As a trusted manufacturer since 2011, Zhejiang Zhong Shark Industrial Technology leverages our 30,000-50,000 sqm advanced facility and decade-long expertise to deliver the SG-M150 - a precision-engineered metal detection solution specifically designed for food processing environments. This industrial-grade system combines FDA-compliant materials with robust detection capabilities to safeguard your production line against costly contamination incidents.
Core Technical Specifications:
| Parameter | Specification |
|---|---|
| Detection Accuracy | Ferrous: 0.8mm | Non-Ferrous: 1.2mm | Stainless: 1.5mm |
| Belt Material | FDA 21 CFR Compliant Polyurethane |
| Belt Speed | Adjustable up to 120 m/min |
| IP Rating | IP65 Standard Protection |
| Rejection System | Pneumatic or Mechanical Options |
Operational Advantages:
Advanced DSP technology reduces false positives by 90% compared to conventional systems
Quick-release mechanism enables belt change within 15 minutes
Multi-frequency scanning adapts to varying product characteristics
Hygienic design with minimal crevices complies with HACCP requirements
FAQ Section:
Q: What maintenance does the PU belt require?
A: Our FDA-compliant belts need only basic cleaning with food-safe sanitizers and periodic tension checks.
Q: Can this integrate with existing production lines?
A: Yes, with customizable mounting brackets and I/O interfaces for PLC connectivity.
Q: How does it handle wet environments?
A: The IP65-rated housing and sealed electronics withstand high-pressure washdowns.
Q: What about temperature variations?
A: Automatic temperature compensation maintains detection accuracy across -10°C to 50°C.
Q: Is calibration complicated?
A: One-touch calibration with test samples takes under 2 minutes.
Q: What warranty is provided?
A: We offer 24-month warranty on critical components with lifetime technical support.
Backed by ISO9001 certification and serving global markets from North America to Oceania, our Zhoushan-based manufacturing facility employs rigorous quality control across all 101-200 production specialists. With shipments available via Shanghai or Ningbo ports, we ensure this industrial metal detector delivers uncompromising contamination protection while reducing your operational downtime by up to 40%. Contact our engineering team today for a custom solution assessment.
