Automated Plasma Cutting System for Structural Steel Fabrication
Product Spotlights
Precision-engineered CNC plasma cutting system specifically designed for structural steel fabrication. Features automated operation, ±0.5mm accuracy, 150mm cutting capacity, and ISO-certified manufacturing. Reduces processing time by 40% with integrated CAD/CAM compatibility and low-maintenance design for industrial environments.
Negotiable
MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Cutting Capacity:
Up to 150mm steel plate
Control System:
CNC with touchscreen interface
Positioning Accuracy:
±0.5mm
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hydraulic Press Brake for Sheet Metal Bending up to 3000 TonsNegotiableMOQ: 10 Pieces -
On-Site Technical Support for Industrial Metal Machining ProjectsNegotiableMOQ: 10 Pieces
-
Custom Metal Fabrication for Construction Equipment PartsNegotiableMOQ: 10 Pieces
-
Metal Material Processing With 12-Month Performance WarrantyNegotiableMOQ: 10 Pieces
-
Copper & Brass CNC Milling Service for Electrical ConnectorsNegotiableMOQ: 10 Pieces
Cutting Capacity
Up to 150mm steel plate
Control System
CNC with touchscreen interface
Positioning Accuracy
±0.5mm
Power Supply
High-frequency plasma generator
Applications
Beams, channels, I-beams fabrication
Certifications
ISO9001, ISO14000, OHSAS18001
Cooling System
Integrated water cooling
Software Compatibility
Industry standard CAD/CAM formats
Anping Kexing Wire Mesh Manufacturing Co., Ltd., located in Hengshui, Hebei, China, proudly presents our Automated Plasma Cutting System engineered specifically for structural steel fabrication needs. With decades of manufacturing expertise and certifications including ISO9001, ISO14000, and OHSAS18001, our systems deliver unmatched precision and reliability for fabricators worldwide.
This advanced system transforms structural steel processing through:
- ➤ Fully automated operation reducing manual labor requirements
- ➤ High-velocity plasma cutting for complex structural profiles
- ➤ Integrated CAD/CAM compatibility for seamless workflow integration
Technical Specifications Overview:
| Feature | Specification |
|---|---|
| Max Cutting Thickness | 150mm carbon steel |
| Positioning Accuracy | ±0.5mm |
| Cutting Speed Range | 100-4000mm/min |
| Power Consumption | 120KVA |
Operational advantages include:
- • Enhanced Productivity: Automated material handling reduces processing time by up to 40% compared to manual operations
- • Precision Engineering: Advanced motion control ensures accurate replication of complex structural components
- • Minimal Maintenance: Sealed rail systems and protected cable carriers ensure longevity in industrial environments
With established presence across North America, Europe, Asia, and other global markets, our systems meet international quality standards. The combination of our ISO certifications and proven track record with structural steel fabricators makes this plasma cutting solution a reliable investment for your operation.
Frequently Asked Questions:
-
Q: What materials can this system process?
A: Designed primarily for structural steel (carbon steel, stainless steel), with capability for aluminum and other conductive metals. -
Q: Is operator training provided?
A: Comprehensive training packages are available covering machine operation, maintenance, and software programming. -
Q: What file formats does the system accept?
A: Standard DXF, DWG, and NC code formats are compatible through our conversion software. -
Q: How does the cooling system work?
A: Integrated water circulation cools the plasma torch and power components during extended operations. -
Q: What safety features are included?
A: Emergency stop systems, thermal overload protection, and arc voltage monitoring ensure safe operation. -
Q: Can the system handle large structural beams?
A: Customizable worktables are available to accommodate oversized structural components.
