Help CenterMulti-Tier Order Picking Trolley With Steps for Warehouse Logistics
Product Spotlights
• Integrated ladder with anti-slip platforms enhances worker safety
• Reduces travel time between storage locations by 25%+
• 200kg/platform capacity supports bulk item handling
• Ergonomic climbing height spacing reduces fatigue
• Industrial-grade casters with brakes ensure stationary stability
Related Products
-
Metal Folding Security Roll Cage Trolley for Warehouse LogisticsNegotiableMOQ: 1 Set -
150kg Capacity Adjustable Handle Platform Truck for Factory & WorkshopNegotiableMOQ: 1 Set
-
Heavy-Duty KPX Rail Trolley for Internal Factory Material TransportNegotiableMOQ: 1 Set
-
Collapsible Stackable Wire Mesh Trolley With Wheels for Industrial UseNegotiableMOQ: 100 Sets
-
Heavy Duty Steel Wire Mesh Storage Cage Pallet for Warehouse LogisticsNegotiableMOQ: 100 Sets
As a specialized manufacturer at Dongguan Jinchuan Logistics Equipment Co., Ltd., we engineer the Multi-Tier Order Picking Trolley to revolutionize warehouse operations. Serving global markets from North America to Oceania, our solutions address the critical need for efficient, safe vertical storage access. This stepped trolley transforms manual picking processes by enabling simultaneous multi-level item retrieval, significantly reducing travel time between shelves. With over 85% of warehouse injuries related to falls, our integrated ladder system provides essential stability for high-level access – a key differentiator in logistics safety.
Core technical specifications include:
- Structural Integrity: Fabricated from 1.2mm thickness steel tubing with reinforced joints
- Ergonomic Design: Step heights optimized at 300mm intervals for natural climbing motion
- Platform Safety: Diamond-pattern anti-slip steel plates prevent foot slippage
- Mobility System: Dual-mode casters (lockable swivel front + rigid rear) ensure precise maneuvering
| Parameter | Specification |
|---|---|
| Overall Dimensions | H1500×W800×D600mm |
| Platform Area (each) | 750×500mm |
| Frame Material | Powder-coated carbon steel |
| Max Load Distribution | 200kg/platform + 150kg/user |
| Wheel Configuration | Ø125mm polyurethane casters |
Operational advantages extend beyond specifications:
- Pick Density Optimization: Consolidates 3 separate pick faces into single mobile unit
- Travel Reduction: 27% decrease in worker walking distance observed in trials
- Cross-Docking Efficiency: Integrated platforms enable sort-while-gather functionality
- Adaptive Configuration: Modular design allows platform quantity adjustment (2-4 tiers optional)
Trusted by logistics teams across 15 global markets including Eastern Europe and North America, our trolleys withstand 3-shift operations in demanding environments. Western European distributors report 40% faster induction for new warehouse staff using this stepped system compared to traditional ladders. With Jincharan's decade-long specialization in Guangdong's manufacturing hub, we offer bulk order discounts for Southeast Asian and African distributors while maintaining OEM quality standards.
Frequently Asked Questions:
-
Q: What gauge steel is used in frame construction?
A: We utilize 16-gauge (1.6mm) rectangular tubing for primary structure with 14-gauge reinforcements at stress points. -
Q: Can the trolley navigate narrow warehouse aisles?
A: The 600mm depth allows navigation in 1.8m wide aisles. Narrower 750mm width versions are available. -
Q: Are anti-slip surfaces maintained in cold storage?
A: Our specialized epoxy powder-coating maintains grip at -20°C environments. -
Q: How does this compare to traditional picking ladders?
A: Provides 360° platform access vs ladder's single-face operation, with integrated cart functionality. -
Q: What maintenance do casters require?
A: Sealed bearing industrial casters need only occasional cleaning – no regular lubrication. -
Q: Can we add branding to the trolley?
A: Custom powder-coat colors and laser-etched logos are available for orders above 50 units.
