Help CenterSD-212C 18-75V 100-720mA Backlight Power Supply for TVs and Monitors With Custom PCBA Options
Product Spotlights
Related Products
-
CE Certified DR-120-24 DIN Rail Mount 120W 24V AC/DC Switching Power SupplyNegotiableMOQ: 500 Pieces -
350W 12V 29A CE RoHS Compliant AC/DC Switching Power Supply for Industrial UseNegotiableMOQ: 500 Pieces
-
UL Certified IP68 Waterproof LED Driver With PFC 12V-48V 60W-300W High Power Factor Switching Power SupplyNegotiableMOQ: 500 Pieces
-
NDR-240-12 240W 12V 20A DIN Rail Mount AC/DC Switching Power SupplyNegotiableMOQ: 500 Pieces
-
16W 24VDC 670mA Waterproof Transformer AC DC Adapter With UL/CUL Certificate for Electronic FaucetUS$ 2 - 3MOQ: 50 Pieces
Established in 2008, Shenzhen Anenerge leverages its 1,000-3,000 sqm manufacturing facility and ISO-certified processes to deliver precision power solutions like the SD-212C. Designed specifically for modern display systems, this backlight power supply combines adaptive voltage regulation with customizable PCBA configurations to solve critical backlighting challenges in commercial display applications.
Core Technical Advantages:
- Intelligent Voltage Adaptation - Automatically maintains stable output across 18-75V input fluctuations
- Precision Current Control - 100-720mA adjustable output via resistor programming
- Thermal Management System - -40°C to +85°C operational range with auto-shutdown protection
- Modular PCBA Design - Supports custom circuit layouts and component substitutions
Performance Specifications:
| Parameter | Value | Benefit |
| Efficiency Rating | ≥89% @ full load | Reduces thermal stress on display panels |
| Ripple Noise | <150mVp-p | Eliminates screen flickering artifacts |
| Protection Features | OVP/SCP/OTP | Prevents cascade failures in LED arrays |
The SD-212C's universal compatibility spans LED/LCD panels from 32" to 85", with parallel operation support for large-format video walls. Our modular PCBA approach allows OEMs to optimize component placement for specific enclosure dimensions while maintaining UL94-V0 flame-rated insulation standards.
Operational Benefits:
- 30% reduction in backlight failure rates versus conventional drivers
- 5-year calculated MTBF with derating design methodology
- Conformal coating option for humid environments (IPC-CC-830B compliant)
Backed by Anenerge's 51-100 person engineering team and US$1-1.5M annual export capacity, this solution ships globally through Shenzhen/Guangzhou ports. With overseas offices supporting North/South America, Europe and Mid East markets, we provide localized technical assistance and warranty coverage. Contact our HACCP-certified manufacturing team today to discuss your custom PCBA requirements.
FAQ
Q: What panel thicknesses does this driver support?
A: Compatible with slim designs from 5mm to standard 15mm LED bars.
Q: Is dimming functionality included?
A: 0-10V/PWM dimming signals are supported through optional interface boards.
Q: Can you provide waterproof versions?
A: IP67-rated housings available upon request.
Q: What's the minimum order quantity for custom PCBA?
A: MOQ starts at 500 units with 4-6 week lead time.
Q: Are international certifications included?
A: Base unit carries ISO19011:2000 with region-specific certifications optional.
Q: How do I adjust output current?
A: Via simple resistor change on the control PCB (values provided in datasheet).
Q: What thermal management is recommended?
A: Requires ≤50°C ambient with 10mm clearance; heatsink kits available.
Q: Do you provide EMC test reports?
A: Full EN55032 compliance documentation provided with shipment.
