Jinan ZeYe Machine Tool Co., Ltd, founded in 1998,is a professional manufa cturer and exporter that is concerned with thedesign development and production of cutting equipment.We are located in Shandong,with an advantageously geographical loca tion and convenient transportation.We hold series of advanced Mazak equipment processing centers, domestically advanced production technologies and complete testing equipm ent and quality systems.It gives us a broad development space.
All of our products comply w ith international quality standards and are greatly appreciated in a variety of different marke ts throughout the world.In addition,all our product are high quality and low overhead and h ave passed the certification of ISO9001：2000.
Whole plant planning, corollary equipment, after-sales and in providing one-stop servic e.we are committed to enable customers to buy the most cost-effective equipment, enjoy th e best quality pre-sale and after-sale service.
A steel coil cross‑cut line (also known as a cut‑to‑length line) is an integrated processing system that performs automatic uncoiling, leveling, feeding, cross‑cutting, conveying, and stacking of metal coils. It offers outstanding advantages in high‑volume sheet metal production, as elaborated below:
Model |
ZCL-6 |
ZCL-8 |
ZCL-12 |
ZCL-16 |
ZCL-20/25 |
Material thickness |
1.5-6.0mm |
2-8 mm |
3-12 mm |
4-16 mm |
6-20/25 mm |
Material width |
800-2000 mm |
800-2000 mm |
800-2000 mm |
800-2200 mm |
800-2500 mm |
Finished length |
1000-6000 mm |
1000-8000 mm |
100-12000 mm |
2000-14000 mm |
2000-14000 mm |
Length accuracy |
±1.0 mm |
±1.0 mm |
±1.0 mm |
±1.0 mm |
±1.0 mm |
Diagonal accuracy |
±1.0 mm |
±1.0 mm |
±1.5 mm |
±1.5 mm |
±1.5 mm |
Leveling accuracy |
|||||
Line speed |
50 m/min |
40 m/min |
40 m/min |
40 m/min |
30 m/min |
Coil weight |
20,30 t |
20,30 t |
20,35 t |
20,35 t |
20,35 t |
1. Flexible Production & Quick Specification Switching
The control system supports quick storage and calling of processing parameters such as length, quantity, and cutting speed. Production specifications can be rapidly adjusted to meet small‑batch, multi‑variety order demands, enhancing production flexibility and market responsiveness.
2. Neat Automatic Stacking & Easy Subsequent Handling
After cross‑cutting, sheets are automatically aligned, counted, and stacked in order. Neatly arranged sheets facilitate subsequent handling, storage, packaging, and processing, reducing secondary sorting work and improving logistics efficiency.
3. Enhanced Product Competitiveness
By improving precision, efficiency, and surface quality while reducing costs, the cross‑cut line helps manufacturers produce higher‑quality sheet products at a lower cost, thus strengthening product competitiveness in both domestic and international markets.
