Product Description
Metal scrap hammermill shredder metal scrap crusher is for the light material. bulky material or the steel wire scrap to process them into smaller density material through the hammer squezing, rubbing,crashing of hammer and the material, to down size of material, meanwhile to get out the impurities .cut off the cost of transportation, increase the melting ratio. there is fit with jet pulse filter to proect environment.
High Efficiency and Energy Saving: Driven by a geared motor, it saves approximately 20% more energy compared to traditional equipment, while also featuring high output and a large crushing ratio.
Robust and Durable: The machine body employs a robust construction and densely distributed reinforcing ribs to ensure stability under high-intensity operation. Key wear parts such as blades and hammers are typically made of wear-resistant materials such as high-alloy steel or manganese steel.
Environmentally Friendly and Low Noise: The equipment operates smoothly and with low noise. Advanced dry systems are equipped with dust removal devices, while wet systems suppress dust through water spraying, minimizing the environmental impact of the production process.
Intelligent Operation: Equipped with centralized control buttons, it enables automated production. Typically, only one person is needed to operate the entire crushing process, making it simple and convenient.
Product Parameters
| Type | power | feeder | rotary | capacity | size | weight |
| PGS-800 | 37-55 KW | 800 mm | 1250 rpm | 0.7-1 t/h | 3800*1600*1800mm | 3.2t |
| PGS-1000 | 45-75 KW | 1000 mm | 1250 rpm | 0.8-1.5t/h | 2560*1800*2200 mm | 7.6t |
| PGS-1300 | 90-150 KW | 1300 mm | 860 rpm | 2-4 t/h | 4000*3500*3200 mm | 11.5-26t |
| PGS-1600 | 200-280 KW | 1600 mm | 750 rpm | 4-6 t/h | 4800*4000*3800 mm | 16.6-35 t |
| PGS-1800 | 220-450 KW | 1800 mm | 650 rpm | 6-10 t/h | 4800*4100*4000 mm | 32-48 t |
| PGS-2000 | 315-630 KW | 2000 MM | 650 rpm | 8-12 T/H | 5000*4500*4300 MM | 35-65 T |
| PGS-2200 | 500-900 KW | 2200 MM | 650 rpm | 15-20 T/H | 5000*4500*4500 MM | 35-65 T |
| PGS-2400 | 1250-2250 KW | 2400 MM | 650 rpm | 20-45 T/H | 6300*4800*4500 MM | 85-120T |
| PGS-2800 | 1600-3000 KW | 2600 MM | 650 rpm | 70-100 T/H | 6400*5200*4800 MM | 145-230T |
| PGS-3000 | 3300-4400 KW | 3000 MM | 650 rpm | 110-140 T/H | 8500*7200*5500 MM | 280-760T |
Detailed Photos
Advantage
Features of the hammermill shredder
1.The hammer is made of high maganese
2. construction is robust and durable, dense reinforcement plate to ensure strong box.
3. Liner Special alloy to ensuare in operation and uptime.
4. Ejection device to avoid damage the hammer and electronics.
5. Hydraulic cyclinder to facilitate mechanical maintenance and repair.
6. PLC controller system to confirm the safety
8 the force feeding device, two stage pressing the bulky material to the crushing chamber . improve the processing efficiency.
9.Robust frame and liar to keep continue uptime.
10. Eject design to avoid heavy material damage the core part.
11. Hydraulic cylinder to open caps , which is convenient to speed up offtime.
12. The New hammer design with the cover to expand working hours.
13. The crushing chamber takes the thickness and durable material to reliable and keep Operation hours.
14. expedition of sorting device, Zig zag separator , and drum magnetic separator equipped.
