Shanghai Yunshan Plasticizing Co., Ltd., a specialized polymer supplier based in Shanghai, China, proudly presents our Saudi PP CX02-82 High Flow Grade – engineered specifically for demanding thin-wall injection molding applications. This premium polypropylene resin delivers exceptional flow characteristics that enable manufacturers to achieve faster cycle times and intricate part geometries while maintaining superior mechanical properties.
Our technical team has meticulously formulated this grade to address common thin-wall processing challenges, offering:
· Unmatched flowability for complex mold filling
· Reduced warpage in finished components
· Consistent crystallinity for dimensional stability
| Property | Test Method | Value |
|---|---|---|
| Melt Flow Rate (230°C/2.16kg) | ASTM D1238 | 52-58 g/10min |
| Tensile Strength | ISO 527 | 34 MPa |
| Flexural Modulus | ISO 178 | 1450 MPa |
| Notched Izod Impact (23°C) | ASTM D256 | 5 kJ/m² |
| Deflection Temperature (0.45MPa) | ISO 75 | 110°C |
Manufacturers benefit from significant production advantages including 15-25% cycle time reduction compared to standard PP grades, up to 0.15mm achievable wall thickness consistency, and up to 98% mold fill efficiency in complex geometries. The material's low moisture absorption (
Typical applications include:
· Electronic connector housings
· Medical device components
· Automotive electrical systems
· Food packaging closures
Frequently Asked Questions:
Q: What wall thickness range is achievable with CX02-82?
A: This grade consistently produces walls between 0.15mm to 1.2mm depending on part geometry and processing parameters.
Q: Does this material require special drying conditions?
A: Standard PP drying at 80-90°C for 2-3 hours is sufficient due to low moisture absorption characteristics.
Q: Can CX02-82 be used for food contact applications?
A: This grade is suitable for food contact applications; specific compliance documentation is available upon request.
Q: What injection speeds are recommended?
A: Optimal results are achieved at 80-95% of machine maximum injection speed to utilize the material's flow properties.
Q: Is color customization available?
A: Yes, we offer standard and custom color compounding services for this grade.
Q: What is the typical order quantity?
A: Standard MOQ is 20 metric tons with flexible packaging options.
Shanghai Yunshan Plasticizing leverages strategic partnerships with Saudi polymer producers to ensure consistent supply chain reliability. Our Shanghai-based technical center provides application support including mold flow analysis and processing parameter optimization. With over 15 years of specialized PP compounding experience, we offer batch-to-batch consistency with comprehensive traceability documentation.
Contact our Shanghai headquarters today to request material samples or discuss how Saudi PP CX02-82 can optimize your thin-wall manufacturing process. Our engineering team stands ready to provide application-specific technical data sheets and processing guidelines tailored to your production requirements.
