This smokehouse features cooking, drying, humidified drying, baking, smoking, exhaust, and cleaning functions.
The main frame is filled with imported high-temperature resistant, high-quality aluminum silicate felt, enhancing insulation, ensuring excellent airtightness, and achieving energy efficiency. Multiple process steps can be performed individually or combined into a single process formula, and up to 100 different formulas can be stored.
It is equipped with a superior smoke circulation system, ensuring even smoke distribution within the oven, resulting in uniform and bright color in meat products and increasing yield. Smoked foods are resin-free, avoiding post-smoking contamination and waste.
It is used for processing and producing sausages, bacon, dried beans, chicken, duck, beef jerky, and other food products.
The smoking oven structure consists of a steam chamber, heating system, air supply system, exhaust system, drying system, and electrical control system. Smoking ovens are available in semi-automatic push-button and fully automatic touchscreen models, and can be customized with features such as cold smoking and spraying upon request.
| type |
QZX-30(Electric heating) |
QZX - 50 (Electric heating) | QZX - 100 (Electric heating) | QZX-150 | QZX-250 | QZX - 500 |
|
Production capacity (kg/oven) |
30 | 50 | 100 | 150 | 250 | 500 |
| Total power (kw） | 15.75 | 16.5 | 18 | 24 | 27 | 48 |
| nominal voltage | 380V 50Hz | 380V 50Hz | 380V 50Hz | 380V50Hz | 380V 50Hz | 380V50Hz |
| High pressure vapor pressure (Mpa) |
0.3-0.6 | 0.3-0.6 | 0.3-0.6 | 0.3-0.6 | ||
| low-pressure steam pressure (Mpa) |
0.1-0.2 | 0.1-0.2 | 0.1-0.2 | 0.1-0.2 | ||
|
Number of material carts |
1 | 1 | 1 | 1 | 1 | 2 |
| External dimensions (mm) | ≈1100×1100×1650 | ≈1850×1100×1840 | ≈1850×1200×2200 | ≈2000×1250×2300 | ≈2200×1100×320 | |
| weight(k g) | ≈200 | ≈400 | ≈600 | ≈1000 | ≈1500 | ≈2400 |
Our Services
Pre-sale service
1.Keep 24 hous online to answer customer's inquiry and online message
2.According to customer's requirement,guide customer choose the best suitable model
3.Offer detailed machine specification,pictures and best factory price
After-sale service
1.12 month warranty except the wearing parts
2.Detailed English User Manual will be equiped with the machine
3.Broken parts of the quality problem(except the wearing parts) will be sent free
4.Timely respond to customer's technical problem
