Product Description:
This chemical copper bonded ground rod is supplied with specially formulated backfill compound containing bentonite and conductive minerals that dramatically reduce ground resistance. The chemical compound retains moisture around the electrode, maintains stable low resistance over time, and improves contact with surrounding soil. Ideal for difficult grounding locations. Typical applications include high-resistivity soil areas (sandy, rocky, or mountainous), desert and arid region earthing, telecommunications grounding in poor soil, substations with high soil resistance, data center grounding, and any site requiring enhanced chemical treatment to achieve acceptable ground resistance.
Key Specifications (Copper Ground Rod)
Parameter |
Specification / Range |
Remarks |
Standards |
ASTM B2, B187, BS 7430, IEC 62561-2, UL 467 |
Others on request |
Material |
C11000 (ETP) / C10200 (OFC) |
Copper purity ≥99.9% |
Diameter |
1/2″, 5/8″, 3/4″, 1″ (12.7mm – 25.4mm) |
Custom on request |
Length |
1.5m, 2.4m, 3m, or custom |
Threaded / pointed ends |
Surface |
Bright, clean, smooth |
Also available tinned |
Tensile Strength |
≥200 MPa |
– |
Conductivity |
≥101% IACS |
– |
Testing |
PMI, tensile, straightness, conductivity |
Mill cert provided |
Packaging |
Bundled with plastic caps, steel strapped, wooden pallet |
Seaworthy, ISPM 15 |
Q1：Do you offer sample orders？
A：Yes, samples are available for quality evaluation. Sample cost is charged but refundable upon bulk order.
Q2：What is your MOQ？
A：Our standard MOQ is 100 kg per specification. For common grades and standard sizes, we accept small batch orders. Mixed orders for different products are also welcome.
Q3：Can you provide custom sizes？
A：Yes, we can produce any length, width, thickness, or diameter based on your drawings. Cutting, slitting, and other processing services are available with tolerance as required.
Q4：What certifications do you provide？
A：Each shipment comes with EN 10204 3.1 mill test certificate (MTC). Third-party inspection reports (SGS/BV/TÜV) can be arranged upon request.
Q5：What is your lead time？
A：7–15 working days for stock items. 20–30 days for custom orders, depending on quantity and specification.
Q6：What surface treatments are available？
A：Various surface treatments are available upon request, including pickled, polished, coated, oiled, or as required.
Q7：What payment terms do you accept？
A：T/T (30% deposit + 70% against BL copy), L/C at sight, Western Union, etc.
Q8：What about packaging for export？
A：Standard seaworthy packaging with waterproof protection, steel straps, corner protectors, and ISPM 15 fumigation certification. Custom packaging is available as required.
