Industrial Coconut Silk Palm Silk Metal Powder Mineral Residue Wine Trough Residue Drum Dryer EPC

Industrial Coconut Silk Palm Silk Metal Powder Mineral Residue Wine Trough Residue Drum Dryer EPC thumbnail-1
Industrial Coconut Silk Palm Silk Metal Powder Mineral Residue Wine Trough Residue Drum Dryer EPC thumbnail-2
Industrial Coconut Silk Palm Silk Metal Powder Mineral Residue Wine Trough Residue Drum Dryer EPC thumbnail-3
Industrial Coconut Silk Palm Silk Metal Powder Mineral Residue Wine Trough Residue Drum Dryer EPC thumbnail-4
Industrial Coconut Silk Palm Silk Metal Powder Mineral Residue Wine Trough Residue Drum Dryer EPC thumbnail-5
Industrial Coconut Silk Palm Silk Metal Powder Mineral Residue Wine Trough Residue Drum Dryer EPC photo-1
Industrial Coconut Silk Palm Silk Metal Powder Mineral Residue Wine Trough Residue Drum Dryer EPC photo-2
Industrial Coconut Silk Palm Silk Metal Powder Mineral Residue Wine Trough Residue Drum Dryer EPC photo-3
Industrial Coconut Silk Palm Silk Metal Powder Mineral Residue Wine Trough Residue Drum Dryer EPC photo-4
Industrial Coconut Silk Palm Silk Metal Powder Mineral Residue Wine Trough Residue Drum Dryer EPC photo-5

Product Spotlights

1.Large Processing Capacity 2.Less Fuel Consumption 3.Low Drying Cost 4.High Temperature Resistance 5.Operate Steadily and Simple Structure 6.Strong overload Resistance
US$ 9800 1 - 4 Combo
US$ 9500 ≥5 Combo
Key Specifications
Get Latest Price
Warranty:
1 year
After-sales Service:
On site installation or video guidance
Heating Mode:
Other
Contact Supplier Request Quote Chat Now
Henan Kunteng Machinery Manufacturing Co., Ltd.
Gold Verified Supplier
1Yr
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Warranty 1 year
After-sales Service On site installation or video guidance
Heating Mode Other
Material Status Powder, Bulk, Other
Drying Medium Other
Flow Other
Operational Method Other
type Drum Drying Equipment
voltage 380V or customized
heating method Gas Heating,oil,steam,biomass pellet
core components Other, Engine, Motor, Pump, Bearing
dimension(l*w*h) 800*800*8000mm/customized
Application Cassava residue,pomace,beer yeast
Advantage Low Consumption High Efficiency Dryer
Keywords Cocopeat dryer
Product name sawdust rotary drum dryer
Temperature range 60~500℃
Transport Package container
Trademark KUNTENG
Origin China

Production Description
Rotary drum dryer Features:

1.Large Processing Capacity
2.Less Fuel Consumption
3.Low Drying Cost
4.High Temperature Resistance
5.Operate Steadily and Simple Structure
6.Strong overload Resistance

Heat Source: coal, natural gas, wood, biomass particles, etc.

Multi Functional Drum Dryer Corn Pomace and Fruit Pomace Dryer Distiller's Grains Drying Equipment



Model

Power (kw)

Rotor Diameter (mm)

Drum Length(mm)

Speed(r/min)

KT-800

7.5

Φ800

10000

7.2

KT-1000

7.5

Φ1000

10000

6.73

KT-1200

15

Φ1200

12000

5.8

KT-1500

22

Φ1500

15000

4.8

KT-1800

37

Φ1800

14000

3.2

KT-2000

55

Φ2000

18000

3

Rotary drum dryer diameter : 800~4000cm,the length according to drying requirement can be customized



Working principle:

The raw material is transported to the inside of the rotary drum dryer by conveyor. High temperature hot air quickly evaporate the moisture, Materials is constantly turned under the action of the lifting plate, finally take the moisture out, the dried material come out at the cyclone.

It can dry wet material to 15% moisture content.

1-30t/h olive pomace dryer cassava pulp drying machine beer brewing waste vinasse drying machine single rotary drum dryer

The Rotary drum dryer Widely used in metallurgy, chemical industry, coal, fertilizer, ore, sand, sawdust, cocopeat, wood chips, cassava residue, pomace, beer yeast, bagasse, manure, etc.

Company Profile

KUNTENG company was founded in 1999. has been focusing on machinery manufacturing for many years.include Rotary drum dryer, heat pump dryer, Mesh belt dryer, Freeze dryer, Charcoal making machines, Waste sorting machines, Coconut husk processing machines.We got more patented technologies and honor. Our machine has passed ISO9001:2000 CCC,CE certification, We provide customers with a one-stop service of design solutions, complete equipment, on-site installation, and after-sales support.

PACKING & SHIPPING

FAQ

Q1: Are you a factory or a trading company?
A1: We are a professional manufacturer in China
Q2: How long is the warranty period?
A2: Normally 12 months. Except for wearing parts.

Q3: What’s your delivery time?
A3: We will arrange for shipping in factory within 15 working days after receiving the advance payment.

Please feel free to contact us for details.
