As a specialized polymer manufacturer based in Shanghai, China, Shanghai Yunshan Plasticizing Co., Ltd. proudly introduces our 640Z Modified PPO Resin engineered with 30% glass fiber reinforcement. This high-performance material delivers exceptional mechanical properties and thermal stability, specifically designed to meet the rigorous demands of automotive applications. Our formulation ensures optimal dimensional stability and chemical resistance, providing automotive parts manufacturers with a reliable solution that enhances product longevity and performance under extreme conditions.
Core Technical Specifications:
Enhanced tensile strength: 120-140 MPa
Deflection temperature (1.82 MPa): 160-175°C
Low coefficient of thermal expansion
Excellent hydrolytic stability
Superior electrical insulation properties
| Property | Test Method | Value |
|---|---|---|
| Density | ISO 1183 | 1.44 g/cm³ |
| Melt Flow Index | ISO 1133 | 8-12 g/10min |
| Water Absorption | ISO 62 | 0.15% |
Key Advantages for Automotive Applications:
30% glass fiber reinforcement significantly improves structural integrity for load-bearing components
Maintains performance across temperature fluctuations from -40°C to +130°C
Reduces part weight compared to metal alternatives while maintaining strength
Resistant to automotive fluids including oils, coolants, and cleaning chemicals
Simplifies assembly through design integration possibilities
Shanghai Yunshan Plasticizing leverages extensive compounding expertise to deliver consistent material performance batch after batch. Our Shanghai-based manufacturing facilities implement rigorous quality control protocols, ensuring that every shipment of 640Z resin meets exacting standards for automotive applications. With over a decade of experience serving the automotive supply chain, we understand the critical importance of material reliability in safety-critical components.
Frequently Asked Questions:
Q1: What temperature range can this material withstand?
A: The 640Z formulation maintains mechanical properties between -40°C and 130°C, making it suitable for under-hood applications.
Q2: Is this material suitable for exterior automotive parts?
A: Yes, our modified PPO demonstrates excellent weatherability and UV resistance when properly stabilized.
Q3: Can we obtain material certifications?
A: Material test reports are available upon request. Specific certification requirements can be discussed with our technical team.
Q4: What molding parameters do you recommend?
A: Optimal processing occurs with melt temperatures of 300-330°C and mold temperatures of 100-140°C. Detailed processing guidelines accompany each shipment.
Q5: How does this compare to unreinforced PPO?
A: The 30% glass fiber reinforcement increases tensile strength by approximately 150% and improves creep resistance significantly.
Q6: Are custom formulations available?
A: Yes, we offer customization options including different reinforcement levels, color matching, and special additive packages.
