Help CenterPP Granules 3009 - Flame Retardant PP Compound for Electrical Components, UL94 V-2 Rated
Product Spotlights
Related Products
-
RP225M RP229N High Rigidity Heat Resistant Industrial Grade Polypropylene PP PelletsNegotiableMOQ: 1000 Kilograms -
PP Resin Granules RP210G/ RP218R High Gloss Transparent Random Copolymer Polypropylene PP PelletsNegotiableMOQ: 1000 Kilograms
-
High Rigidity Heat Resistant Industrial Grade RP229N Polypropylene PP Resin Pellets RP225MNegotiableMOQ: 1000 Kilograms
-
Basel Origin PP 4160/HP500N General Purpose Injection Molding Homopolymer Polypropylene PP PelletsNegotiableMOQ: 1000 Kilograms
-
PP Resin 4160 Polypropylene Resin 6301 High Rigidity Injection Grade PP PelletsNegotiableMOQ: 1000 Kilograms
Shanghai Wenqin Plastics Co., Ltd., established in 2020 and located in the industrial hub of Shanghai, specializes in manufacturing high-performance polymer compounds. Our PP Granules 3009 is a flame retardant polypropylene compound specifically engineered for critical electrical components requiring enhanced fire safety. This material meets the stringent UL94 V-2 flammability standard, offering manufacturers a reliable solution to enhance product safety without compromising processability.
This compound combines excellent electrical insulation properties with inherent flame retardancy, making it an ideal choice for connectors, switches, housings, and other electrical parts where fire risk mitigation is paramount. We serve diverse global markets including North America, Europe, Asia, and beyond, shipping efficiently through major ports like Shanghai and Ningbo.
Our manufacturing facility, though compact (under 1,000 sqm), operates under strict quality management systems. We are proud to hold certifications including ISO 9001 for quality management and ISO 14000 for environmental management, ensuring consistent product quality and responsible manufacturing practices.
Key Technical Features & Specifications
- Superior Flame Retardancy: Achieves UL94 V-2 rating, significantly reducing flame propagation.
- Excellent Electrical Properties: High volume resistivity and dielectric strength ensure reliable insulation. Good Processability: Compatible with standard injection molding and extrusion equipment.
- Balanced Mechanical Properties: Offers a practical blend of stiffness, impact strength, and dimensional stability for component design.
- Halogen-Free Options Available: Environmentally preferable formulations can be developed upon request.
Below is a summary of typical physical properties for PP Granules 3009:
| Property | Test Method | Unit | Value |
|---|---|---|---|
| Density | ISO 1183 | g/cm³ | 0.92 - 0.96 |
| Melt Flow Rate (MFR) | ISO 1133 (230°C/2.16kg) | g/10 min | 12 - 18 |
| Tensile Strength | ISO 527 | MPa | ≥ 25 |
| Flammability Rating | UL 94 | - | V-2 |
Benefits for Your Business
- Enhanced Product Safety: Meet international flammability standards for electrical goods.
- Streamlined Sourcing: Obtain a reliable, certified material directly from a specialized manufacturer.
- Reduced Development Time: Utilize a pre-compounded material ready for your molding processes.
- Global Compliance: Material certification supports market access in regions requiring UL recognition.
- Consistent Quality: Benefit from our ISO 9001 certified quality management system.
Shanghai Wenqin Plastics, though a young company founded in 2020, has rapidly established a reputation for quality and reliability. Operating from our facility in Shanghai, we leverage our ISO 9001 and ISO 14000 certifications to ensure that every batch of PP Granules 3009 meets exacting standards. Our commitment to quality is further demonstrated by our diverse portfolio of certifications including HACCP, OHSAS18001, and TS16969, reflecting a holistic approach to management systems.
We efficiently serve a truly global customer base, exporting to North America, South America, Eastern and Western Europe, Southeast Asia, Africa, Oceania, the Middle East, and beyond. Our strategic location allows for smooth logistics via the major ports of Shanghai and Ningbo, facilitating timely deliveries worldwide. Trust Wenqin Plastics for your flame-retardant PP needs – a partner dedicated to providing materials that enhance the safety and performance of your electrical components.
Ready to improve the fire safety of your electrical products? Contact Shanghai Wenqin Plastics Co., Ltd. today for samples, technical data sheets, and competitive quotations for our UL94 V-2 certified PP Granules 3009.
Frequently Asked Questions (FAQ)
Q1: What is the minimum order quantity (MOQ) for PP Granules 3009?
A1: Our standard MOQ is 500 kilograms. However, we are flexible and willing to discuss smaller trial orders for new customers evaluating the material.
Q2: Can this material be customized for specific color requirements?
A2: Yes, color customization is available. We can match specific RAL or Pantone codes upon request. Standard colors include white and natural.
Q3: Are there halogen-free versions of this flame-retardant PP compound?
A3: While the standard 3009 grade may contain halogenated flame retardants, we do offer halogen-free alternatives. Please inquire about our HF series for environmentally preferred options.
Q4: What is the typical lead time for orders?
A4: For standard grades and colors, we typically ship within 10-15 working days after order confirmation and receipt of payment. Larger or customized orders may require slightly longer.
Q5: Do you provide material certification or test reports?
A5: Yes, we provide a Certificate of Analysis (CoA) with each batch. UL certification documentation confirming the V-2 rating is also available upon request.
Q6: What packaging options are available?
A6: The granules are typically packed in 25kg polywoven bags with inner liners. Palletization and container loading options are standard for export orders.
Q7: Is this material suitable for food contact applications?
A7: PP Granules 3009 is formulated for electrical applications. It is not specifically certified for food contact. If food-grade compliance is needed, please inquire about our other PP compounds.
Q8: Can you assist with processing parameters for injection molding this material?
A8: Absolutely. We provide technical support and recommended processing guidelines (melt temperature, mold temperature, injection speeds) to help optimize your production.
