Durable Corrugated PTFE Hose for Chemical Industry Use
Product Description
1, Low chemical activity, resistance to all kinds of chemicals;
2, Weather resistance, corrosion resistance is strong, not easy ageing;
3, Low surface friction coefficient, the viscous resistance is strong;
4, Excellent electrical properties;
5, Heat resistance(+260ºC), Cold(-65ºC)
6, High pressure and low pressure resistance
| Brand Name | TFL |
| Item Name | PCB ptfe hose flexible chemical-resistance etching machine strong-acid |
| Color | Milky White/Translucent/Black |
| Inner Layer | Straight tube/Spiral corrugated hose/Annual hose PTFE |
| Reinforcement | Stainless steel 304 & 316 braided/Aramid fiber |
| Port Type | Straight tube/Flange/Fitting |
| Temperature Range | -65ºC -+260ºC(-85°F-+500°F) |
| Specification | 1/4'' 5/16'' 3/8'' 1/2'' 5/8'' 3/4'' 1'' 1¼'' 1½'' 2'' 3'' |
| Applications | Aero space &Transportation Technology, Electronics, Components & Insulators, Chemical & Pharmaceutical Manufacturing, FoodProcessing, Environmental Sciences, Air Sampling, Fluid Transfer Devices and Water Processing Systems. |
| Material | PTFE |
| Factory | Shanghai Teflon Anti Corrosion & engineering Group company |
| Standard | ISO9001 |
| No. | Specification | Inner Diameter | Outer Diameter(braided) | Min Bend Radius | Working pressure | Unit weight | |
| DN(mm) | NB(inch) | mm | mm | mm | bar | kg/m | |
| 1 | 6 | 1/4 | 6.5-6.8 | 10.4 | 19 | 82 | 0.112 |
| 2 | 8 | 5/16 | 7.8-8.1 | 12.1 | 20 | 75 | 0.144 |
| 3 | 10 | 3/8 | 9.1-9.3 | 14.2 | 22 | 60 | 0.158 |
| 4 | 15 | 1/2 | 13.1-13.3 | 18.8 | 28 | 48 | 0.223 |
| 5 | 18 | 5/8 | 16.0-16.3 | 21.9 | 32 | 38 | 0.345 |
| 6 | 20 | 3/4 | 19.3-19.8 | 26 | 40 | 30 | 0.456 |
| 7 | 25 | 1 | 25.0-25.4 | 30.4 | 56 | 28 | 0.511 |
| 8 | 32 | 1¼ | 32.0-32.5 | 41.9 | 70 | 25 | 0.878 |
| 9 | 1 | ½ | 38.5-39.5 | 49.9 | 75 | 20 | 1.138 |
| 10 | 50 | 2 | 53.5-54.5 | 66.9 | 80 | 15 | 1.725 |
| 11 | 80 | 3 | 61.5-63.5 | 80.4 | 150 | 10 | 2.622 |
* Meet SAE 100R14 standard.
* Customer-specific products may be discussed with us for detailed.
Detailed Photos
Technical Date
Technical date of PTFE smooth hose braid with 304 stainless steel
| Inner Diameter (inches) | Working Pressure (bar) | Burst Pressure (bar) | Bend Radius (mm) |
| 1/8'' | 280 | 840 | 40 |
| 3/16'' | 227 | 680 | 50 |
| 1/4'' | 200 | 600 | 75 |
| 5/16'' | 177 | 530 | 100 |
| 3/8'' | 153 | 460 | 125 |
| 13/32'' | 150 | 450 | 135 |
| 1/2'' | 140 | 420 | 165 |
| 5/8'' | 117 | 350 | 200 |
| 3/4'' | 93 | 280 | 230 |
| 7/8'' | 82 | 245 | 260 |
| 1'' | 67 | 200 | 300 |
