Henan San Kuang Machinery Technology Co., Ltd., established in 2014 with 10,000-30,000 sqm manufacturing facilities in Luoyang, specializes in precision-engineered transmission components. Our hardened gear shaft with spline ends delivers exceptional torque transmission efficiency and extended service life in demanding industrial environments. Manufactured in compliance with DIN 5480 standards, this component ensures precise power transfer while minimizing vibration and wear. With over 51-100 skilled technicians and annual exports of $2.5M-$5M worldwide, we guarantee components that meet rigorous international quality benchmarks.
Core Technical Specifications:
- Precision-ground spline ends ensure perfect mating with gear assemblies
- Through-hardened to HRC 45-55 for superior wear resistance
- Involute spline profile according to DIN 5480 specifications
- Optimized tooth root geometry prevents stress concentration
- Surface roughness maintained at Ra ≤ 0.8μm for smooth operation
- Magnetic particle inspected for subsurface defects
| Parameter | Specification | Testing Method |
|---|---|---|
| Material Grade | 20MnCr5 / 42CrMo4 | Spectrometer analysis |
| Hardness Depth | 1.5-3mm case depth | Microhardness testing |
| Spline Tolerance | DIN 5480 Class 7 | CMM measurement |
| Straightness | ≤0.05mm/m | Optical comparator |
The induction hardening process creates a martensitic microstructure in the surface layer while maintaining ductility in the core material. This dual-property configuration provides excellent resistance to pitting and fatigue failure. Spline teeth undergo profile grinding after heat treatment to maintain dimensional accuracy within 0.01mm tolerance. For specialized applications, we offer various surface coatings including phosphating and black oxide treatment upon request.
Backed by ISO 9001, TS 16949, and ISO 14000 certifications, our manufacturing processes undergo regular audits to ensure consistency. With direct shipments available from Shanghai, Qingdao, Tianjin, and Lianyungang ports, we efficiently serve global markets including North America, Europe, and Southeast Asia. Our 10,000-30,000 sqm production facility enables flexible batch sizes from prototypes to mass production. Experience the reliability difference – contact our engineering team today for customized solutions matching your exact transmission requirements.
Frequently Asked Questions:
-
Q: What materials are typically used?
A: We primarily use alloy steels like 20MnCr5 and 42CrMo4 that offer optimal strength-to-weight ratios for transmission applications. -
Q: Can you produce non-standard spline profiles?
A: Yes, our CNC gear shaping capabilities allow customization beyond standard DIN 5480 specifications. -
Q: What quality control measures are implemented?
A: Every batch undergoes dimensional checks with CMM, hardness verification, magnetic particle inspection, and surface roughness testing. -
Q: What is the typical lead time for orders?
A: Standard configurations ship in 4-6 weeks; expedited options are available for urgent requirements. -
Q: Do you provide surface treatments?
A: Various protective coatings including phosphating, black oxide, and nickel plating are available upon request. -
Q: How does hardening affect performance?
A: Controlled heat treatment increases surface hardness to HRC 45-55 while maintaining core toughness, significantly improving wear resistance. -
Q: What industries commonly use these shafts?
A: Our shafts serve automotive transmissions, industrial gearboxes, agricultural machinery, and heavy equipment applications. -
Q: Can you assist with installation specifications?
A: Our engineering team provides comprehensive mounting guidelines and torque specifications with every order.
