Thin Balde slitter
1.Slitting Part: adopt high quality tungsten steel blade, sharp and long work-life, slice more tidy, non-pressing and non-burr.
2.Scoring Part: adopt 5 points scoring, scoring distance in-phase adjust, blazonry and easy to bend the carton Sheet.
3.Grinding Part: adopt automatic and manual two kinds pneumatic grinding type, it could be grinding when working, improve work efficiency.
4.Electric control lift-down and correct error, easy to operate, suit for different requirements.
5.Adopt China famous brand or imported electric element, dependable performance.
6.Adopt synchronous belt drive, low noisy and work steady.
7.It could be adopts double machine type, easy and fast change cutting order.
8.Max running speed for production line:150m/min
9.with protect cover,make sure the workers safety
Model |
2000 |
2500 |
3000 |
3500 |
Width of paper board(mm) |
2000 |
2500 |
3000 |
3500 |
Speed of paper dividing(m/S) |
2 |
2 |
2 |
2 |
Driving power(kw) |
1.1 |
1.5 |
2.2 |
2.2 |
Weight(kg) |
1000 |
1400 |
2000 |
2500 |
Size of conflguration |
2400*1100*1170 |
2900*1100*1170 |
3400*1100*1170 |
3400*1100*1170 |
If you are also interested in this machine,please don’t hesitate to contact us:
Overseas manager: Tom Wang
Email:cartonmachine.tomwang@aliyun.com
Phone/Wechat/Whatsapp:+86 13303078975
