Shanghai Yunshan Plasticizing Co., Ltd., a specialized manufacturer based in Shanghai, China, proudly presents our high-performance Thermoplastic Polyurethane TPU 1175A Industrial Belts. Engineered specifically for demanding industrial environments, these belts set a benchmark in abrasion resistance and durability. As a dedicated producer, we focus on delivering belts that significantly reduce downtime and maintenance costs for operations involving heavy or abrasive materials. Our TPU 1175A belts are the result of rigorous formulation and manufacturing processes, ensuring consistent quality and reliability that you can depend on for critical conveying tasks.
The core advantage of our TPU 1175A belts lies in their exceptional material properties. Thermoplastic Polyurethane offers a unique combination of toughness and flexibility, outperforming traditional rubber or PVC belts in numerous aspects. The 1175A grade is formulated to excel in applications where resistance to wear from sharp-edged or gritty materials is paramount. This translates directly into longer belt life, reduced replacement frequency, and lower overall operational costs for your business.
Beyond abrasion resistance, these belts demonstrate outstanding performance characteristics:
High Tensile Strength: Withstands significant operational loads without stretching or deforming.
Excellent Tear Resistance: Maintains integrity even when handling materials with sharp protrusions.
Good Flexibility at Low Temperatures: Performs reliably in cooler environments where other materials might stiffen.
Resistance to Oils and Greases: Withstands exposure to common industrial lubricants and contaminants.
Low Coefficient of Friction: Ensures smooth material flow and reduces drive power requirements.
Hydrolysis Resistance: Suitable for environments with moisture exposure.
Typical technical specifications for our standard TPU 1175A belt material include:
| Property | Test Method | Typical Value |
| Tensile Strength | DIN 53504 | ≥ 40 MPa |
| Elongation at Break | DIN 53504 | ≥ 550% |
| Abrasion Resistance | DIN 53516 / ISO 4649 | ≤ 35 mm³ |
| Tear Resistance | DIN 53515 | ≥ 100 N/mm |
| Hardness (Shore A) | DIN 53505 | 85 ± 2 |
These belts find optimal application in industries where conveying abrasive materials is a daily challenge. Key sectors include:
Mining and Quarrying: Handling ores, stones, and aggregates.
Recycling: Moving glass, metal scraps, and e-waste.
Wood Processing: Conveying wood chips, bark, and sawn timber.
Agriculture: Transporting grains, feed, and fertilizers.
Construction Materials: Moving sand, cement, and gravel.
Shanghai Yunshan Plasticizing Co., Ltd. leverages its manufacturing expertise in Shanghai to ensure consistent quality across every batch of TPU 1175A belts we produce. Our commitment is to deliver products that enhance your operational efficiency by minimizing belt failures and unplanned stoppages. Choosing our abrasion-resistant belts means investing in a solution proven to handle tough materials day in and day out, providing a tangible return on investment through extended service life. We encourage you to contact us to discuss your specific application requirements and discover how our TPU 1175A belts can improve your material handling processes.
Frequently Asked Questions (FAQ):
Q: What makes TPU better than rubber for abrasive applications?
A: TPU generally offers superior abrasion resistance compared to many rubber compounds. It maintains its physical properties better under high-wear conditions, leading to longer belt life when handling sharp or gritty materials. TPU also tends to have better resistance to oils and ozone.Q: How does the service life of TPU 1175A compare to standard PVC belts?
A: In abrasive applications, TPU 1175A belts typically last significantly longer than standard PVC belts – often 3 to 5 times longer, depending on the specific material being conveyed and the operating environment. This translates to reduced replacement costs and downtime.Q: Can these belts be customized for specific widths or thicknesses?
A: Yes. Shanghai Yunshan offers customization. Belts can be manufactured in various widths (typically from 100mm up to 2000mm or more) and thicknesses to suit different conveyor designs and load requirements. Contact us with your specifications.Q: Are TPU belts suitable for food contact applications?
A: Standard TPU 1175A is not specifically formulated for direct food contact. However, food-grade TPU compounds are available. Please inquire if your application requires food-grade certification.Q: What temperature range can the TPU 1175A belts operate within?
A: The TPU 1175A material performs well within a typical range of approximately -30°C to +80°C. For continuous operation outside this range, consult our technical team.Q: How does the 1175A grade differ from other TPU belt materials?
A: The 1175A formulation is specifically engineered to maximize abrasion resistance while maintaining good flexibility and tear strength. It represents a balanced grade optimized for high-wear industrial conveying tasks.Q: What joining methods are available for these belts?
A> Common methods include splicing (using special TPU adhesives for a strong, flexible bond) and mechanical fasteners. The optimal method depends on the application and belt thickness. We can advise on the best joining technique.Q: Are there special storage requirements for TPU belts?
A: Store belts in a cool, dry place away from direct sunlight, extreme heat, ozone sources (like electric motors), and chemicals. Avoid folding or crushing the belts. Rolls should be stored upright.
