Shandong Huilong Electrical Material Co., Ltd., established in 1970 with ISO-certified manufacturing facilities spanning over 10,000 square meters, proudly presents our premium High Conductivity Enamelled Copper Magnet Wire. Engineered for demanding electromagnetic applications, this 0.8mm diameter wire delivers exceptional electrical performance with 180°C thermal stability. Our five decades of expertise ensure precise manufacturing tolerances and consistent quality for industrial power systems.
This magnet wire features:
- Optimized conductivity - Minimizes energy loss in electromagnetic circuits
- Thermal endurance - Maintains integrity at continuous 180°C operation
- Precision dimensions - 0.8mm diameter with ±0.01mm tolerance
- Dielectric strength - High breakdown voltage insulation
- Mechanical durability - Resists winding stress during coil fabrication
Technical specifications:
| Parameter | Value | Standard |
| Conductor resistance | ≤0.033 Ω/m | IEC 60317 |
| Dielectric strength | ≥5.5 kV | ASTM D1676 |
| Elongation | ≥30% | ISO 6892 |
| Thermal shock | No cracking at 3×d | NEMA MW1000 |
Applications include:
- Electric motor windings
- Power transformer coils
- Solenoid valves and actuators
- Generator armatures
- Induction heating systems
FAQ
Q: What temperature class does 180°C rating correspond to?
A: This corresponds to Class H insulation per IEC 60085 standards, suitable for most industrial applications.
Q: Can this wire be used in inverter-fed motors?
A: Yes, the enamel insulation provides excellent resistance to partial discharge phenomena common in VFD applications.
Q: Are custom diameters available?
A: We offer customization from 0.2mm to 2.5mm diameters with equivalent thermal performance.
Q: What packaging options do you provide?
A: Standard spool sizes from 1kg to 20kg, with custom packaging solutions upon request.
Q: Do you provide material certification?
A> Full traceability with material certifications including RoHS compliance documentation.
Q: What is your production lead time?
A: Standard orders ship within 15 working days from Qingdao/Shanghai ports.
Backed by our $100M+ annual export volume and certifications including ISO9001 and OHSAS18001, we guarantee consistent quality across all production batches. With established supply chains to North America, Europe, and Asia, our 51-100 member engineering team ensures technical support throughout your project lifecycle. Experience the Huilong advantage - contact us today for samples or discuss your specific winding requirements.
