0.5-80t/h Forced Circulation Skid-Mounted MVR Evaporator for Horizontal/Counterflow Wastewater Treatment
Product Spotlights
Energy-saving MVR evaporation (60-80% less consumption than multi-effect); forced circulation design prevents scaling; skid-mounted for fast installation; wide capacity range 0.5-80 t/h; automated PLC control; customizable materials; suitable for high-salinity & fouling wastewater; proven reliability from ISO-certified manufacturer with global export experience.
US$ 14600 - 812000
MOQ: 2 Combos
Key Specifications
Get Latest Price
Application:
Other, Wastewater Treatment
Capacity Range:
0.5–80 t/h
Circulation Type:
Forced Circulation
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
50 days
Related Products
-
0.5-80t/h Falling Film Vacuum Counterflow MVR Evaporator for Petrochemical & Acidified Oil ProcessingUS$ 14600 - 812000MOQ: 2 Combos -
Horizontal and Counterflow Tube-Type Skid-Mounted MVR Evaporator for Efficient EvaporationUS$ 14600 - 812000MOQ: 2 Combos
-
Fruit Juice Concentrate MVR Evaporation Crystallizer With Concentration TechnologyUS$ 4180 - 53200MOQ: 2 Combos
-
Stainless Steel 2205/316L/304/316 MVR Evaporation Concentration Crystallizer Reliable OperationUS$ 4180 - 53200MOQ: 2 Combos
-
Industrial MVR Evaporation Concentration Crystallizer for Fine Chemicals and Pickling WastewaterUS$ 4180 - 53200MOQ: 2 Combos
Application
Other, Wastewater Treatment
Capacity Range
0.5–80 t/h
Circulation Type
Forced Circulation
Installation Type
Skid-Mounted
Flow Configuration
Horizontal / Counterflow
Materials
Stainless Steel / Duplex Steel (customizable)
Power Supply
380V–690V, 50/60Hz (customizable)
Control System
PLC + HMI (automatic operation)
Qingdao Conqinphi Environmental Technology Group Co., Ltd. proudly introduces our latest 0.5–80 t/h Forced Circulation Skid-Mounted MVR Evaporator — a high-efficiency solution designed specifically for horizontal and counterflow wastewater treatment. With over 9 years of manufacturing experience and a factory spanning 10,000–30,000 m², we engineer every unit to deliver reliable performance, energy savings, and easy installation. Our MVR (Mechanical Vapor Recompression) technology reuses latent heat, reducing operating costs significantly.
This skid-mounted evaporator integrates forced circulation to handle challenging wastewater with high scaling or fouling tendencies. Whether your application involves industrial brine, pharmaceutical effluent, or chemical processing waste, our system provides robust concentration and zero-liquid-discharge (ZLD) capabilities. The compact, pre-assembled skid design minimizes on-site construction and commissioning time.
Key Features & Advantages
- Forced Circulation Design — Prevents scaling and fouling, ensuring long operational cycles even with high TDS (Total Dissolved Solids) feed streams.
- Skid-Mounted Configuration — Factory pre-assembled, tested, and ready for quick installation. Reduces footprint and civil engineering costs.
- MVR Technology — Energy consumption is 60–80% lower than traditional multi-effect evaporators. The compressor recycles vapor heat, requiring only electrical power.
- Horizontal & Counterflow Option — Optimizes heat transfer efficiency and minimizes vapor entrainment, ideal for high-viscosity liquids.
- Automated PLC Control — Real-time monitoring of temperature, pressure, flow, and concentration. Minimal operator intervention required.
- Wide Capacity Range — From 0.5 t/h for pilot-scale projects up to 80 t/h for large industrial lines.
Technical Specifications (Typical)
| Parameter | Value / Range |
|---|---|
| Evaporation Capacity | 0.5 – 80 t/h |
| Evaporation Temperature | 60–90 °C (adjustable) |
| Compressor Power | 15–800 kW (model dependent) |
| Specific Energy Consumption | 30–60 kWh per ton of evaporated water |
| Materials of Construction | SS304, SS316L, Duplex 2205 (customizable) |
| Control System | PLC + HMI touchscreen (remote monitoring optional) |
| Dimensions (per skid) | Approx. 4m × 2m × 3m (varies with capacity) |
Why Choose Our MVR Evaporator?
- Scalable & Modular — Multiple skids can be combined for higher throughput without redesigning the entire system.
- Robust for Challenging Wastewater — Handles high-salinity, high-COD, and corrosive streams with optional anti-corrosion coatings.
- Low Maintenance — Forced circulation reduces scale buildup, and the open-channel design allows easy inspection and cleaning.
- Environmentally Friendly — Achieves near-zero liquid discharge, reducing wastewater volume by 90–95%.
- Global Compliance — Designed to meet international standards; certified for quality management (ISO9001), environmental management (ISO14000), and occupational health (OHSAS18001).
Our team has delivered customized evaporation solutions to clients across North America, Europe, Southeast Asia, and Africa. With an annual export value exceeding US$10 million and a dedicated workforce of over 200 engineers and technicians, we guarantee professional after-sales support and prompt delivery from Qingdao port.
Contact us today for a detailed technical proposal tailored to your wastewater characteristics. Our engineers will work with you to select the optimal capacity, materials, and auxiliary equipment (preheater, condenser, etc.) to ensure maximum return on investment.
Frequently Asked Questions
-
What types of wastewater can this evaporator handle?
It is suitable for high-salinity brine, pharmaceutical effluents, chemical process streams, landfill leachate, and many industrial wastewaters with high total dissolved solids (TDS) or scaling potential. -
How much energy does it save compared to traditional evaporators?
Our MVR system typically consumes 30–60 kWh per ton of evaporated water, which is 60–80% less energy than conventional multi-effect evaporators, thanks to vapor recompression. -
Is the system fully automated?
Yes, it includes a PLC-based control system with HMI touchscreen for real-time monitoring of temperature, pressure, flow, and concentration. Automatic start/stop and alarm functions are standard. -
Can I customize the capacity or materials?
Absolutely. We offer flexible customization from 0.5 t/h to 80 t/h, and materials can be selected from SS304, SS316L, Duplex 2205, or other alloys upon request. -
What is the typical delivery time?
Standard models can be shipped within 8–12 weeks after order confirmation. Custom configurations may require 12–16 weeks depending on complexity. -
Do you provide installation and commissioning support?
Yes, we provide on-site supervision or remote guidance for installation, commissioning, and training. Spare parts and service support are available globally. -
What is the footprint of the skid-mounted unit?
The footprint varies with capacity. A typical unit of 5 t/h occupies about 4m × 2m × 3m. Detailed layout drawings are provided for your site planning. -
Does it require any external steam source?
No. The MVR system only requires an electrical power supply. During start-up, a small electric heater is used to reach operating temperature, after which the compressor maintains the cycle.
