As a leading manufacturer with a decade of experience in precision transmission solutions, Henan San Kuang Machinery Technology is proud to introduce our Metric Modular Gear Set for Precision Transmission Gear Assemblies. Engineered specifically for the demanding environments of automated assembly lines, our gear sets are the result of extensive R&D and a commitment to industrial excellence. Operating from our expansive 10,000-30,000 square meter facility in Luoyang, we combine advanced manufacturing techniques with stringent quality control processes to deliver components that ensure reliability, efficiency, and longevity in your production systems. This product line is designed to be the robust, precise, and adaptable heart of modern automation, helping you minimize downtime and maximize throughput.
Our modular gear system is built on the principle of versatile precision. Unlike off-the-shelf components, this set offers a high degree of configurability to match specific torque, speed, and spatial requirements within an assembly line. The core advantage lies in its metric modular design, which allows for seamless integration and easy replacement, significantly reducing maintenance complexity and inventory costs for spare parts.
Superior Engineering & Material Selection: We utilize high-grade alloy steels and, upon request, stainless steel, which undergo precise heat treatment processes like carburizing or nitriding. This ensures an optimal balance between a tough, wear-resistant core and a hard, durable surface, capable of withstanding continuous operation under load.
Uncompromising Precision: Each gear is manufactured to tight tolerances, achieving precision grades from DIN 5 to 8 or AGMA 10 to 12. This high level of accuracy translates into smooth meshing, reduced vibration, lower noise levels, and ultimately, higher positional accuracy for the automated equipment they drive.
Modular Design Philosophy: The "modular" aspect is key. The set includes a range of gear types (spur, helical, bevel, worm) within standardized metric modules. This allows system designers and maintenance engineers to create or modify transmission stages without needing completely custom-made parts, offering tremendous flexibility.
Optimized for Automation: Every design consideration is made with automated assembly lines in mind. This includes features for easy mounting (via shafts or flanges), compatibility with standard servo and stepper motors, and options for various lubrication systems to suit cleanroom or high-duty-cycle environments.
Here is a summary of typical technical specifications available. Please note that specific parameters can be customized to meet your project's exact needs.
| Parameter | Specification Range / Option |
|---|---|
| Module (Metric) | 0.5, 0.8, 1.0, 1.5, 2.0, 2.5, 3.0, 4.0, 5.0, 6.0, 8.0, 10.0 mm |
| Number of Teeth | Customizable from 12 to 150+ |
| Face Width | 5 mm to 100 mm (scalable with module) |
| Pressure Angle | 20° (Standard), 14.5° or 25° available |
| Bore Diameter | Standard metric sizes (e.g., 6mm, 8mm, 10mm, 12mm+) or custom |
| Operating Temperature Range | -20°C to +120°C (with standard lubricant) |
The direct benefits for your operation are substantial. By integrating our precision gear sets, you can expect a reduction in mechanical failure rates, leading to less unplanned downtime. The smooth operation lowers energy consumption and reduces stress on connected components like motors and bearings. Furthermore, the modularity future-proofs your investment, allowing for easy system upgrades or repairs without redesigning entire transmission assemblies.
Our commitment to quality is underpinned by a robust management system, as reflected in our certifications. With an annual export value ranging between US$2.5 and US$5 Million, our products have earned the trust of a global clientele across North America, South America, Europe, Asia, Africa, and Oceania. This widespread acceptance is a testament to their reliability and performance. We support this global reach with efficient logistics through major ports like Shanghai, Qingdao, and Tianjin. When you choose Henan San Kuang, you are not just purchasing a component; you are gaining a reliable partner dedicated to supporting the smooth and efficient operation of your automated assembly lines. Contact us today to discuss how our Metric Modular Gear Sets can be tailored to enhance your specific application.
Frequently Asked Questions (FAQ)
Q1: What does "modular" mean in the context of this gear set?
A1: "Modular" refers to a system built from standardized, interchangeable units. Our gear sets use standard metric modules and mounting interfaces. This allows you to combine different gear types and sizes from the set to create various speed ratios and transmission configurations, much like building blocks, offering great design flexibility and simplifying spare parts management.
Q2: Can these gear sets be used with both servo and stepper motors?
A2: Yes, they are designed to be compatible. The precision and low-backlash characteristics make them suitable for the precise positioning requirements of servo systems, while their robust construction can handle the torque characteristics of stepper motors. The key is selecting the correct module and size for the motor's torque and speed output.
Q3: What are the main advantages of a metric module system over an imperial (DP) system?
A3: The metric module system is globally prevalent, especially in automation and robotics. It often allows for more compact designs at higher torque capacities. Sourcing replacement parts or designing for global markets is generally easier with metric standards. We offer a comprehensive range of metric modules to meet this industry standard.
Q4: How do I determine the correct module and material for my application?
A4: Selection depends on several factors: transmitted torque, rotational speed, required lifespan, and operating environment (e.g., presence of contaminants, temperature). Our technical team can assist you with this calculation. Generally, higher loads and longer life requirements call for a larger module and higher-grade, heat-treated alloy steel.
Q5: Are custom bore sizes, keyways, or special surface treatments available?
A5: Absolutely. While we offer standard metric bore sizes, custom machining of bore diameters, keyways, set screw holes, or splines is a core part of our service. Special surface treatments like nickel plating or specific coatings for corrosion resistance can also be arranged upon request.
Q6: What kind of lubrication is recommended, and is a pre-lubricated option available?
A6: For most industrial automation applications, a high-quality synthetic grease is recommended for its long service life and stability. We can provide gears pre-lubricated with a standard industrial grease. For high-speed or extreme temperature applications, oil lubrication systems or specific dry-running coatings may be more suitable, which we can discuss.
Q7: What is the typical lead time for standard and custom orders?
A7: Lead times vary based on order complexity and volume. Standard configurations from our modular range typically have shorter lead times. For fully custom-designed gear sets or large orders, our sales team will provide a detailed production schedule upon receiving your specifications.
Q8: Do you provide technical drawings or 3D models for integration into our designs?
A8: Yes, we provide detailed 2D technical drawings (in PDF or DXF format) for all orders. For many standard items in our modular set, 3D models (STEP, IGES) are available upon request to facilitate your CAD design and assembly simulation process.
