Textured PVC Plastisol Coating for Hand Tools - Non-Slip Grip, ASTM D638 Certified
Product Spotlights
ASTM D638 certified PVC plastisol coating provides enhanced non-slip grip for hand tools through engineered texture patterns. Improves safety in wet/oily conditions with vibration damping properties. Customizable colors/thickness with chemical/abrasion resistance. ISO-certified manufacturing ensures consistent performance for global tool manufacturers.
US$ 2 - 4
MOQ: 1000 Kilograms
Key Specifications
Get Latest Price
Certification:
Other, ASTM D638 Certified
Material:
PVC Plastisol
Application:
Hand Tools Grip
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
PVC Plastisol Wire Coatings - 600V Insulation, UL 62 StandardUS$ 2 - 4MOQ: 1000 Kilograms -
High Adhesion PVC Plastisol Dip Coating for Industrial Equipment - 200°C Heat ResistanceUS$ 2 - 4MOQ: 1000 Kilograms
-
Corrosion-Resistant PVC Plastisol for Marine Hardware - Salt Spray Test 500hrsUS$ 2 - 4MOQ: 1000 Kilograms
-
PVC Plastisol Coatings for Metal Fabrication - 0.5mm Thickness, RoHS CompliantUS$ 2 - 4MOQ: 1000 Kilograms
-
PVC Plastisol Coated Handrails for Public Facilities - ADA Compliant, Slip-ResistantUS$ 2 - 4MOQ: 1000 Kilograms
Certification
Other, ASTM D638 Certified
Material
PVC Plastisol
Application
Hand Tools Grip
Feature
Non-Slip Textured Surface
Color Options
Customizable
Function
Enhanced Grip & Vibration Reduction
Durability
Abrasion and Chemical Resistant
Thickness
0.5-1.2mm (Adjustable)
As a leading manufacturer since 2018, Nanjing Vaughn Tech leverages its 5,000-10,000㎡ facility and ISO-certified production systems to deliver premium Textured PVC Plastisol Coatings engineered for professional hand tools. Our ASTM D638 certified coating transforms standard tools into ergonomic masterpieces, combining safety with performance through its patented non-slip technology.
Core Advantages:
- Superior Traction: Micro-textured surface increases friction coefficient by 40% compared to standard coatings
- Impact Protection: Absorbs up to 70% vibration energy during heavy-duty applications
- Environmental Resilience: Withstands temperatures from -30°C to 90°C and resists oils/solvents
Technical Specifications:
| Parameter | Value | Test Method |
| Tensile Strength | 12-15 MPa | ASTM D638 |
| Elongation at Break | 350-450% | ASTM D638 |
| Peel Adhesion | >25 N/cm | ISO 8510-2 |
The diamond-pattern texture design ensures secure grip even with wet/oily hands, while our plastisol formulation maintains flexibility in freezing conditions. Application versatility covers screwdrivers, pliers, wrenches, and specialty tools with custom color matching available.
Backed by our US$2.5-5M annual exports to 15+ global markets including North America and EU, we guarantee batch consistency through ISO9001-controlled processes. Our Shanghai/Ningbo port logistics ensure timely delivery alongside comprehensive technical support. Experience how our coating reduces workplace accidents – request samples today.
FAQ:
-
Q: What's the curing temperature requirement?
A: Optimal curing occurs at 180-200°C for 10-15 minutes in convection ovens. -
Q: Can it be applied over existing coatings?
A: Requires bare metal surface; not recommended over existing coatings. -
Q: Minimum order quantity?
A: MOQ starts at 200kg with custom formulations available. -
Q: Lead time for samples?
A: 7-10 working days for standard formulation samples. -
Q: Chemical resistance level?
A: Resists gasoline, alcohols, and dilute acids (pH>4) per ISO 2812-2. -
Q: Shelf life of unapplied coating?
A: 12 months in sealed containers at 15-25°C. -
Q: Compatible with powder-coated handles?
A: Designed for direct metal application; compatibility testing recommended. -
Q: UV degradation resistance?
A: Contains UV stabilizers preventing cracking/discoloration for 5+ years outdoors.
