Product Information:
Portable CNC cutting machine, also known as micro CNC cutting machine. From the perspective of model characteristics, the portable cutting machine has the characteristics of high-speed and high-efficiency CNC cutting machine, and its processing accuracy is also much higher than that of general handheld or copying equipment. It is precisely by virtue of the above characteristics that the portable CNC cutting machine is the most widely used type of cutting machine in the domestic market, with a market share of more than half.
Advantages:
1. The beam is designed with light structure, good rigid structure and light weight.
2. The incision is small and neat to avoid secondary processing.
3. Suitable for steel plate, aluminum plate, galvanized sheet, 100 steel plate and metal plate.
4. High configuration of CNC system, automatic arc striking, stable performance.
5. Automatically generate standard G-code documents, or input AutoCAD software to generate DXF format documents.
6. Support multi language, system language and power cord are configured according to customer's remarks or country.
7.When air transportation is selected, the y-axis track will be divided into two sections due to the limitation of air transportation length. When truck transportation is selected, it is a whole.
Parameters:
Product Name |
Portable CNC Cutting Machine |
||
Brand |
RAYLINE |
||
Model |
RA-XF1525 |
RA-XF1530 |
RA-XF2530 |
Effective Cutting Range(mm)( Customized) |
1500*2500 |
2500*3000 |
2500*3000 |
Total Weight (KG) |
110 |
120 |
120 |
Max. Cutting Speed |
15000mm/min |
15000mm/min |
15000mm/min |
Cutting Thickness(Flame)(mm) |
6-160 (O2/C3H8 or C2H2) |
6-160 (O2/C3H8 or C2H2) |
6-160 (O2/C3H8 or C2H2) |
Torch Flame |
Electric height adjustment(±60mm) |
Electric height adjustment(±60mm) |
Electric height adjustment(±60mm) |
Control System |
STARFire plasma cutting system |
STARFire plasma cutting system |
STARFire plasma cutting system |
Type of Gas |
C3H8 C2H2 |
C3H8 C2H2 |
C3H8 C2H2 |
Working Voltage ( Customized) |
AC220/50HZ |
AC220/50HZ |
AC220/50HZ |
Software Support |
FASTCAM,AutoCAD,etc |
FASTCAM,AutoCAD,etc |
FASTCAM,AutoCAD,etc |
Drive System |
Stepper motor |
Stepper motor |
Stepper motor |
Instruction Format |
G code |
G code |
G code |
Move Precision |
±0.2mm/m |
±0.2mm/m |
±0.2mm/m |
Emergency Stop |
YES |
YES |
YES |
ARC |
Untouched arc striking |
Untouched arc striking |
Untouched arc striking |
Plasma Power Supply |
China Huayuan 63/100/160/200A(Optional Hyper therm --45A,65A,85A,105A,125A,200A) |
||
Processing Materials |
Iron, steel aluminum sheets, galvanized sheets, Titanium plates |
