PMMA XF03 Clear Acrylic Pellets High Flow Resin for Optical Lighting Parts

PMMA XF03 Clear Acrylic Pellets High Flow Resin for Optical Lighting Parts thumbnail-2

PMMA XF03 Clear Acrylic Pellets High Flow Resin for Optical Lighting Parts thumbnail-3

PMMA XF03 Clear Acrylic Pellets High Flow Resin for Optical Lighting Parts thumbnail-4

PMMA XF03 Clear Acrylic Pellets High Flow Resin for Optical Lighting Parts thumbnail-5

PMMA XF03 Clear Acrylic Pellets High Flow Resin for Optical Lighting Parts photo-1

PMMA XF03 Clear Acrylic Pellets High Flow Resin for Optical Lighting Parts photo-2

PMMA XF03 Clear Acrylic Pellets High Flow Resin for Optical Lighting Parts photo-3

PMMA XF03 Clear Acrylic Pellets High Flow Resin for Optical Lighting Parts photo-4

PMMA XF03 Clear Acrylic Pellets High Flow Resin for Optical Lighting Parts photo-5

Product Spotlights

PMMA XF03 clear acrylic pellets offer high flow for easy molding of intricate optical lighting parts. Features exceptional clarity (>92% transmittance), UV resistance, and durability. Enhances production efficiency with faster cycles and consistent quality, ideal for lenses, light guides, and covers requiring superior aesthetics and performance.

Negotiable MOQ: 1 Kilogram (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Material:

PMMA (Polymethyl Methacrylate)

Grade/Model:

XF03

Appearance:

Clear, transparent pellets

Contact Supplier Request Quote Chat Now

Shanghai Wenqin Plastics Co., Ltd.

1Yr

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI/NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Material PMMA (Polymethyl Methacrylate)

Grade/Model XF03

Appearance Clear, transparent pellets

Melt Flow Rate High flow grade

Primary Application Optical and lighting components

Processing Method Injection molding, extrusion

Optical Properties High light transmittance, low haze

Certifications ISO 9001, ISO 14001, IATF 16949

As a specialized manufacturer of high-performance engineering plastics, Shanghai Wenqin Plastics Co., Ltd. is proud to introduce our PMMA XF03 Clear Acrylic Pellets. Engineered for demanding optical and lighting applications, this high-flow resin combines exceptional clarity with superior processability, enabling the production of parts with brilliant aesthetics and consistent quality. We leverage our expertise and modern production facilities to deliver a reliable material solution that meets the stringent requirements of global markets, from North America and Europe to Southeast Asia and beyond.

Our PMMA XF03 resin is formulated to address the core challenges in manufacturing optical lighting parts, such as lenses, light guides, diffusers, and decorative covers. The material's inherent properties and optimized flow characteristics make it an ideal choice for complex, thin-walled designs where both visual perfection and manufacturing efficiency are paramount.

Key Features and Technical Advantages:

Exceptional Optical Clarity: Offers high light transmittance and low haze, ensuring bright, undistorted light output and crystal-clear appearance for finished parts.
Superior High-Flow Performance: The XF03 grade is specifically designed for easy filling of intricate molds, reducing injection pressure and cycle times, which enhances productivity and lowers energy consumption.
Excellent Weathering and UV Resistance: PMMA naturally resists yellowing and degradation from prolonged exposure to sunlight and outdoor conditions, ensuring long-term durability for lighting applications.
Good Mechanical Strength and Rigidity: Provides the necessary structural integrity for components while maintaining dimensional stability under various thermal conditions.
High Surface Hardness and Scratch Resistance: The material offers good resistance to abrasion, helping to maintain a pristine surface finish on lenses and covers throughout their service life.
Consistent Quality and Batch-to-Batch Uniformity: Produced under strict quality control systems, ensuring reliable performance in every production run.

Technical Specifications Overview:

Property	Test Method	Typical Value
Melt Flow Rate (230°C/3.8kg)	ISO 1133	High Flow Grade
Light Transmittance (3mm thickness)	ASTM D1003	≥ 92 %
Haze (3mm thickness)	ASTM D1003	≤ 1 %
Tensile Strength	ISO 527	70 - 75 MPa
Flexural Modulus	ISO 178	3200 - 3500 MPa
Vicat Softening Temperature	ISO 306 (B50)	≥ 95 °C

Benefits for Your Business:

Enhanced Production Efficiency: The high flow rate allows for faster cycle times and easier processing of complex geometries, potentially increasing your output.
Superior Part Quality: Achieve optical components with excellent clarity and surface finish, reducing the need for secondary finishing operations.
Material Reliability: Consistent pellet quality minimizes processing issues like splay, voids, or short shots, leading to fewer rejects and more predictable manufacturing.
Design Freedom: Enables the molding of thinner walls and more intricate light-guiding features that might be challenging with standard flow resins.
Long-Term Performance: Parts made from this PMMA resin are known for their durability and resistance to environmental factors, contributing to product longevity.

Processing Guidelines:

For optimal results, standard drying procedures for PMMA are recommended before processing (e.g., 2-4 hours at 80-90°C). Typical melt temperatures for injection molding range from 220°C to 260°C. Mold temperature should be controlled between 50°C and 80°C to achieve the best surface finish and dimensional stability. Specific processing parameters can be adjusted based on part design and mold configuration.

Backed by a commitment to quality evidenced by our ISO 9001 and IATF 16949 certifications, Shanghai Wenqin Plastics ensures that every batch of PMMA XF03 resin meets rigorous standards. Our strategic location in Shanghai and shipment ports like Shanghai and Ningbo facilitate efficient logistics to our main markets worldwide. We invite you to experience the difference that a high-performance, reliable acrylic resin can make in your optical lighting parts production. Contact us today to request samples, discuss your specific application requirements, or place an order.

Frequently Asked Questions (FAQ):

Q: What is the primary difference between your XF03 grade and standard PMMA resin?
A: The XF03 grade is classified as a high-flow resin. This means it has a higher melt flow rate, allowing it to fill molds more easily and completely, which is particularly advantageous for intricate optical parts with thin walls or complex geometries.
Q: Is this material suitable for outdoor lighting applications?
A: Yes. PMMA is known for its good weatherability and UV resistance. Our XF03 resin maintains these properties, making it a suitable choice for outdoor lighting fixtures where resistance to yellowing and environmental degradation is important.
Q: Can you provide material data sheets (MDS) and safety data sheets (SDS)?
A: Absolutely. Comprehensive technical data sheets and safety documentation are available upon request to support your material evaluation and compliance processes.
Q: What are the recommended storage conditions for these pellets?
A: The pellets should be stored in a cool, dry place in their original, sealed packaging to prevent moisture absorption. Proper storage ensures the material maintains its optimal processing characteristics.
Q: Do you offer custom color matching or formulations?
A: Customization options such as specific color tints or modified properties may be available. Please contact our technical sales team to discuss your specific needs and feasibility.
Q: What is the typical lead time for an order?
A: Lead times can vary based on order quantity and current production schedule. We strive to provide prompt delivery, especially for standard grades. Please inquire for a specific timeline based on your requirements.
Q: Is this resin compliant with any specific industry standards for optical parts?
A: While the material exhibits properties suitable for optical applications, compliance with specific end-product standards (e.g., for automotive lighting) would depend on the final part design and manufacturing process. We can provide material property data to support your certification efforts.
Q: How does the cost of this high-flow grade compare to regular PMMA?
A: High-flow grades often provide value through increased production efficiency (faster cycles, lower energy use, fewer rejects). The overall cost-in-use can be favorable. We recommend evaluating based on total production cost rather than just material price per kilogram.
