Product Overview
YANTOK YT-PS600H is a professional single-projector passive 3D polarization modulator independently developed by yantuo electronics. It is fully compatible with all DLP 3D projectors and D-ILA 3D projectors, enabling high-quality passive circular polarized 3D projection using only one standard projector. This patented 3D solution delivers stable, sharp, and immersive 3D images with extremely low crosstalk, making it widely used in home theaters, movie bars, KTV, 4D/5D dynamic cinemas, business conferences, exhibition halls, science museums, 3D education, medical training, 3D projection blending,and various commercial entertainment venues.
Built with industrial-grade standards and protected by national patents, YT-PS600H features a durable CNC-machined aluminum alloy shell with laser engraving, combining stylish appearance and heavy-duty reliability. It uses imported high-transmittance, ultra-fast-response polarizing filters and high-stability electronic components to ensure consistent performance and stunning 3D visuals. The advanced design supports both DLP-Link wireless and wired synchronization, with automatic 3D signal detection and smart 2D/3D switching without remote control or manual operation. Equipped with a high-precision spatial positioning sensor, it automatically calibrates 2D/3D spatial positions for perfect image alignment.
The fan-free, fully sealed structure prevents dust contamination on optical parts, avoiding brightness loss and mechanical failures, while ensuring stable operation even under high-temperature conditions. Extremely easy to install within 3 minutes, YT-PS600H is powered directly by the projector with no external power supply required. It supports projectors up to 10,000 lumens and projection screens up to 10 meters wide, delivering professional cinema-grade 3D performance for small theaters, home cinemas, and commercial 3D projects.
!Note: When used with D-ILA projectors, a waveplate must be installed between the modulator and the projector lens.
Core Advantages
National Patent Technology
YT-PS600H uses patented optical and control technology with independent intellectual property rights, ensuring stable performance and professional 3D modulation effects.
Industrial-Grade Aluminum Alloy Shell
The shell adopts CNC laser engraving technology, with high strength, good heat dissipation, stylish appearance, and long service life for both commercial and home use.
Imported High-End Optical Components
Equipped with imported high-transmittance and ultra-fast-response polarization filters and high-stability electronic modules, ensuring ultra-low ghosting and high-quality 3D imaging.
Dual Synchronization Modes & Auto 2D/3D Switching
Supports DLP-Link wireless and wired synchronization. It automatically senses 3D signals and switches between 2D and 3D without manual operation or remote control.
Full Compatibility with DLP & D-ILA Projectors
Works with all DLP 3D projectors and D-ILA 3D projectors. (A 1/2 waveplate is required for D-ILA projector applications.)
Fan-Free & Fully Sealed Dust-Proof Design
No fan, no noise, fully sealed optical system to avoid dust contamination, brightness loss, and failure, ensuring stable long-term operation.
3-Minute Quick Installation & Projector-Powered
Super easy installation in 3 minutes. Powered directly by the projector, no external power supply or complicated wiring needed.
Single Projector RealD Circular Polarized 3D
Only one projector can achieve professional passive RealD circular polarized 3D effect, greatly reducing equipment cost.
Ultra-Low 3D Glasses Cost
Uses low-cost universal passive circular polarized 3D glasses. Damaged glasses can be replaced directly at minimal cost.
Wide Application for Multiple Scenarios
Suitable for small 3D cinemas, home theaters, 4D/5D/6D/7D/9D cinemas, KTV, movie bars, business exhibitions, education, medical training,3D projection blending, and luxury home cinema.
Full Specifications
Model: YT-PS600H
Product Type: Single-projector passive 3D polarization modulator
Optical Effective Area: 100mm x 80mm
Light Transmittance: 40%±1.5% for DLP; 90%±2% for D-ILA
Light Efficiency: 16% ±1% for DLP; 35%±1.5% for D-ILA
Ghosting Rate:
Optical Principle: Circular polarization
Response Time:
Supported Frame Rate: > 480Hz
Max Projection Screen Width: 10m
Recommended Screen Gain: 2.0 – 3.0 (recommended 2.4)
Polarization Contrast (Metal Screen): > 150:1
2D/3D Conversion: Fully automatic
Projector Sync Interface: VESA(mini Din3) / DLP-LINK(White Peak Pulse)
Compatible Projectors: All DLP 3D projectors; D-ILA 3D projectors (with 1/2 waveplate)
Max Supported Projector Brightness: 10000 Lumens
Structure: Fan-free, fully sealed, dust-proof
Power Supply: Powered by projector (no external power needed) or USB 5V Power Adapter(5V,100mA)
Housing: CNC aluminum alloy with laser engraving
-
Patent: National patent protected technology
Applications
YANTOK YT-PS600H 3D polarization modulator is widely used in:
Small 3D digital cinemas & private movie theaters
Home theaters, villas, and luxury home cinema systems
4D/5D/6D/7D/9D dynamic cinemas & amusement equipment
Movie bars, KTV, 3D internet cafes, and entertainment venues
Business conference rooms, exhibition halls & experience centers
Science museums, technology centers & educational institutions
3D education training & 3D medical simulation training
High-end clubs, spa centers, and commercial cultural tourism projects
3D projection blending
Why Choose YANTOK YT-PS600H?
YANTOK YT-PS600H is the most cost-effective and reliable single-projector 3D solution for global buyers. Its patented circular polarization technology delivers cinema-level 3D effects at a fraction of the cost of dual-projector systems. The industrial-grade design, fan-free silent operation, dust-proof structure, and automatic 2D/3D switching make it extremely user-friendly and maintenance-free.
With full compatibility for DLP and D-ILA projectors up to 10,000 lumens and 10-meter screens, it supports almost all small and medium-sized 3D projection scenarios. The low-cost passive 3D glasses greatly reduce long-term operating costs, while the 3-minute quick installation simplifies deployment for installers and integrators.
Backed by national patents, imported optical parts, and strict industrial standards, YT-PS600H provides stable performance, stunning image quality, and long service life. It is the top choice for building professional, economical, and reliable 3D projection systems for home, business, education, and entertainment markets worldwide.
