450/750V AC Rubber Insulated Power Cable for ESP and Electrical Systems
Product Spotlights
Premium rubber insulation ensures flexibility and durability in demanding ESP applications. With 450/750V AC rating and copper conductors, it delivers reliable power transmission in harsh environments. Customizable configurations for specific industrial needs, featuring oil/moisture resistance and extended temperature tolerance. Reduces maintenance costs through enhanced longevity.
Negotiable
MOQ: 500 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Insulation Material:
Other, High-grade rubber compound
Conductor Material:
Other, Copper (customizable)
Rated Voltage:
450/750V AC
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
3KV 6KV High Voltage ESP Cable for Electric Submersible Pump Power SupplyNegotiableMOQ: 500 Meters -
High Voltage Flat Electric Cable for Submersible Oil Pumps and ESPNegotiableMOQ: 500 Meters
-
Flat Submersible Power Cable for Electric Oil Pumps and ESP SystemsNegotiableMOQ: 500 Meters
-
Shielded ESP Cable With EMI Protection for Precision InstrumentationNegotiableMOQ: 500 Meters
-
Industrial ESP Cable With 600V Voltage Rating for Harsh EnvironmentsNegotiableMOQ: 500 Meters
Insulation Material
Other, High-grade rubber compound
Conductor Material
Other, Copper (customizable)
Rated Voltage
450/750V AC
Core Configuration
Customizable core numbers
Application Fields
ESP systems and industrial electrical
Temperature Range
Customizable operating temperature
Certification Compliance
International electrical standards
Cable Color
Black (standard), customizable
Outer Sheath
Weather-resistant rubber
As a specialized manufacturer based in Jinan, Shandong, Shandong Huaning Electric Heating Technology Co.,Ltd delivers premium 450/750V AC rubber insulated power cables engineered for Electrical Submersible Pump (ESP) systems and industrial electrical networks. Our cables provide exceptional reliability in demanding environments through advanced rubber insulation technology that ensures operational safety and longevity. Designed to withstand challenging conditions, they offer superior flexibility and durability compared to standard alternatives.
Key technical advantages include:
- Enhanced Safety: Multi-layer rubber insulation prevents electrical leakage and short circuits
- Environmental Resistance: Excellent performance in moisture, oil, and chemical exposure scenarios
- Flexibility Advantage: Maintains performance in tight bending radius installations
- Temperature Adaptability: Customizable operating range for specific environmental needs
- Reduced Maintenance: Robust construction minimizes downtime in industrial applications
Technical specifications include:
| Parameter | Standard Specification | Custom Options |
|---|---|---|
| Conductor Cross-section | 1.5-240 mm² | Available upon request |
| Core Numbers | 1-5 cores | Multi-core configurations |
| Operating Temp | -20°C to +70°C | Extended ranges |
| Insulation Thickness | 0.8-2.0mm | Application-specific |
Applications extend beyond ESP systems to include:
- Industrial machinery power distribution
- Fixed installations in control systems
- Renewable energy connections
- Construction site power networks
Backed by Shandong Huaning's expertise from China's industrial hub in Jinan, our manufacturing processes implement rigorous quality control protocols. With dedicated R&D capabilities, we ensure each cable delivers consistent performance in critical applications. Partner with us for tailored solutions that optimize your electrical infrastructure's reliability and efficiency.
Frequently Asked Questions:
-
Q: What makes rubber insulation superior for ESP applications?
A: Rubber maintains flexibility in submersible environments while providing excellent dielectric strength and resistance to oil/moisture degradation. -
Q: Can these cables withstand direct burial?
A: Yes, with additional sheath protection options available for underground installations. -
Q: Are custom lengths available?
A: We provide precise cutting and drumming services per project requirements. -
Q: What termination methods are recommended?
A: Compatible with standard cable glands and connectors; specific recommendations depend on application voltage. -
Q: How does temperature affect performance?
A: Our rubber compound maintains insulation properties across specified ranges; extreme conditions may require custom formulations. -
Q: What's the minimum bending radius?
A: Typically 6-8 times the cable diameter, varying by configuration and conductor size. -
Q: Do you provide testing documentation?
A> Electrical and mechanical test reports are available upon request.
