Help CenterCopper Wire Granulator Machine | High Purity Copper Plastic Separation Equipment
Product Spotlights
Related Products
-
Automatic Copper Wire Recycling Machine | Waste Cable Copper Separation PlantUS$ 18600MOQ: 1 Set -
Industrial Copper Granulator | Dry Type Waste Wire Copper Plastic SeparatorUS$ 18600MOQ: 1 Set
-
High Efficiency Waste Cable Recycling Machine | Copper Wire Separation EquipmentUS$ 18600MOQ: 1 Set
-
Dry Copper Wire Granulator Machine | Pure Copper Recovery for Waste CableUS$ 18600MOQ: 1 Set
-
Commercial Copper Plastic Separation Machine | Scrap Wire Recycling GranulatorUS$ 18600MOQ: 1 Set
Basic Info.
Model NO.
WL-600
Automation
Automatic
Certification
ISO, CE
Screw
Multi-Screw
Knife Type
Flat Knife Crusher
Recycling Product
PCB, Copper Cable Wire
Capacity
200-300 Kg/H
Recycle Rate
99%
Power
45kw
Opearator
1
Weight
2800 Kgs
Transport Package
Wood Box
Specification
5800*2150*3000 mm
Trademark
walle industry
Origin
China
HS Code
8479820090
Production Capacity
10set/Month
Product Description
Product Description
| Type | power | Working capacity | tips | weight |
| RK50 | 8.69 kw | 50-60 kg/h | copper purity 99%. cutter material SKD-11 or D2. cutter four sides use | 1000 KGS |
| RK400 | 28 kw | 70-100 kg/h | 1900 kgs | |
| RK600 | 42 kw | 200-300 kg/h | 3200 KGS | |
| RK800 | 68 kw | 500-600 kg/h | 6500 kgs | |
| RK1000 | 128 kw | 800-1000 kg/h | 12500 kgs | |
| RK1500 | 232 kw | 1200-2000 kg/h | 23000 kgs |
The more detail and high capacity of the machines assemble, pls connect us for more .
Our Advantages
1.Dry method recycling rate is up to 98%. 2.Full autaomtic 1 operator,the whole system controlled by the PLC 3. integrated type , cut off the power and improve the capacity. 4. The separating parts take the gravity separator combined with the electrostatic separator machine. 5. There is equipped with the jet filter bag dust removal 6. The cutter of wire chopping machine takes the steel alloy D2 or SKD-11 keeps the long operation and uptime.
7. It works to the coarse wires.like the car wire, and other kind of tiny wire.
A Copper Wire Granulator, also known as a Copper wire recycling machine, is a specialized recycling system designed to efficiently separate copper from plastic/rubber insulation in waste cables and wires. It plays a vital role in the e-waste recycling and metal recovery industries, transforming scrap materials into reusable resources with high economic and environmental value.
Cable Shredder
Function: Cuts scrap wires into small granules (copper particles mixed with plastics, called "copper rice").
Vibration table
filter oversize particle to secondary grinding.
Separating stage
1. Air gravity separator :Utilizes density differences (copper: 8.9 g/cm³ vs. plastic: 1.0-1.4 g/cm³) to separate lighter plastics via airflow.
2. Electrostatic separator:
Principle: Separates fine copper powder and plastics using conductivity differences in a high-voltage electrostatic field.
Application: Ideal for complex mixtures (e.g., thin copper wires with PVC residues
3. Straight table: to sort the pink coper from yellow
DUST PURIFICATION
The Impulse filter dust collector or bag type to control the dust flying.
Detailed Photos
