. Width: 55", 60", 65", 127CM, 165CM, 260CM, 330CM, 365CM etc.
6. Length: 30m-80m, or standard roll length 30m, 50m, 30yards, 50yards, 60yards etc.
7. Color: White, Yellow are available
8. Characteristic :high tension,low elongation,excellent dimensional stability
9. 2meters of free sample available at request.
US$ 0.5 - 20 MOQ: 1 Roll
Key Specifications
Get Latest Price
Material:
100% Polyester
Elasticity:
Low
Weave Type:
Plain
Contact Supplier Request Quote Chat Now
Shijiazhuang Paiou Mesh Co.'ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material 100% Polyester
Elasticity Low
Weave Type Plain
Transport Package IN CARTON
Specification 6T-165T
Trademark PAYOVO
Origin CHINA

Hot Sell Pet Monofilament Silk Screen Mesh for Screen Printing

PAIOU adopts high-precision imported steel reed to ensure the consistency of screen opening and avoid inaccurate printing caused by the screen deformation during screen printing.


1. Material: 100% polyester monofilament yarn
2. Temperature for continuous operation: 120°C
3. Max temperature: 195°C
4. Mesh counts: 6T-180T (15mesh - 460mesh)
5. Width: 55", 60", 65", 127CM, 165CM, 260CM, 330CM, 365CM etc.
6. Length: 30m-80m, or standard roll length 30m, 50m, 30yards, 50yards, 60yards etc.
7. Color: White, Yellow are available
8. Characteristic :high tension,low elongation,excellent dimensional stability

9. 2meters of free sample available at request.
10. fast delivery time as we have 1000-2000meters stocks for normal standard sizes

PAIOU 100% POLYESTER SCREEN PRINTING MESH SPECIFICATIONS
MESH CODE MESH COUNT THREAD DIAMETER OPENING    OPEN AREA THICKNESS   THEORETICAL INK VOLUMEg/m²
/CM /INCH Micron μm % μm
6T-400 6 15 400 1300 65 790 560
7T-350 7 18 350 1067 55 585-598 389
8T-300 8 20 300 970 58 550-580 406
8T-350 8 20 350 950 56 575-595 395
10T-250 10 25 250 743 55 495 274
12T-140 12 30 140 686 68 277 189
12T-250 12 30 250 578 48 495 239
16T-100 16 40 100 535 72 169 126
16T-120 16 40 120 515 65 225-230 147
16T-150 16 40 150 461 58 238 139
16T-200 16 40 200 403 44 329-341 151
17-180 17 45 180 410 53 255-275 137
20T-80 20 55 80 378 68 125-140 125
20T-100 20 50 100 380 62 170 105
20T-150 20 50 150 354 50 255 126
21T-80 21 55 80 378 68 130 125
24T-100 24 60 100 301 56 170 95
24T-120 24 60 120 282 49 204 99
24T-150 24 60 150 273 42 250 100
28T-80 28 70 80 263 58 136 79
28T-100 28 70 100 244 50 170 85
28T-150 28 70 150 240 55 198 70
29T-120 29 73 120 213 41 240 102
32T-64 32 80 64 236 61 109 67
32T-80 32 80 80 221 53 136 73
32T-100 32 80 100 202 44 170 75
32T-120 32 80 120 183 36 204 74
34T-100 34 86 100 184 42 170 71
36T-80 36 70 100 202 51 148 70
36T-90 36 80 100 185 45 160 65
36T-100 36 90 100 180 41 170 60
39T-55 39 100 55 191 60 94 56
39T-64 39 100 64 183 54 109 59
39T-71 39 100 71 176 50 121 61
39T-80 39 100 80 168 45 136 62
39T-100 39 100 100 149 35 170 60
43T-55 43 110 55 176 58 98 56.8
43T-64 43 110 64 160 51 109 55
43T-80 43 110 80 145 41 136 56
47T-55 47 120 55 150 53 94 50
47T-64 47 120 64 143 40 90 48
48T-70 48 125 70 135 42 121 51
53T-45 53 135 45 148 52 100 47
53T-48 53 135 48 140 55 90 49.5
53T-55 53 135 55 127 48 94 45
54T-64 54 137 64 118 42 109 45
54T-71 54 137 71 112 37 115 45
59T-45 59 150 45 124 45 85 29
59T-48 59 150 48 121 51 85 43.4
59T-55 59 150 55 114 48 108 49.7
59T-64 59 150 64 105 39 119 48.4
62T-48 62 160 48 115 48 80 41
62T-55 62 160 55 103 41 94 38
62T-64 62 160 64 95 34 109 37
64T-55 64 162 55 96 39 94 36
64T-64 64 162 64 88 32 109 35
68T-55 68 173 55 92 39 102 39.8
72T-48 72 180 48 91 43 89 38.3
72T-55 72 180 55 84 37 100 37
77T-48 77 195 48 82 40 89 35.6
77T-55 77 195 55 75 33 108 35.6
80T-48 80 200 48 77 38 89 33.8
90T-40 90 230 40 68 38 68 26
90T-48 90 230 48 62 32 92 29.4
100T-40 100 255 40 60 36 72 25.9
110T-40 110 280 40 51 31 79 24.5
120T-31 120 305 31 52 39 53 20.7
120T-34 120 305 34 46 31 50 18.4
120T-40 120 305 40 43 27 72 19.4
130T-34 130 330 34 36 26 58 15
140T-31 140 350 31 42 34 61 20.7
140T-34 140 350 34 38 28 67 18.8
150T-31 150 380 31 37 30 60 18
150T-34 150 380 34 33 28 62 14.9
165T-31 165 420 30 30 25 56 14
