Smooth Bore Stainless Steel Braided PTFE Hose

Smooth Bore Stainless Steel Braided PTFE Hose thumbnail-3

Smooth Bore Stainless Steel Braided PTFE Hose thumbnail-4

Smooth Bore Stainless Steel Braided PTFE Hose photo-1

Smooth Bore Stainless Steel Braided PTFE Hose photo-2

Smooth Bore Stainless Steel Braided PTFE Hose photo-3

Smooth Bore Stainless Steel Braided PTFE Hose photo-4

Product Spotlights

Smooth bore stainless braided ptfe hose comprises a straight PTFE hose liner with single or double layer stainless steel wire outer braided, and is the basic PTFE hose design being used successfully in many automotive, fluid handling, chemical transfer, paint, pharmaceutical, food and beverage processing, cosmetics and general-purpose applications. The hose core is made from virgin 100% PTFE resin without any pigment or additive. the wire braiding is produced from ss304, ss201 or ss316 stainless

Negotiable MOQ: 1 Roll (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Material:

Other, teflon

Kind:

Other, ptfe hose

Transport Package:

wooden pallet

Contact Supplier Request Quote Chat Now

Anping Dinghong Wire Mesh Products Trading Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin

Delivery Detail:

3 days

Product Details
Company Profile
Contact Us

Material Other, teflon

Kind Other, ptfe hose

Transport Package wooden pallet

Specification 3mm - 51mm

Trademark Ding Hong

Origin China

Smooth bore stainless braided PTFE hose specifications:

1. PTFE hose diameter: 3mm - 51mm
2. Hose type: smooth bore
3. Braided wire material: SS304 or 316, color wire, etc
4. Operating temperature range: -70℃ -- 260℃
5. Maximum working pressure: 260Bar (depending on hose diameter)
6. Braided PTFE hose length: 6-130m/roll or as your request

In order to protect the braided ptfe hose as well as to protect the operators in the field, we can add a protective coating. the materials we cover include but are not limited to PVC, glass fiber, silicone, polyester, cotton yarn (thread) of various colors, etc.

PVC layer - Protective stainless steel braided layer for automotive/motorcycle retrofit brake lines.

Glass fiber - Insulation (thermal insulation).

Silicone layer - thermally insulated, high abrasion resistance.

Dacron polyester layer - heat-insulating, high strength and elastic recovery, high conformability, and wrinkle resistance.

Cotton yarn layer- Thermally insulated with an anti-crimp effect.

Motley cotton yarn colored cotton yarn layer - insulated, recognizable.

Product Tags: braided ptfe hose , ptfe hose , braided teflon hose
