Track-Mounted High-Performance Wood Crusher for Efficient Chipping Operations
Product Spotlights
Mobile track system enables on-site processing in challenging terrains. High-torque diesel engine processes 30-80 tons/hour of wood waste. ISO9001-certified hardened steel construction ensures durability. Adjustable chip sizing (10-150mm) meets diverse biomass requirements. Global technical support from experienced manufacturer with export presence in 15+ markets.
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Power Source:
Other, Diesel Engine
Mounting Type:
Track-mounted
Material Construction:
Hardened Steel Components
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Wood Crusher for Garden Waste Recycling and CompostingNegotiableMOQ: 1 Piece -
Industrial Wood Crusher With Conveyor Belt for Continuous OperationNegotiableMOQ: 1 Piece
-
Wood Crusher for Sawdust Production in Particleboard ManufacturingNegotiableMOQ: 1 Piece
-
Electric Wood Crusher 15KW Motor for Biomass ProcessingNegotiableMOQ: 1 Piece
-
Portable Wood Crusher 220V/380V for On-Site ProcessingNegotiableMOQ: 1 Piece
Power Source
Other, Diesel Engine
Mounting Type
Track-mounted
Material Construction
Hardened Steel Components
Processing Capacity
30-80 tons/hour (customizable)
Application
Forestry, Recycling, Biomass Production
Certification
ISO9001 Quality Management System
Output Size
Adjustable 10-150mm Wood Chips
Mobility Feature
Hydraulic Folding Conveyor System
Control System
PLC with Touchscreen Interface
As an ISO9001-certified manufacturer with global exports reaching US$1.5-2.5 million annually, Henan Riku Machinery proudly presents our track-mounted wood crusher engineered for demanding chipping operations. With over 3,000 square meters of advanced manufacturing facilities in Zhengzhou, we've developed this high-performance solution to address the core challenges of mobile wood processing across diverse terrains.
Core Technical Advantages:
- Autonomous Mobility: Integrated crawler system enables operation in challenging environments without towing vehicles
- Intelligent Processing: PLC-controlled hydraulic feed system automatically adjusts speed based on material density
- Dual-Shaft Mechanism: Interlocking blades with tungsten carbide tips process logs up to 650mm diameter
- Dust Suppression: Optional water spray system reduces particulate emissions by 85%
| Parameter | Specification |
|---|---|
| Engine Power | 298 kW (400 HP) Tier 3 Diesel |
| Track Width | 500mm with hydraulic tensioning |
| Feed Opening | 1200×800 mm |
| Discharge Height | 3.2m (extendable to 4.5m) |
| Ground Pressure | <0.35 kg/cm² |
Operational Benefits: Our clients in North American forestry and European recycling operations report 40% faster job completion versus wheeled units. The hydraulic leveling system maintains stability on 15° slopes, while remote diagnostics minimize downtime through predictive maintenance alerts.
Trusted by biomass producers across 15 global markets including Oceania and Southeast Asia, this equipment ships from Shanghai or Qingdao ports with comprehensive technical documentation. Our 50+ engineering team provides lifetime support, including:
- Operator training simulators
- Wear-part replacement programs
- Site-specific configuration consulting
Frequently Asked Questions:
-
Can it process palm or bamboo?
Yes, with optional specialized blade configurations -
What maintenance intervals are required?
Daily greasing points, with major service at 500-hour intervals -
Is road transport possible?
Unit folds to 2.8m width for standard trailer transport -
How is blade wear monitored?
Vibration sensors provide real-time thickness measurements -
Can it handle wet material?
Self-cleaning rotor design processes wood up to 45% moisture -
What safety features are included?
Emergency stop system, anti-restart protection, and discharge deflectors
