Help CenterHigh-Precision Plastic Tensile Testing Machine, Compliant With ISO 527-1 Standard
Product Spotlights
Related Products
-
ISO 527-1 Plastic Tensile Testing Equipment for Automotive Component TestingUS$ 3000 - 20000MOQ: 1 Set -
ISO 527-1 Compliant Plastic Tensile Testing Machine With 50kN Load CapacityUS$ 3000 - 20000MOQ: 1 Set
-
Digital Plastic Tensile Tester for ISO 527-1 Standard, 1-500mm/min Speed RangeUS$ 3000 - 20000MOQ: 1 Set
-
Industrial Plastic Tensile Tester for ISO 527-1 Testing, RS232 Data OutputUS$ 3000 - 20000MOQ: 1 Set
-
Plastic Tensile Properties Tester, ISO 527-1 Certified, Includes Technical SupportUS$ 3000 - 20000MOQ: 1 Set
As a specialized manufacturer since 2016, Jinan Wangtebei Instrument And Equipment Co., Ltd proudly delivers cutting-edge material testing solutions globally. Our High-Precision Plastic Tensile Testing Machine, rigorously engineered to comply with the ISO 527-1 standard, empowers laboratories and quality control departments to obtain reliable polymer performance data. Serving diverse markets across North America, Europe, Asia, and beyond from our base in Jinan, China, we understand the critical need for accuracy and compliance in material characterization. This instrument is designed to meet the exacting demands of research institutions and industrial production lines seeking trustworthy tensile property measurements.
Core Features & Technical Excellence:
- Unmatched Precision: Incorporates advanced load cell technology and high-resolution displacement sensors, ensuring measurement accuracy meets stringent international testing requirements essential for R&D and quality certification.
- ISO 527-1 Compliance: Pre-configured test protocols specifically for determining the tensile properties of plastics according to ISO 527-1, guaranteeing standardized and reproducible results.
- Versatile Testing Capabilities: While optimized for plastic tensile tests, the system can be optionally configured for compression, bending, and shear tests on various materials, offering exceptional value.
- Intuitive Microcomputer Control: Features a user-friendly touchscreen interface and powerful software for real-time data acquisition, curve plotting, automatic calculation of key parameters (tensile strength, elongation at break, modulus of elasticity), and comprehensive report generation.
- Robust Construction & Safety: Built with high-grade components for durability and equipped with overload protection and emergency stop mechanisms to safeguard both the operator and the equipment.
Key Technical Specifications:
| Parameter | Specification |
| Maximum Capacity | 5 kN / 10 kN / 20 kN (Customizable) |
| Force Accuracy | ±0.5% of reading |
| Displacement Resolution | 0.001 mm |
| Test Speed Range | 0.05 mm/min to 500 mm/min (Infinitely Variable) |
| Grip Types | Manual Wedge Grips, Pneumatic Grips, Film Grips (Available) |
| Data Sampling Rate | Up to 1000 Hz |
Benefits for Your Business:
- Ensure product quality and material consistency through accurate and repeatable tensile property measurements.
- Meet international quality standards (ISO 527-1) and customer specifications with certified test reports.
- Accelerate material development and failure analysis with reliable data and efficient testing workflows.
- Reduce costly production errors and material waste by identifying substandard polymers early.
- Enhance laboratory productivity with automated testing sequences and streamlined reporting.
Trusted Global Performance & Support:
Backed by Jinan Wangtebei's extensive experience since 2016, this tensile testing machine is a proven solution trusted by clients worldwide. We efficiently serve demanding markets including North America, South America, Eastern & Western Europe, Southeast Asia, Africa, Oceania, and the Middle East, exporting reliably through major ports like Qingdao, Shanghai, Ningbo, and Guangzhou. Our commitment extends beyond the sale; we offer comprehensive technical support, calibration guidance, and readily available spare parts to ensure your instrument performs optimally for years. Experience the Wangtebei difference – precision engineered in Jinan, Shandong, and built for global reliability.
Frequently Asked Questions (FAQ):
-
Q: Does this machine require calibration upon delivery?
A: Yes, the machine is calibrated before shipment. We recommend verification upon installation and periodic recalibration according to your quality procedures. Calibration certificates are provided. -
Q: What sample sizes and shapes can it test according to ISO 527-1?
A: It accommodates standard Type 1A and 1B multipurpose test specimens, as well as other common shapes like dog-bone samples. Specific grips for different sample geometries are available.
Q: Is the software included, and can it generate reports compliant with ISO 527-1? -
Q: Can I upgrade the machine for other test types later?
A> Yes, the modular design allows for future upgrades. Compression platens, bend fixtures, and other accessories can typically be added to expand its testing capabilities. -
Q: What warranty and after-sales service do you provide?
A> We offer a standard 12-month warranty covering parts and workmanship. Global technical support is available via email, phone, and remote assistance. Spare parts are stocked for prompt delivery. -
Q: How do I ensure I'm selecting the correct load capacity (5kN, 10kN, 20kN)?
A> Capacity selection depends on the maximum expected tensile force of your materials. We recommend analyzing your typical material strength ranges. Our engineers can assist in determining the optimal capacity for your specific needs.
A: Yes, comprehensive PC-based software is included. It features pre-defined ISO 527-1 test methods, automatically calculates all required parameters, and generates detailed test reports meeting the standard's requirements.
Take the Next Step: Elevate your plastic material testing capabilities with a reliable, high-precision solution. Contact Jinan Wangtebei Instrument today for a detailed quotation, technical consultation, or to discuss your specific application requirements.
