Dew Point Transmitter Pura
The compact dew point transmitter PURA features a robust and independent sensor for measuring trace moisture content in high-purity gases. Pura is easy to use and install. It offers options of two-wire, three-wire, and models for hazardous areas. It is a fully customizable product that can meet various special requirements.
The compact dew point transmitter PURA features a robust and independent sensor for measuring trace moisture content in high-purity gases. Pura is easy to use and install. It offers options of two-wire, three-wire, and models for hazardous areas. It is a fully customizable product that can meet various special requirements.
The measurement range can be as low as -120°Cdp (1ppbV)
Stable and repeatable measurement
Analog and digital outputs
Easy installation
VCR process connection
Optional display/alarm unit
Compact design
Fast response
Optional hazardous area certification
Calibration and replacement service
| Range | -120 - -40°Cdp (Calibration range -100 - -40°C) |
| Accuracy | ±1°C -40 ~ -60°Cdp ±2°C -60 ~ -100°Cdp ±4°C -100 ~ -120°Cdp (Estimated) |
| Operating pressure | Minimum 10-7 Pa (10-9 torr) 24 MPa (240 barg) |
| Operating temperature | -40 ~ +60°C |
| Flow rate | 1 ~ 5 Nl/min |
| Electrical | |
| Power supply | Nominal voltage 24 V DC, 10-28 V DC, current 25 mA, 2 or 3-wire configuration |
| Output | PUR-TX-2W: 4 ~ 20mA 2-wire system PUR-TX-3W: 4~ 20mA 3-wire system Only PUR-AOL-SEN: Digital (RS485) |
| Display cable | PUR-OL & PUR-IS-OL: 2m (standard) / 5 or 10m (optional) PUR-AOL: 2m (standard) / 5 or 10m (optional) |
